MIMAKI JFX500-2131 Guide de référence

UV INKJET PRINTER

UV FAN Filter 交換手順書

Procedure Manual to replace UV FAN Filter

株式会社ミマキエンジニアリング

MIMAKI ENGINEERING CO., LTD.

D902454-11

12

© 2014 MIMAKI ENGINEERING CO., LTD.All Rights Reserved. D902454-11

・Refer to the JFX500-2131’s Operation Manual for information about precautions and safety.

・Be sure to read and understand “Warning for Use” and “Precaution for Use” in this manual before using the device.

・Read the main unit Operation Manual for details about the operating method.

・This Operation manual has been carefully prepared for your easy understanding.

・Descriptions contained in this Operation manual are subject to change without notice for improvement.

・Make sure to always wear protective gloves and goggles during the operations.

Ink or dirt of filter may come in contact with your skin by scattering ink or dirt of filter.

Before Use

Before Use

Precaution for Use

Safety Precautions

Requests

12

© 2014 MIMAKI ENGINEERING CO., LTD.All Rights Reserved. D902454-11

UV FAN Filter will be getting dirt.

Replace the filter periodically when it is dirt.

Depending on the environments and printing conditions, the filter condition is different.

Check the filter condition when cleaning every day.

・Replace the filter periodically when it is dirt.

When the following error is shown, replace the filter.

・If the printer is working, replace the filter after the job is completed.

・Even though the following error is shown, the machine is not stop immediately.

We recommended the genuine products for the replacement filter for UV FAN.

It may not to obtain the filtering effect sufficiently if you do not use the genuine products.

・Record the UV unit position before the operation.

・Move the UV Unit to the front.

・Please follow the next page to replace the filter.

・Reposition the UV Unit in place.

UV FAN Filter replacement estimated time

１

2

ERROR 706

UV LAMP TEMP HIGH

Preparations

1

2

3

4

12

© 2014 MIMAKI ENGINEERING CO., LTD.All Rights Reserved. D902454-11

Required tools Filter for replacement or ・Protective goggles

UV FAN replacement Filter KIT（SPA-0256) ・Protective gloves

How to remove the filterAssy

This procedure is shown for only right side unit. Please operate it as well as left side.

Unscrew the screws which are fixed the filter cover.

Remove the filter cover.

Pull up the projection of filterAssy.

How to replace the filter

1

2

3

12

© 2014 MIMAKI ENGINEERING CO., LTD. All Rights Reserved. D902454-11

How to replace the filter

Please follow the procedure to replace the filter.

・Unscrew the pinch screw.

・Remove the cover.

・Remove the dirty filter.

・Set the new filter on the base.

Make sure that the filter butt to the end of filter base

that is like the red arrow in the right drawing.

・Attach the cover .

Make sure to insert the projections to the notch hole

ofthefilterbase.

・Fix the cover using pinch screw.

1

2

Cover

3

4

5

6

Filter Base

12

© 2014 MIMAKI ENGINEERING CO., LTD. All Rights Reserved. D902454-11

How to attach the filterAssy

・Insert the filterAssy from the open part of outer cover.

Insert the filter Assy to the projection of receiver.

Make sure to insert it to the bottom softly and firmly.

・Attach the filter cover.

・Fix the filter cover using pinch screw.

1

2

3
