Mini Gadgets SportCameraEX Manuel utilisateur

EXTREME SPORT CAMERA

WITH

WATER RESISTANT CASE

SKU: SportCameraEX

THANK YOU FOR PURCHASING THE EXTREME SPORT

CAMERA

Please read this manual before operating the Extreme Sport Camera

and keep it handy.

Starting out with 1080P HD recording resolution and featuring full

motion detection modes for video as well as adjustable recording

intervals and resolutions, this camera is certainly not lacking in

features. The Extreme Sports Cam records color video with audio and

has excellent low light recording for twilight excursions. The included

accessories also give you numerous options for mounting. The Extreme

Sports Cam supports up to 64GB MicroSD cards, can recharge while still

retaining its recording functions, works as a webcam, and even

supports HDMI out so you can immediately review your footage on

the big screen.

Your purchase should include:

1 x Extreme Sport Camera

1 x Micro USB Cable

1 x AC Adapter

1 x Car Charger

1 x Velcro Strap

1 x Belt Clip Mount

1 x L-mount

1 x Bar Mount

1 x Stand Clip Mount with Adhesive Tape

1 x Car Window Mount

1 x Tool and Screw Packet

1 x Cleaning Cloth

1 x Instruction Booklet

GET FAMILIAR WITH YOUR EXTREME SPORT CAMERA

OPERATING THE EXTREME SPORT CAMERA

IMPORTANT NOTICE: Allow the device to charge 4 –6 hours before

using.

HOW TO INSTALL THE BATTERY

1. Push the battery cover down to open.

2. Correctly install the battery into the camera based on the

positive and negative symbols and the direction of the arrow

marked on the battery.

HOW TO CHARGE THE BATTERY

You can charge the Extreme Sport Cam by connecting it to

your PC.

You can charge the Extreme Sport Cam by connecting it to a

power adapter.

You can charge the Extreme Sport Cam in your car with a car

charger.

The Extreme Sport Cam can record while charging.

The Extreme Sport Cam can charge even when turned off.

HOW TO TURN THE CAMERA ON AND OFF

Press and hold the power switch for one second to turn the

camera on or off.

HOW TO SWITCH MODES

Press the mode button to switch between video recording and

photo shooting mode.

indicates recording mode

HOW TO SET UP SYSTEM SETTINGS

Press the menu button once, and press it again to enter

“System Settings” interface, which has a blue background.

Button

Status

Preview of

Video Recording

Power

Press and Hold: Switch on

Press: Switch voice record

Up / Down

Zoom In / Out

Menu / OK

Menu / Start video record

Mode

Switch to photography

Recording

Power

Press and Hold: Switch on

Press: Switch voice record

Up / Down

Zoom In / Out

Menu / OK

Null / Stop video record

Mode

Mandatory lock

Photo Shooting

Power

Press and Hold: Switch on

Press: Switch voice record

Up / Down

Zoom In / Out

Menu / OK

Menu / Confirm action

Mode

Switch to replay mode

Replay Preview

Power

Press and Hold: Switch on

Press: Switch voice record

Up / Down

Previous file / Next file

Menu / OK

Menu / Start replaying

Mode

Switch to video recording

Replaying

Power

Press and Hold: Switch on

Press: Switch voice record

Up / Down

Fast-forward / Rewind

Menu / OK

Null / Start replaying

Mode

Stop

Pause while Replay

Power

Press and Hold: Switch on

Press: Switch voice record

Up / Down

Null / Null

Menu / OK

Null / Resume playing

Mode

Stop

Exposure Compensation

-1/3 -2/3 -1.0

-4/3 -5/3 -2.0

+0.0

-1/3 +2/3 +1.0

+4/3 +5/3 +2.0

Resolution

1080P 1920*180

720P 1280*720

WVGA 848*480

VGA 640*480

Setup

Date / Time

Photo Shooting

Res: 12M / 8M / 5M

Self-Timer: 2s / 5s / 10s

Continuous

Screen Saver Setting

Formatting

Restore Default Settings

Version

Playback

Delete

Protection

Loop Video Recording

Power-off

3 minutes

5 minutes

10 minutes

Wide Dynamic HDR

Off

Language Setting

English

French

Mandarin

Cantonese

Japanese

Portuguese

Russian

Korean

Auto Power-off

Power-off

3 minutes

5 minutes

10 minutes

Gravity Sensor

Power-off

Frequency of Optical Source

50Hz

60Hz

Motion Detection

Off

Video Audio

Off

Date Tag

Off

HOW TO RECORD VIDEO

1. Switch to recording mode.

There will be a video camera icon in the upper left

corner of the screen.

2. Press OK to start recording.

The red recording dot will flash.

3. Press OK again to stop.

The video camera icon will appear again.

HOW TO TAKE PHOTOGRAPHS

1. Switch to photography mode.

There will be a photo camera icon in the upper left

corner of the screen.

2. Press OK to take photographs.

3. Press the Menu button to enter photo settings.

Shooting Mode: Single shot / Self-timer / Continuous

RETRIEVE THE FILES TO YOUR PC

1. Plug the device into your PC using the USB cable.

2. Select “Mass Storage” on the screen and press OK.

3. Locate “Removable Disk” inside the (My) Computer folder.

AutoPlay Removable Disk > Open folder to view files

Or…

Go to Start > Computer > Removable Disk

4. Open the Removable Disk drive.

5. Open the DCIM folder.

6. Double click the file you want to view.

VLC Player is recommended for watching videos

TROUBLESHOOTING

THE DEVICE WON’T TURN ON

Charge the device for at least 4 hours before the first use.

Make sure the charging cable is securely inserted into the

device and into the power source.

THE DEVICE ISN’T CHARGING

Replace the battery or charging cable.

If you are charging via a wall power source, you may need to

charge via your PC. The AC adapter might not be working.

THE DEVICE HAS CRASHED

You need to reset the device.

oTake the battery out and put it back in.

MY COMPUTER DOESN’T RECOGNIZE THE DEVICE

Unplug the device from your PC and reboot the device.

Unplug the device from your PC and reboot your PC.

Try using a different USB slot on your PC.

Replace the USB cable.

THE SOUND OR VIDEO IS UNCLEAR

The device needs charging.

OTHER PROBLEMS

Call our technical support at 770–694–6921

SPECIFICATIONS

Video Resolution

1920 x 1080

1080 x 720

848 x 480

640 x 480

Video Format

MOV

Frames per Second

30fps

Vision Angle

12-megapixel HD Wide

Motion Detection

Yes

Photo Resolution

12M, 8M, 5M

Photo Format

JPEG

Water Resistant

Only with case

Battery Life

90 minutes @ 1080P

150 minutes @ 640P

Type of Memory

External MicroSD Card

Memory Capacity

64GB

Memory Consumption

~4GB every 35 minutes @ 1080P

~554MB every 10 minutes @ 640P

Recording Capacity

110 minutes @ 1080P

150 minutes @ 640P

USB Interface

2.0 USB

Player Software

VLC recommended

Operating Systems

Windows 2000

Windows Me

Windows XP

Windows Vista

Windows 7

Mac OSX

Linux
