MikroTik RouterBOARD 750 Manuel utilisateur

RouterBOARD 750

Quick Setup Guide and Warranty Information

First use

1. Connect your WAN cable to port 1, and LAN computers to ports 2-5

2. Set LAN computer IP conf gurat on to automat c (DHCP)

3. RB750 Default IP address from LAN s 192.168.88.1 or http://router

Powering

The board accepts power ng from the power jack or from the f rst ethernet port (Pass ve PoE):

●d rect- nput power jack (5.5mm outs de and 2mm ns de d ameter, female, p n pos t ve plug) accepts 8..28V DC

●f rst ethernet port accepts pass ve Power over Ethernet accepts 8-28V DC

Normally the power consumpt on of th s dev ce s 2.4W, under max mum load - 3.6W

Booting process

Th s dev ce doesn't come f tted w th a Ser al Port connector, so n t al connect on has to be done v a the Ethernet cable, us ng

the M kroT k W nbox ut l ty. W nbox should be used to connect to the default IP address of 192.168.88.1 w th the username

admin and no password.

In case IP connect on s not ava lable, W nbox can also be used to connect to the MAC address of the dev ce. More

nformat on here:

http: wiki.mikrotik.com wiki First_time_startup

In case you w sh to boot the dev ce from network, for example to use M kroT k Net nstall, hold the RESET button of the

dev ce when start ng t unt l the LED l ght turns off, and RB750 w ll start to look for Net nstall servers.

Extension Slots and Ports

●F ve nd v dual Ethernet ports, support ng automat c cross/stra ght cable correct on (Auto MDI/X), so you can use

e ther stra ght or cross-over cables for connect ng to other network dev ces. The Ethernet port accepts 8..28 V DC

power ng from a pass ve PoE njector.

Buttons and Jumpers

●ROS reset jumper hole (on the bottom of case, beh nd one of the rubber feet) – resets RouterOS software to

defaults. Must short c rcu t the metall c s des of the hole (w th a screwdr ver, for example) and boot the dev ce. Hold

screwdr ver n place unt l RouterOS conf gurat on s cleared.

●RouterBOOT reset button (RESET, front panel) has two funct ons:

●Hold th s button dur ng boot t me unt l LED l ght starts flash ng,

release the button to reset Router S configuration (same result as w th reset hole)

●Hold th s button dur ng boot t me longer, unt l LED turns off,

then release t to make RB750 look for Netinstall servers.

See www.routerboard.com for more nformat on. Contact support@m krot k.com for support quest ons. rev. A (6-Jul-2009)

perating System Support

Currently tested operat ng system s M kroT k RouterOS (start ng from vers on 3.26).

part of t may be reproduced or transm tted n any form w thout pr or wr tten perm ss on from the copyr ght holder.

RouterBOARD, RouterOS, RouterBOOT and M kroT k are trademarks of M kroT kls SIA. All trademarks and reg stered

trademarks appear ng n th s manual are the property of the r respect ve holders.

Hardware. M kroT kls SIA warrants all RouterBOARD ser es equ pment for the term of one year from the sh pp ng date to be

free of defects n mater als and workmansh p under normal use and serv ce, except n case of damage caused by

mechan cal, electr cal or other acc dental or ntended damages caused by mproper use or due to w nd, ra n, f re or other

acts of nature.

If you have purchased your product from a M kroT k Reseller, please contact the Reseller company regard ng all warranty

and repa r ssues, the follow ng nstruct ons apply NLY f you purchased your equ pment d rectly from M kroT k Latv a

To return fa led un t or un ts to M kroT kls you must perform the follow ng RMA (Return Mater al Author zat on) procedure.

Follow the nstruct ons below to save t me, efforts, avo d costs, and mprove the speed of the RMA process. Take nto

account that all goods have one year warranty.

Instruct ons are located on our webpage here: http://rma.mikrotik.com

Manual. Th s manual s prov ded “as s” w thout a warranty of any k nd, expressed or mpl ed, nclud ng, but not l m ted to,

the mpl ed warranty of merchantab l ty and f tness for a part cular purpose. The manufacturer has made every effort to

ensure the accuracy of the contents of th s manual, however, t s poss ble that t may conta n techn cal naccurac es,

typograph cal or other errors. No l ab l ty s assumed for any naccuracy found n th s publ cat on, nor for d rect or nd rect,

nc dental, consequent al or other damages that may result from such an naccuracy, nclud ng, but not l m ted to, loss of

data or prof ts. Please report any naccurac es found to support@m krot k.com

See www.routerboard.com for more nformat on. Contact support@m krot k.com for support quest ons. rev. A (6-Jul-2009)
