MiTAC LBP01 Manuel utilisateur
LBP01
User’s Manual
(December 2001)
TRADEMARKS
All brand and product names are trademarks or registered trademarks of their
respective companies.
NOTE
Information in this manual is subject to change without notice.
i
0 Table of Contents
Regulations Information..........................................................ii
Safety Precautions..................................................................ii
1 Introduction ..........................................................................1
1.1 Product Description.................................................................1
1.2 Product View...........................................................................2
2 Setting Up .............................................................................3
2.1 System Requirements.............................................................3
2.2 Installing the Driver and Utility.................................................3
For Windows 98/Me/2000......................................................3
For Windows CE....................................................................6
2.3 Inserting the WLAN PC Card...................................................6
2.4 Removing the WLAN PC Card................................................7
3Using Configuration & Monitor Application Utility............8
3.1 For Windows 98/Me/2000 .......................................................8
3.2 For Windows CE...................................................................15
AAppendix.............................................................................19
A.1 Specifications........................................................................20
A.2 Uninstalling the Utility and Driver...........................................20
Configuration & Monitor Application Utility ...........................20
WLANPCCard....................................................................20
ii
Regulations Information
Federal Communications Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Caution:
To ensure continued compliance, use only shielded interface cables when connecting to computer
or peripheral devices. Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause
undesired operation.
Important Note:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance of 20
cm between the radiator and your body.
This transmitter must not be co-located or operated in conjunction with any other antenna or
transmitter.
iii
Safety Precautions
Be sure to read and follow all warning notices and instructions.
In order to extend the life of the device it is advised to store it in a protective
casing whenever carrying the computing device on travel and not operating
the device.
Never use abrasive materials or rinse the device with liquids.
At all times, it will be the responsibility of the end-user to ensure that an
outdoor antenna installation complies with local radio regulations.
Do not service the product by yourself. Refer all servicing to qualified
service personnel.
In order to limit Radio Frequency (RF) exposure, the following rules should
be applied:
–Install the antenna in a location where a distance of 20 cm from the
antenna may be maintained.
–While installing the antenna in the location, please do not turn on
power of the device.
–While the device is working (transmitting or receiving), please do not
touch or move the antenna.
–Do not operate a portable transmitter near unshielded blasting caps or
in an explosive environment unless it is a type especially qualified for
such use.
1
1 Introduction
This chapter introduces the features and functions of the product.
1.1 Product Description
Congratulations on purchasing this PCMCIA Wireless Local Area Network
(WLAN) Card.
Your WLAN PC Card’s 11 Mbps data rate provides an equivalent Ethernet
speed to access corporate networks or the Internet in a wireless environment.
When installed, the WLAN PC Card is able to communicate with any
802.11b-compliant product, allowing you to work anywhere in the coverage
area, enjoying its convenience and mobility.
Your PC Card features:
IEEE 802.11b and Wi-Fi-compliant 11 Mbps WLAN access solution
Seamless wireless roaming
Direct Sequence Spread Spectrum (DSSS) standard
Wired Equivalent Privacy (WEP) 128-bit data encryption
Frequency range at 2.4 GHz ISM band
Automatic data rate selection at 11 Mbps, 5.5 Mbps, 2 Mbps, and 1 Mbps
PCMCIA Type II Plug-and-Play
High sensitivity and output power
2
Typical applications include:
IEEE 802.11b-compliant WLAN radio
Portable PC wireless modem
Point-to-Point data
Wireless home networking
Small Office Home Office (SOHO) wireless application
1.2 Product View
Ref Component Description
Power and
Transmit/Receive
Indicator
Glows red when the WLAN PC Card is inserted into a
PCMCIA slot and is deriving power from it.
Glows green when the WLAN PC Card is sensing/
transmitting wireless data.
Integrated
Antenna Allows the WLAN PC Card to receive and transmit
wireless data.
3
2 Setting Up
This chapter tells you how to setup the device for use.
2.1 System Requirements
To use the device, you need:
Operating system: Windows 98, Windows Me, Windows 2000,
Windows CE
Available PCMCIA slot on your computing device
Driver CD
Windows installation disks (in case you are prompted for the operating
system files)
2.2 Installing the Driver and Utility
CAUTION: Do not insert your WLAN PC Card into the PCMCIA slot at this stage until you
are required to do so.
For Windows 98/Me/2000
NOTE:Whenusing Windows2000andbeforeproceeding,make sureyouhave loggedon
as “Administrator.”
1. Insert the driver CD into the CD-ROM drive and double-click the file
SETUP.EXE under the Win98_Me_2000 directory.
2. Follow the onscreen instructions to continue.
4
3. When the next screen appears, select the first option “Application &
PCMCIA Drivers” to install the utility (Configuration and Monitor
Application) and the WLAN PC Card driver.
NOTE: If the WLAN PC Card driver have been previously installed and have not been
uninstalled prior to this latest installation, the new driver will overwrite the old one without
prompting you.
4. After you have confirmed the driver’s “Destination Location” as well as the
“Program Folders,” choose the mode of operation whether Ad-Hoc or
Infrastructure on the Operating Mode Dialog window.
5
Ad-Hoc Mode
In Ad-Hoc mode the wireless stations can communicate directly with
each other.
When selecting the Ad-Hoc mode you need to specify the ESSID and
the Channel parameters.
–ESSID: All stations participating in the Ad-Hoc network should
have the same ESSID.
–Channel: Select the 14 channels available for use.
Infrastructure Mode
In Infrastructure mode the use of an Access Point (AP) is necessary for
wireless stations to communicate with each other.
When selecting the Infrastructure mode you need to specifythe ESSID.
–ESSID: Specify the ESSID of the AP to which the wireless station
will be associated with.
NOTE: You can still change the Operating Mode afterwards using the Configuration &
Monitor Application utility.
