MikroElektronika Click ccRF Manuel utilisateur

1. Introduction

Once you have soldered the headers your

board is ready to be placed into desired

mikroBUS™socket. Make sure to align the

cut in the lower-right part of the board

with the markings on the silkscreen at

the mikroBUS™socket. If all of the pins are

aligned correctly, push the board all

the way into the socket.

3. Plugging the board in

2 3

2. Soldering the headers

4. Essential features

Turn the board upward again. Make sure

to align the headers so that they are

perpendicular to the board, then solder the

pins carefully.

Turn the board upside down so that

bottom side is facing you upwards.

Place shorter pins of the header into the

appropriate soldering pads.

Before using your click™board, make sure

to solder 1x8 male headers to both left

and right side of the board. Two 1x8 male

headers are included with the board in

the package.

click

BOARD

www.mikroe.com

ccRF click Manual

ver. 1.01

0 100000 023952

ccRF click™is an accessory board in

mikroBUS™form factor. It’s a compact and

easy solution for adding RF transceiver to

your design. It features CC2500 Low-Power

2.4 GHz RF transceiver as well as PCB

trace antenna. ccRF click™communicates

with the target board microcontroller via

mikroBUS™ SPI (MOSI, MISO, SCK, CS), RST

and PWM lines. The board is designed to

use 3.3V power supply only. LED diode

(GREEN) indicates the presence of power

supply.

ccRF click

ccRF click™with it’s CC2500 IC is a low-power

2.4 GHz transceiver designed for the 2400-

2483.5 MHz ISM and SRD frequency band.

The CC2500 is integrated with a highly

congurable baseband modem that supports

various modulation formats and has data rate

up to 500 kBaud. All these features make

this board ideal for consumer electronics,

wireless audio, wireless keyboard and mouse

RF remote controls and many more.

8. Support

MikroElektronika oers Free Tech Support

(www.mikroe.com/esupport) until the end

of product lifetime, so if something goes

wrong, we are ready and willing to help!

7. Code Examples

.com

Once you have done all the necessary

preparations, it’s time to get your click™

board up and running. We have provided

the examples for mikroC™, mikroBasic™and

mikroPascal™compilers on our Libstock

website. Just download them and you are

ready to start.

VCC3.3

2K2

LD1

RST

SCK

MOSI

MISO

+3.3V

GND

PWM

INT

SCL

SDA

+5V

GND

VCC3.3

IFA_2.4GHz

RF-SO

RF-SCLK

RF-SI

RF-CS#

RF-GDO0

C15

22pF

C16

22pF

R4 1M

26MHz

C1 100pF

C3 100pF

1pF

1.2nH

L2 1.2nH

C2 1pF

L1 1.2nH

1.8pF

1.5pF

VCC-RF R1 56K

RF-SI

RF-CS#

RF-GDO0

RF-OSC1

RF-OSC2

100nF

R3 10K

CC2500

DVDD

GDO2

SCLK

GDO0

CSn

XOSC1

AVDD

RF_P

RF_N

AVDD

RBIAS

DGRD

GND

DCPL

XOSC2

AVDD

GND

RF-SO

RF-SCLK

RF-GDO2

C11

220pF

100nF

C10

100nF

VCC3.3

FP1

C12

220pF

C13

100nF

VCC-RF

10uF

C14

100nF

ANT

MikroElektronika assumes no responsibility or liability for any errors or inaccuracies that may appear in the present document.

6. PCB Trace Antenna

5. ccRF click™Board Schematic

Board features PCB trace antenna, designed

for the 2400-2483.5 MHz frequency band.

Maximum device range is up to 20 meters in

open space.

Mouser Electronics

Authorized Distributor
