OWNER’S MANUAL
AIR COOLER
AC100-18BR
READ AND SAVE THESE INSTRUCTIONS
Attention: Pictures in the IM are for reference only.
1. If the supply cord is damaged, it must be replaced by manufacturer,its
service agent or a similarly qualified person in order to avoid a
hazard.
2.
This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children without supervision.
3.
Unplug the appliance during filling and cleaning.
4.
Prior to cleaning or other maintenance, the appliance must be
disconnected from the supply mains.
5.
Correct Disposal of this product
This marking indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent possible harm to
the environment or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable reuse of material
resources. To return your used device, please use the return and
collection systems or contact the retailer where the product was
purchased. They can take this product for environmental safe recycling.
SAFETY INSTRUCTION
1
Front Foot-wheel
Rear Foot-wheel
Foot-Wheel Installation
INSTALLATION INSTRUCTIONS
Name of components
Honeycomb
Filter
Universal
Wheel
Water tank
Ice Box
Water tank
cover
Control panel
2
Press a key on the unit to activate a corresponding function.
For instance:
● Press [ ] Key to adjust 3 speeds of air flow.
● Press [ ] Key to switch between Natural and Sleep Functions.
● Press [ ] Key：When the fan is on, press the“PRO./TIMER”
key to time the fan to shut down after 1-7 hours. In stand-by mode, you
can pre-set the fan to start in 1-7 hours.
● When [ ] Key is pressed, the indicator lights up constantly
if the operation is normal; when the indicator flashes, it denotes a water
shortage, please add water immediately.
Considerate Hint:
Push Buttons on the unit may differ based on the actual product model.
Instructions for operation of body
3
Considerate Hint:
When humidifying, water level in the Water Tank must remain under MAX
indication; replenish water if level gets lower than MIN indication.
Using the Ice Box
Water + Ice
Water Level
Using the Water tank
4
Warm tips:
1. The positive pole shall be faced upward when installing the battery.
2. The remote controller shall be in 5m in the front of the product, and
normally used in the range of deviation angle for 30 degrees.
Instructions for key of remote controller
INSTRUCTIONS FOR USE
Battery installation
WIND TYPE Key
ON/OFF Key
TIMER Key
SPEED Key
SWING Key HUMIDIFYER/
COLD WIND Key
Locking
latch
Pull Notch
CR2032
Battery, 3v
It uses one button battery of type "CR2032".
5
The fan requires little maintenance. Do not try to fix it by yourself.
Refer it to qualified service personnel if service is needed.
1. Before cleaning and assembling, fan must be unplugged.
2. To ensure sufficient air supply, the honeycomb filter and dust filter
shall be cleaned regularly.
3. Please wipe the exterior parts with a soft cloth soaking a mild
detergent.
4. Do not use any abrasive detergent or solvents to avoid scratching the
surface.
Do not use any of the following as a cleaner: gasoline, thinner.
5. Do not allow water or any other liquid into the motor housing or
interior parts.
1. Be sure to unplug from the electrical supply source before cleaning.
2. Plastic parts should be cleaned with a soft cloth moisten with mild
soap. Thoroughly remove soap film with dry cloth.
MAINTENANCE INSTRUCTION
CLEANING
6
