Mini Gadgets USBCAMDVR Manuel utilisateur

Updated 06/15/16 1 Version 1.0

HIDDEN CAMERA USB DRIVE

SKU: USBCAMDVR

THANK YOU FOR PURCHASING THE USBCAMDVR

Please read this manual before operating the USBCAMDVR and keep

it handy.

Looking for a multi-purpose covert camera? Well look no further, our

USBCAMDVR does it all! The USBCAMDVR serves several functions as

not only is it a covert camera perfect for use in any office or business

setting, but also functions as a webcam.

Your purchase should include:

1 x USBCAMDVR

1 x 16GB MicroSD Card

1 x Manual

1 x Keychain Connector

1 x USB Extension Cable

Updated 06/15/16 2 Version 1.0

GETTING TO KNOW YOUR USBCAMDVR

OPERATING THE USBCAMDVR

IMPORTANT NOTICE: Allow the device to charge 2-3 hours before

using.

HOW TO CHARGE USBCAMDVR

1. Ensure the device is off and plug the device into a USB port on

your computer

2. While charging, a blue light will flash near the base of the USB

connector

3. When charging is complete the blue light will stop blinking and

stay on.

HOW TO TURN ON USBCAMDVR

1. Press and hold the power button for 2-3 seconds until you get

a bright blue light.

2. The blue light will stay on and you are now in standby mode.

HOW TO RECORD VIDEO

1. Put the device into standby mode

2. Press and release the power button one time.

3. The blue light will start slowly blinking.

4. You are now recording video

5. To stop recording, press and release the power button one

more time. The blue light will become solid again and you

have saved your recording

NOTE: You may plug your device in to a USB port while it is

recording to extend the battery life. You MUST already be recording

prior to plugging in the device.

HOW TO TAKE A PICTURE

1. Put the device into standby mode

2. Quickly press and release the power button 2 times.

Updated 06/15/16 3 Version 1.0

3. The blue light will blink off and on once and a photo will be

taken.

HOW TO SET THE TIME AND DATE STAMP

1. Plug the device into your PC using the USB cable

2. Turn on the device

3. Locate “Removable Disk” inside the (My) Computer folder

Go to Start > Computer > Removable Disk

4. Open the Removable Disk drive

NOTE: if “time.txt” already exists you delete that file and

create a new one.

5. Right click with your mouse

6. Scroll down to “New”

7. Click “Text Document”

8. Rename “New Text Document” as “time”and press “enter”

on your keyboard

9. Open the text document

10. Enter the current date in YYYY-MM-DD format

11. Enter the current time in military format

Example:

2016-09-14 13:16:51.

12. Save the text document (file > save). The contents must be in

the exact format as the bolded text above. (no quotes or other

characters)

13. Unplug the device from your PC and power it on.

NOTE: After you set the date and time, the device will consume

the file that was just created and replace it with a default file. If

setting the time stamp worked, your video will still show the

correct date and time even though the default file has an

incorrect date and time.

RETRIEVE THE FILES TO YOUR PC

1. Ensure the device is powered off and then plug the device into

your PC using the USB cable

2. Locate “Removable Disk” inside the (My) Computer folder

AutoPlay Removable Disk > Open folder to view files

Or…

Go to Start > Computer > Removable Disk

Updated 06/15/16 4 Version 1.0

3. Open the Removable Disk drive

4. Open the folder containing the files

5. Double click the file you want to view

TROUBLESHOOTING

THE DEVICE WON’T TURN ON

Charge the device for at least 2-3 hours before the first use.

Make sure the charging cable is securely inserted into the

device and into the power source.

THE DEVICE ISN’T CHARGING

Use a different charging source or, if available, a different USB

cable.

MY COMPUTER DOESN’T RECOGNIZE THE DEVICE

Unplug the device from your PC and reboot the device.

Unplug the device from your PC and reboot your PC.

Try using a different USB slot on your PC.

Replace the USB cable.

OTHER PROBLEMS

Call our technical support at 770–694–6921

USING THE UNIT AS A WEBCAM

1. Plug the device in using the USB cable.

2. Power on the device by pressing the power button.

3. A driver will be automatically installed called GENERAL-UVC

4. Slide the units cover to the left or right to expose the camera.

5. The webcam will display the name as GENERAL –UVC

NOTE: Driver installation can take up to five minutes.

SPECIFICATIONS

Video Resolution

1280x960 @ 30fps

Video Format

AVI

Image Resolution

1600x11200

Image Format

JPG

Battery Life

45 Mins

Type of Memory

microSD Card

Memory Capacity

Up to 128GB (Above 64GB Requires Special

Formatting, visit this like: 64GB Formatting)

Recording Capacity

3GB ≈ 45 minutes

USB Interface

2.0 USB

Player Software

VLC recommended

Operating Systems

Windows XP & Up

Mac OSX 10.5 & Up

Linux
