1. Introduction

Once you have soldered the headers your

board is ready to be placed into desired

mikroBUS™ socket. Make sure to align the

cut in the lower-right part of the board with

the markings on the silkscreen at the

mikroBUS™ socket. If all of the pins

are aligned correctly, push the

board all the way into the socket.

3. Plugging the board in

2 3

2. Soldering the headers

4. Essential features

Turn the board upward again. Make sure

to align the headers so that they are

perpendicular to the board, then solder the

pins carefully.

Turn the board upside down so that

bottom side is facing you upwards. Place

shorter parts of the header pins in both

soldering pad locations.

Accel click

Before using your click board™, make sure

to solder 1x8 male headers to both left

and right side of the board. Two 1x8 male

headers are included with the board in

the package.

click

BOARD

www.mikroe.com

Accel click Manual

ver. 1.00

0 100000 020968

Accel Click™ with it’s ADXL345 module

supports several sensing functions such as

single/double tap detection, activity/inactivity

monitoring, free-fall detection etc. It has

memory management system with a 32-level

FIFO buer to store data with minimized host

processor activity. All these features make

this board ideal for mobile devices, medical

and industrial instrumentation, navigation

devices, hard drive protection and more.

Accel Click™ is an accessory board in

mikroBUS™ form factor. It’s a compact

and easy solution for adding accelerometer

functionality to your device. It features

ADXL345 3-axis accelerometer module with

ultra-low power and high resolution (13-bit)

measurement. Accel Click™ communicates

with target board via I2C or SPI interface. The

Board is designed to use 3.3V power supply

only. It has a LED diode (GREEN) which

indicates the presence of power supply.

8. Support

MikroElektronika oers Free Tech Support

(www.mikroe.com/esupport) until the

end of product lifetime, so if something goes

wrong, we are ready and willing to help!

7. Code Examples

.com

Once you have done all the necessary

preparations, it’s time to get your click

board™ up and running. We have provided

the examples for mikroC, mikroBasic and

mikroPascal compilers on our Libstock

website. Just download them and you are

ready to start.

5. Accel Click™ Board Schematic

RST

SCK

MOSI

MISO

+3.3V

GND

PWM

INT

SCL

SDA

+5V

GND

MIKROBUS DEVICE CONN.

VCC

GND

Res

GND

VCC

INT1

INT2

Res

ADD

SDA

SCL

ADXL345

VCC-3.3VCC-3.3

10K

SCK

SDO

SDI

SCL

SDA

SDI/SDA

SDO/ADD

INT

SCK/SCL

VCC-3.3

2K2

LD1

SDI/SDA

SDO/ADD

10K

VCC-3.3

SCK

SCL

SPI

I2C

SDI

SDO

SDA

VCC-3.3

100nF

VCC-3.3

100nF

SCK/SCL

R4 220

INT

VCC-3.3

R5100K

MikroElektronika assumes no responsibility or liability for any errors or inaccuracies that may appear in the present document.

6. SMD Jumpers

The Accel Click™ board communicates

with the main board via I2C or SPI interface

depending on the position of the J1, J2 and J3

SMD jumpers. These jumpers are soldered in

I2C interface position by default. There is an

option to select the alternate address with

jumper J4 in the case of I2C interface (default

position is logic 1).
