MULTIMEDIA DATA/VIDEO PROJECTORS

BrilliantColorTM is a trademark of Texas Instruments.

Functional Performance at Its Best

Easy Maintenance & Improved Security Features

Top-access lamp cover for easy lamp replacement

Filter-free design

Enhanced security features with reinforced

anti-theft security bar and password protection

160cm(64'')

2100lm 2500:1 contrast ratio

Optional whiteboard and blackboard modes

Center lens design for easy symmetrical installation

Splash screen and wall screen support

Audio and video inputs for computer and video sources

Time saving shut-down feature

Impressive Short-throw Projection

The issue of presenting in locations with limited projection space is eliminated with

the new WD500U-ST. This full WXGA projector is equipped with an ultra-powerful

short-throw lens capable of projecting an amazing 60-inch diagonal image

at a distance of just 28in (70cm) from the screen. No more need to worry about

presenters casting their shadows on the screen!

70cm(28'')

Previous Mitsubishi Electric Model

[projection distance over 160cm (64in)]

Projected Image Comparison (60in screen)

Long projection distances sometimes require

the presenter to stand between the projector

and screen, casting a shadow onto the image,

and light from the projector may enter the

presenter’s field of vision, blinding them

momentarily when facing the audience.

By installing the projector close to the screen,

the presenter never has to cross the projection

path, eliminating the problem of shadows on

the screen. Furthermore, projected light does

not enter the presenter’s field of vision.

Projector Projector

WD500U-ST

Screen Screen

Shadow

Original

BrilliantColorTM

Conventional

DLP projector's

color area

BrilliantColorTM

mode

Non-BrilliantColorTM

Color spectrum

BrilliantColorTM technology is one of Texas Instruments’ latest innovations for the

production of amazingly rich and vibrant colors. At Mitsubishi Electric, we have

developed a 6-segment R, G, B, W, Y, C color wheel. Apart from the standard

red, green, blue and white, yellow and cyan segments are added to display

a wider color spectrum. Additionally, our color algorithms are coded to emphasize

brightness and color gradations that best match the environment the WD500U-ST

is being used in.

Together with selective lamp-powered modulation techniques, the WD500U-ST

intelligently processes the source data to boost color and improve the intensity

and vibrancy of the overall image. For example, when projecting an already bright

screen image, the lamp is programmed to provide brighter, more vivid colors.

In contrast, if the image shows genuine color reproduction, the algorithm delivers

just the right colors with the appropriate luminance for maximum visual impact.

Splash screen

Top-access lamp cover

BrilliantColorTM Technology and Mitsubishi Electric Engineering

Yield Superior Color Performance

WD500U-ST

Ultra-short Throw Projector

NEW

Large, Wide Screen

Regardless of Projector Location

Short-throw lens for big-screen projection in tight spaces

the WD500U-ST other

Input and Output Terminals

*Compliance with ISO21118-2005 *All brand names and product names are trademarks, registered trademarks or trade names of their respective holders.

WD500U-ST

0.65”1-Chip DMD

1280 x 800 (total 1,024,000 pixels)

2100lm

2500:1

40” ~ 300”

640 x 480 ~ 1280 x 1024, True: 1280 x 800, Sync on green available

2W mono

332 x 102 x 250 mm / 13.1 x 4.0 x 9.8 inch (excluding height adjustment)

3.4kg / 7.5lbs

AC100-240V, 50/60Hz

VLT-XD510LP

Audio speaker

Dimentions (WxHxD)

Weight

Power supply

Optional lamp

Video compatibility

Computer compatibility

NTSC / NTSC4.43 / PAL (including PAL-M, N) / SECAM / PAL-60

Component Video: 480i/p (525i/p), 576i/p (625i/p), 720p (750p), 1080i (1125i 60Hz), 1080i (1125i 50Hz)

Source lamp

Model

Display technology

Resolution

Brightness

Contrast

Picture Size

The above numbers are approximate, and may be slightly different from the actual measurements.

Screen size chart

Communication terminals

Output terminals

RS-232C (D-sub 9pin)x 1, USB terminal for Page Up/Down x 1

Input terminals

As seen from the side

Unit:mm

Dimensions

Screen size and Projection distance

RGB: mini D-sub15pin x 2, DVI-D (with HDCP), Video: RCA x 1 + S-video x 1

Audio: stereo mini jack (3.5mm)x 1, RCA jack (L/R)x 1

RGB: mini D-sub15pin x 1, Audio: stereo mini jack (3.5mm)x 1

166

332

245

71128

58 59 199

300

102

Front

Side(Left)Side(Right)Top Bottom

Specifications

180W (Shut Off Time 4000Hrs)with Low Mode,

230W (Shut Off Time 2000Hrs)with Standard Mode

Screen (16:10 aspect ratio)

Diagonal size Width (W)Height (H)

inch

inch cm inch cm cm inch

0.5

0.7

0.9

1.2

1.8

2.4

3.0

3.6

inch cm

1.6

2.4

3.2

4.0

6.0

8.0

10.0

12.0

118

142

108

135

202

269

337

404

106

132

159

129

172

215

323

431

538

646

127

170

212

254

102

152

203

254

381

508

635

762

100

150

200

250

300

Distance from

screen (L)

Height projected

image (Hd)

L-188-8-B8202-A KYO-0811 Printed in Japan(MDOC)

New publication, effective Nov. 2008

Specifications subject to change without notice.

Brilliant

ColorTM

Color

enhancer

Gamma

mode Wall

screen Cinema

mode Freeze

function

Digital

expanded

zoom

Splash

screen

Digital

keystone

Password

protection

Lamp

mode

Automatic

power on Automatic

power off

Instant

shutdown

Center

lens

Ceiling

mounted

Ultra-short

throw

lens

Closed

caption

Page

up/down

Picture performance Presentation User friendly

Ultra-short Throw Projector

WD500U-ST

Height

Projection Distance(L)

Serial RS-232C

PC / Component Video output

DVI-D (with HDCP)

S-Video / RCA

Audio input [RCA jack (L/R)]

Audio input (stereo mini jack)

Audio output

USB terminal for Page Up/Down

PC / Component Video input

(mini D-sub 15pin)

NEW

1 2 43 5 6 7 8 9
