Mirion Technologies AD2006+ Manuel d'instructions

HARDWARE QUICKSTART MANUAL

(August 2020)

This manual relates to Revision 12, 13, 14 &15 Hardware.

PLEASE ENSURE THAT YOU HAVE THE CORRECT POWER SUPPLY VOLTAGE BEFORE POWERING UP THE MODULE.

The product warranty does not cover installation error.



Miri Technologies, 2 Fellowship Road, Gnangara, Western Australia 6077 | Tel: +61 89 409 8998 | www.miri.com.au

Contents
1. Scope of this Manual.......................................................................................................................... 1
2. Ordering Information......................................................................................................................... 2
Standard Features ...................................................................................................................... 2
Optional Features & Ordering Information............................................................................... 2
Part Numbers / Ordering Code......................................................................................................... 2
General Arrangement ................................................................................................................. 3
LED Indicators..................................................................................................................................... 3
Digital I/O..................................................................................................................................... 4
Digital Inputs ...................................................................................................................................... 4
Pulse Counters.................................................................................................................................... 4
Digital Outputs ................................................................................................................................... 5
Analog I/O .................................................................................................................................... 6
Analog Inputs ..................................................................................................................................... 6
Analog Outputs (Optional) ............................................................................................................... 7
Communication Options ............................................................................................................. 8
Ports ............................................................................................................................................. 9
Port 1 –External Radio - RS232....................................................................................................... 9
Ports 2 & 5 - RS232 ............................................................................................................................ 9
Port 3 - RS485..................................................................................................................................... 9
Port 4 - USB-B ..................................................................................................................................... 9
Port 5 - Ethernet Option.................................................................................................................... 9
3. Antennas ........................................................................................................................................... 10
Vertically Polarised 400 MHz Band Antennas.............................................................................. 10
4. Wiring & Mounting ........................................................................................................................... 11
Wiring......................................................................................................................................... 11
Mounting.................................................................................................................................... 11



Page 1 of 11

Miri Technologies, 2 Fellowship Road, Gnangara, Western Australia 6077 | Tel: +61 89 409 8998 | www.miri.com.au

1. Scope of this Manual

This manual is intended to provide sufficient information for the correct installation of your AD2006+ telemetry

module. Your AD2006+ module will be delivered pre-configured to your project specifications where requested, or set

to factory defaults as specified in this manual.

For programming information, please refer to the Software Quick Start Guide, available in the Downloads section of the

Miri Technologies website, www.miri.com.au

Page 2 of 11

Miri Technologies, 2 Fellowship Road, Gnangara, Western Australia 6077 | Tel: +61 89 409 8998 | www.miri.com.au

2. Ordering Information

There are many variations of the AD2006+ telemetry modules available. The following shows the ordering code and

details for modules with or without internal data radios. For other radio or modem options please contact Miri directly.

Standard Features

The AD2006+ modules come with the following standard features:

2x RS232 Serial Ports

1x RS485 Serial Port

1x USB Port

16x Digital Inputs (including 2 fast pulse counters)

4x Isolated Relay Outputs

8x Analog Input Channels

Note: With the factory Analog Output option, any or all of the last 4 channels can be configured as 4-20mA analog

outputs.

Optional Features & Ordering Information

The following options are not fitted as factory standard and need to be requested when ordering:

Multi-session Ethernet Port Option

4 Channel Analog Output Option

Please Note: If you are ordering a module to add to an existing

system, please be sure to specify the project name when ordering

the new module.

The AD2006+ part number is displayed on the rear of each unit

together with other relevant information.

Part Numbers / Ordering Code

Page 3 of 11

Miri Technologies, 2 Fellowship Road, Gnangara, Western Australia 6077 | Tel: +61 89 409 8998 | www.miri.com.au

Technical Information

General Arrangement

LED Indicators

The pwr LED should be on at all times when the unit is powered up.

The run LED should flash at 2Hz in RUN mode and 4Hz in PROG mode.

A fault means that the module has received a bad reply to a message.

The tx and rx LEDs reflect the PTT and CD status of the internal radio.

The tx and rx LEDs for each port indicate that a valid system message has been

sent or received on that port. A link indication means that the slave time-out

period for that port has lapsed or the programmed number of retries have failed

and communications have been lost.

The first four LEDs indicate that the physical outputs are active.

The second four LEDs are programmable status indications.

These LEDs indicate that a particular input is active.

Page 4 of 11

Miri Technologies, 2 Fellowship Road, Gnangara, Western Australia 6077 | Tel: +61 89 409 8998 | www.miri.com.au

Digital I/O

Digital Inputs

There are two different versions of the AD2006+ module with respect to Digital Inputs. There is a low voltage version

for nominally 12 or 24 volt inputs, and a high voltage version specifically for 110 volt inputs. The digital inputs are

optically isolated to 2.5KV.

AD2006+ L- Lo Voltage 10-35VDC/AC 4k7 Impedance

AD2006+ H- Hi Voltage 70-130VAC/DC 27k Impedance

Note: This is not an on-board selectable option, so please ensure that you have the correct version of

hardware for your application.

The digital input voltage is marked on the terminal strip label with the ‘Lo’ voltage inputs in blue, and the ‘Hi’ voltage

inputs in orange.

The digital inputs are supplied in two blocks of 8 inputs each, with a separate common terminal.

The inputs will accept an AC input voltage or a DC voltage of either polarity.

Pulse Counters

Each Digital Input may be used as a pulse counter up to 5Hz. The first two inputs can be configured as high speed pulse

counters up to 5 KHz (equal mark space ratio).

Where the inputs are used as slow counters (to 5Hz), the inputs are usually referred to the digital input

common.

Where the fast pulse counters are used, the inputs are referred to the module 0V supply (ground).

The digital inputs will then accept inputs from common emitter transistors, FETs or reed switches etc. as shown below.

The factory default setting is for all inputs to be configured as digital inputs / slow counters. The following jumper

settings apply where inputs 1 or 2 are required to be fast counters.

Jumper Configurations

Digital Input Wiring

All inputs

DINs (factory

default)

(OR)

DIN1 –

Fast Pulse

(OR)

DIN2 –

Fast Pulse

Page 5 of 11

Miri Technologies, 2 Fellowship Road, Gnangara, Western Australia 6077 | Tel: +61 89 409 8998 | www.miri.com.au

Digital Outputs

Each of the four Digital Outputs may be individually configured as an isolated relay or common emitter transistor.

Isolated Relay Configuration (factory default)

Common Emitter Configuration

With all jumpers J12 - J15 in position A, the module is

configured for 2 SPST and 2 SPDT relay outputs.

With all jumpers J12 - J15 in position B, all outputs are

common emitter transistors.

Page 6 of 11

Miri Technologies, 2 Fellowship Road, Gnangara, Western Australia 6077 | Tel: +61 89 409 8998 | www.miri.com.au

Analog I/O

Analog Inputs

The AD2006+ module has 8 analog input channels as standard. These are configured from the factory as

4-20mA/1-5V. The following options are available by jumper selection:

0-20mA / 0-5V

4-20mA / 1-5V

0-1V

Whichever option is selected determines the configuration of all analog input channels. Channels 1 to 8 are configured

for current or voltage inputs via jumpers J35 to J42 respectively. If a jumper is installed in the appropriate location then

that channel will operate as a current input. If no jumper is installed, it will operate as a voltage input.

Whilst this

facility provides for a mix of current and voltage inputs signals it is recommended that all analog inputs be either

current or voltage for ease of ongoing serviceability and support.

FACTORY DEFAULTS - All channels set to 4-20mA

All input channels 0-20mA

All input channels 1-5V

All input channels 0-5V

All input channels 0-1V

OTHER OPTIONS

POWER SUPPLY MONITOR - Analog input channel 8 is set by factory default to monitor the module’s supply voltage.

This is particularly useful in solar powered installations. If channel 8 is required as a normal analog input channel then

J24 is moved from position A to position B.

VOLTAGE SOURCE FOR FIELD SENSORS - The analog input channel (8) can be configured as a 5V source to power

field sensors to a maximum current supply of 20mA. To select this option, install jumpers J16 to position B and J22 to

position A.

Page 7 of 11

Miri Technologies, 2 Fellowship Road, Gnangara, Western Australia 6077 | Tel: +61 89 409 8998 | www.miri.com.au

Analog Outputs (Optional)

An analog output board must be installed to utilise this option. This is a factory fitted option. When the analog output

option is installed, any of the last four channels can be configured as 4-20mA outputs.

ANALOG OUTPUTS –Channel 5-8 Configured as Outputs

Note: Ensure that the unit is powered down

when moving jumpers.

Channels 5 to 8 are selected as 4-20mA outputs by

way of locating jumpers in position A as follows:

Ch. 5 (J4)

Ch. 6 (J5)

Ch. 7 (J20)

Ch. 8 (J22 and J16)

Note: If channel 8 is configured as an analog output,

analog input 8 will still operate as a supply voltage

monitor, provided that J24 is selected in position A.

Page 8 of 11

Miri Technologies, 2 Fellowship Road, Gnangara, Western Australia 6077 | Tel: +61 89 409 8998 | www.miri.com.au

Communication Options

The standard radio option for an AD2006+ module is an on-board digital

Microhard Nano

radio.

This is installed on a ‘Nano’ interface board and is connected to the main PCB via CONN4. All options for the Nano

radios are selected in software. There are no hardware jumper settings required for this radio configuration.

The AD2006+ Rev.11 hardware platform also supports FFSK radio options which are interfaced to the main PCB via the

appropriate interface board. Where an FFSK radio is being used, it is necessary to configure the radio data options as

shown below. Your telemetry module will already be configured by the factory to the appropriate baud rate settings if

the required information has been given at the time of ordering.

Note: Only MR450+ and DTX+ interface boards can be used with the AD2006+ modules. These are not interchangeable

with previous radio interface boards.

FACTORY DEFAULTS –Internal FFSK radio –2400 baud

FFSK BAUD RATE OPTIONS –The jumper

arrangement shown is the factory default

configuration for an internal FFSK radio operating

at 2400 baud. Other baud rate options can be

selected using the following jumper configurations.

There is a PTT push button located under the

bottom right hand corner of the module which

operates in conjunction with FFSK radios. This is

intended to be used to check the SWR of antenna

installations during commissioning.

FACTORY DEFAULTS –External RS232 Radio Interface

FFSK EXTERNAL RADIO –The factory default is

for an external RS232 radio interface. To change

this for an external FFSK radio interface, shift J8,

J11 and J17 to the ‘B’ position.
