Operating and Installation

Instructions

Downdraft Ventilation System

DA 6480, DA 6490

DAG 500, DAG 1000

To prevent accidents

and appliance damage,

read these instructions

before

installation or use. M.-Nr. 09 045 140

en - US, CA

IMPORTANT SAFETY INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Functional description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Description of the appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Raising the vent / Turning on the fan ...................................10

Selecting the power level............................................10

Delayed shut-off feature ¢15 ........................................10

Temperature warning §............................................11

Cleaning and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Grease filters .....................................................13

After Sales Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Installation instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Caring for the environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Appliance dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Installation with the DAG 1000 external blower ...........................34

Air extraction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Electrical connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Contents

READ AND SAVE THESE

INSTRUCTIONS

Keep these operating instructions in

a safe place and pass them on to any

future user.

Read these Instructions carefully

before installing or using the

Ventilation System.

~This appliance is intended for

residential use only. Use the appliance

only for its intended purpose.

~This appliance complies with current

safety requirements. Improper use of

the appliance can lead to personal

injury and material damage.

,CAUTION

For General Ventilating Use

Only. Do Not Use To Exhaust

Hazardous Or Explosive

Materials And Vapors.

~This appliance is designed to vent

cooking smoke and odors only.

~This appliance is suitable for

installation beside gas or electric

cooking surfaces.

~This appliance is not intended for

outdoor use.

~This appliance must not be used in

a non-stationary location (e.g. on a

ship).

,WARNING

TO REDUCE THE RISK OF

FIRE, ELECTRIC SHOCK, OR

INJURY TO PERSONS,

OBSERVE THE FOLLOWING:

~a) Use this appliance only in the

manner intended by the manufacturer.

If you have questions, contact Miele.

~b) Before servicing or cleaning the

appliance, switch power off at the

service panel and lock the service

disconnecting means to prevent power

from being switched on accidentally. If

the service disconnecting means

cannot be locked, securely fasten a

prominent warning device, such as a

tag, to the service panel.

~c) Be certain your appliance is

properly installed and grounded by a

qualified technician.

To guarantee the electrical safety of this

appliance, continuity must exist

between the appliance and an effective

grounding system. It is imperative that

this basic safety requirement be met. If

there is any doubt, have the electrical

system of the house checked by a

qualified electrician.

IMPORTANT SAFETY INSTRUCTIONS

~d) Before connecting the appliance

to the power supply make sure that the

voltage and frequency listed on the

data plate correspond with the

household electrical supply.

This data must correspond to prevent

appliance damage. If in doubt consult a

qualified electrician.

~e) Installation work and repairs

should only be performed by a qualified

technician in accordance with all

applicable codes and standards.

Repairs and other work by unqualified

persons could be dangerous.

~f) Only open the housing as

described in the "Cleaning and care"

section of this manual. Under no

circumstances should any other parts

of the housing be opened. Tampering

with electrical connections or

components and mechanical parts is

highly dangerous to the user and can

cause operational faults.

~g) Before discarding an old

appliance, disconnect it from the power

supply and remove the power cord.

Use

,WARNING

TO REDUCE THE RISK OF A

COOKTOP GREASE FIRE:

~a) Never leave surface units

unattended at high settings. Boilovers

cause smoking and greasy spillovers

may ignite. Heat oils slowly on low or

medium settings.

~b) Always turn the ventilation system

on when cooking at a high heat.

~c) Clean the ventilation system

frequently. Grease should not be

allowed to accumulate on the fan or

filter.

~d) Use the proper pan size. Always

use cookware appropriate for the size

of the cooking area.

~e) Do not flambé or grill with an

open flame beside the ventilation

system.

Flames could be drawn into the

ventilation system by the suction and

the grease filters may catch fire.

IMPORTANT SAFETY INSTRUCTIONS

,WARNING

TO REDUCE THE RISK OF

INJURY TO PERSONS IN THE

EVENT OF A COOKTOP

GREASE FIRE, OBSERVE THE

FOLLOWING*:

~a) SMOTHER FLAMES with a close

fitting lid, cookie sheet, or metal tray

then turn off the burner.

BE CAREFUL TO PREVENT BURNS.

If the flames do not go out immediately,

EVACUATE AND CALL THE FIRE

DEPARTMENT.

~b) NEVER PICK UP A FLAMING

PAN - You may be burned.

~c) DO NOT USE WATER, including

wet dishcloths or towels - a violent

steam explosion will result.

~d) Use a fire extinguisher ONLY if:

1) You have a class ABC

extinguisher, and you know how to

operate it.

2) The fire is small and contained in

the area where it started.

3) The fire department has been

called.

4)You can fight the fire with your

back to an exit.

*Based on "Kitchen Firesafety Tips"

published by NAFTA

~Do not allow children to play with or

operate the appliance or its controls.

Supervise its use by the elderly or

infirm.

~Never operate gas burners without

cookware. Turn the burner off when not

in use. Adjust the burner so that the

flames do not extend beyond the

cookware. Do not overheat the

cookware, e.g. when using a wok. The

ventilation system can be damaged

due to excessive heat from the burners

and the cookware.

~Do not use the ventilation system

without the grease filters in place.

~Do not use a steam cleaner to clean

the ventilation system. Steam could

penetrate electrical components and

cause a short circuit.

IMPORTANT SAFETY INSTRUCTIONS

Installation

,WARNING

TO REDUCE THE RISK OF

FIRE, ELECTRIC SHOCK, OR

INJURY TO PERSONS,

OBSERVE THE FOLLOWING:

~a) Installation work and electrical

wiring must be done by qualified

persons in accordance with all

applicable codes and standards,

including fire-rated construction.

~b) Sufficient air is needed for

combustion and exhausting of gases

through the flue. Follow all equipment

manufacturer’s guideline and safety

standards such as those published by

the National Fire Protection Association

(NFPA) and the American Society for

Heating, Refrigeration and Air

Conditioning Engineers (ASHRAE), and

the local code authorities.

~c) When cutting or drilling into the

wall or ceiling, do not damage electrical

wiring and/or other hidden utilities.

~d) Ducted ventilation systems must

always be vented to the outdoors.

~e) Do not use this ventilation system

with any solid-state speed control

device.

~f) Do not use an extension cord to

connect the appliance to electricity.

Extension cords do not guarantee the

required safety of the appliance,

(e.g. danger of overheating).

~g) Do not install this ventilation

system beside cooktops that burn solid

fuel.

~h) Provided a larger distance is not

given by the manufacturer of the

cooktop, follow the minimum safety

distances between a cooktop and the

ventilation system given in the

"Appliance dimensions" section of this

manual.

If local building codes require a greater

safety distance, follow their

requirement.

~i) Never connect a ventilation

system to an active chimney, dryer

vent, vent flue, or room ventilating

ductwork.

~j) Seek professional advice before

connecting an exhaust vent to an

existing, inactive chimney or vent flue.

~k) Any fittings, sealant, or materials

used to install the ductwork must be

made of approved non-flammable

materials.

,WARNING

TO REDUCE THE RISK OF

FIRE USE ONLY METAL

DUCTWORK.

IMPORTANT SAFETY INSTRUCTIONS

The ventilation system offers two installation options:

with the internal DAG 500

exhaust blower

(not included)

The air is drawn through and cleaned

by the grease filters and then directed

outside.

with the DAG 1000 external

blower

(not included)

The air is drawn through and cleaned

by the grease filters and then directed

outside.

The external blower is designed to be

installed in a different location than the

ventilation system.

The external blower is connected to the

ventilation system by a control cable,

and exhaust ductwork and is operated

via the ventilation system's control

panel.

Functional description

Description of the appliance

aOn/Off button for the retractable

vent and fan

bControl panel

cRetractable vent

dGrease filter

eExhaust blower DAG 500

(not included)

The exhaust blower can also be

installed behind the appliance.

fVent collar

The vent collar can be installed so that

the exhaust vents to either side,

downwards, or to the rear.

gTemperature warning light

The warning light will flash if the

temperature of the vent exceeds 113 °F

(45°C).

hPower level settings

The button 0/1 can also be used to turn

off the fan without retracting the vent.

iDelayed shut down feature

When pressed, the power will be

reduced to level 1 and the fan will

automatically shut down after

15 minutes.

Description of the appliance

Raising the vent / Turning on

the fan

^Press the On/Off button on the top of

the ventilation system.

The vent will rise.

The fan will start at power level 2.

The fan will automatically turn off if it

is blocked while rising or retracting.

When the obstruction is removed, press

the On/Off button on the top of the

appliance to restart it.

Selecting the power level

^Use buttons 1to 4to select the

desired power level.

Typically, levels 1to 3are sufficient for

regular cooking needs.

Intensive level

^To remove intensive vapors or odors,

such as when pan-frying, select

power level 4.

Delayed shut-off feature ¢15

We recommend that you let the fan run

for several minutes after you have

finished cooking.

This will help remove any remaining

vapors or odors from the kitchen.

The Delayed shut down feature lets you

set the fan to shut off automatically after

15 minutes.

^With the fan on press the Delayed

shut down button ¢15.

The fan will turn off in 15 minutes.

The vent will remain up.

^To lower the vent, press the On/Off

button on the top of the appliance.

Turning the fan off / Lowering

the vent

^Press the On/Off button on the top of

the appliance.

The fan turns off.

The vent retracts.

^If you wish to turn off the fan but

leave the vent up for cleaning, press

and hold the 0/1 button until the fan

turns off.

^To turn the fan back on, press the 0/1

button again.

Operation

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Miele hotte de ventilation

Miele

Miele DA 6296 W EXT Manuel utilisateur

Miele

Miele DA 5960 W Manuel utilisateur

Miele

Miele DA 6881 Manuel utilisateur

Miele

Miele DA 424 V EXT Manuel utilisateur

Miele

Miele DA 216-2 EXT Manuel utilisateur

Miele

Miele DAW 1620 Active Manuel utilisateur

Miele

Miele DA 3060 Manuel utilisateur

Miele

Miele DA5190 Manuel de la liste des pièces

Miele

Miele DA250-4 Instructions d'utilisation

Miele

Miele DA 3466 Manuel utilisateur

Miele

Miele DAR 1120 Manuel utilisateur

Miele

Miele DA 2270 Fiche technique

Miele

Miele DA 5428 W Manuel utilisateur

Miele

Miele DA 5196 W EXT Manuel utilisateur

Miele

Miele DA 2360 Manuel utilisateur

Miele

Miele DA2578 Manuel utilisateur

Miele

Miele DA 211 Instructions d'utilisation

Miele

Miele DA 3190 Guide de l'utilisateur

Miele

Miele DA 422-4 Fiche technique

Miele

Miele DA 5391 W Manuel de la liste des pièces

Miele

Miele DA 289 Manuel de la liste des pièces

Miele

Miele DAS 4930 Manuel utilisateur

Miele

Miele DA 2450 Manuel utilisateur

Miele

Miele DA 6996 W Instructions de montage

Manuels hotte de ventilation populaires d'autres marques

emmeti

emmeti RECUPA MED A-140 Mode d’emploi

Nibe

Nibe F135 Manuel utilisateur

Kuppersberg

Kuppersberg INTRO 60 Instructions d'installation et d'entretien

Zephyr

Zephyr Spruce AK9834BS Guide d'installation

Hisense

Hisense MH6INBG Manuel utilisateur

Broan

Broan 46000 Manuel utilisateur

GE Profile PV977 Instructions originales

FALMEC

FALMEC FFRIA24W5FS Manuel utilisateur

Whirlpool

Whirlpool RH2600XL-1 SERIES Manuel utilisateur

Küppersbusch

Küppersbusch DX ISLA Manuel utilisateur

ETNA

ETNA AV360RVS Manuel utilisateur

JUNO

JUNO JDF603E6 Manuel utilisateur

Tricity Bendix

Tricity Bendix LE 150 Manuel

AEG

AEG X68163BV1 Manuel utilisateur

AEG

AEG 125 D Manuel utilisateur

Smeg

Smeg KSEV97X Manuel utilisateur

Nibe

Nibe S Series Guide de l'utilisateur

Caple

Caple CCH100 Manuel
