ObjectScan 1600

Object Scanner

User's Manual

2 ObjectScan 1600 User's Manual

Preface

be reproduced or copied in any way, stored electronically, or translated into any

language, without the permission of Microtek International, Inc.

Trademarks

Microtek, ScanMaker, ArtixScan, ScanWizard and ColoRescue are trademarks

or registered trademarks of Microtek International, Inc. All other trademarks or

registered trademarks are the property of their respective holders. Specications,

software and hardware bundles are subject to change without notice. Not

responsible for typographical errors.

Disclaimer

The contents of this manual have been checked carefully for accuracy, and every

effort has been made to ensure that there are no errors. However, Microtek

makes no guarantee as to the accuracy of the contents of this document and

reserves the right to make changes to the contents without prior warning.

I49-005160 C

November 2017

Microtek International, Inc.

No. 6, Industry East Road 3, Science Based Industrial Park, Hsinchu, 30075, Taiwan

Tel: 886-3-5772155, Fax: 886-3-5772598, http://www.microtek.com

ObjectScan 1600 User's Manual 3

FCC Compliance Statement

This equipment (Model: MRS-1600A3OS) has been tested and found to comply

with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules.

These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and used in accordance

with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or more of

the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

NOTE: A shielded Hi-Speed USB interface cable with ferrite core installed on the

scanner connector end must be used with this equipment.

Caution: Changes or modications not expressly approved by the manufacturer

responsible for compliance could void the user's authority to operate the

equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference,

and (2) this device must accept any interference received, including interference

that may cause undesired operation.

4 ObjectScan 1600 User's Manual

Safety Precautions

Before using your scanner, read the following safety guides carefully, which

detail the proper operation of the scanner and its accessories to prevent injuries

or damage to users or equipment.

Meanings of Symbol Signs

This indicates hazardous situation which, if not paid

attention, could result injury or damage to users or

equipment.

This indicates hazardous situation which, if not paid

attention, could result serious injury or death to users.

Power Supply:

• Use a power source only with a power rating specied on the marking label.

• Ensure to turn off the power of each device before connecting or

disconnecting the cables.

• Insert the plug completely into the outlet, as a loose connection may cause

arcing and result in re.

• Ensure to hold the plug or connector to disconnect the cable; otherwise,

if you pull the cable only, it may damage the core wire and result in re or

electric shock.

• Place and route the power supply cord such that it is not likely to be walked

on or pinched by items placed upon or against them, paying particular

attention to the cord near the power plugs, convenience receptacles, and at

the point where it exits from the outlet.

• When the scanner is left unattended and unused for long periods of time,

unplug it from the wall outlet.

Moving and Storing the Scanner:

• Always ensure that the scanner is stored properly before shipping or moving

it. Quick stops, excessive force, and uneven surfaces may cause the

product to overturn when moving.

• Do not hit or drop the scanner. The scanner may be damaged if it receives

a strong jolt, which may result in re or electric shock if the scanner is used

without being repaired.

• Do not place the scanner on any slippery, slanted, or unstable surface. The

product may slide or fall, causing serious injury to people as well as serious

damage to the product.

CAUTION

WARNING

ObjectScan 1600 User's Manual 5

• Do not use the scanner near water. Never spill liquid of any kinds on the

product, or it may result in electric shock or other hazards.

• This scanner should be situated away from heat sources such as radiators,

heat registers, stoves, or other products (including ampliers) that produce

heat.

• Do not store the scanner in which it may be exposed to direct sunlight.

• Do not place the scanner near the edge of a table. When the drawer of the

scanner is opened, the weight of the product may cause the scanner falling,

causing serious injury to people as well as serious damage to the product.

Using the Scanner:

• The maximum loading weight for upper and lower scan beds is 5.5 lbs (2.5

kg). Do not put any material on scan beds heavier than the loading limit.

Maintenance and Service:

• When the scanner is going to be cleaned, ensure to turn off the power of

each device and unplug the power cable from the AC outlet.

• When you need a repair service, unplug the scanner from the power outlet

and consult qualied service personnel.

• When replacement parts are required, use replacement parts that are

specied by the manufacturer or have the same characteristics as the

original parts.

6 ObjectScan 1600 User's Manual

Table of Contents

Preface ................................................................................................2

FCC Compliance Statement ................................................................3

Safety Precautions ..............................................................................4

Knowing about Your Scanner..............................................................7

Features of the Your Scanner ............................................................. 7

System Requirements ........................................................................ 8

Taking a Closer Look ......................................................................... 9

Front View ................................................................................. 9

Back View................................................................................ 10

Initiate Setup..................................................................................... 11

Step 1: Unpacking Package Contents ................................................ 11

Step 2: Installing the Software.......................................................... 12

Step 3: Unlocking the Scanner.......................................................... 13

Step 4: Installing the Upper Scan Bed................................................ 15

Step 5: Connecting the Scanner........................................................ 16

To the Power Source................................................................. 16

To the Hi-Speed USB Cable ........................................................ 16

Scanning the Materials......................................................................17

Positioning the Materials .................................................................. 17

Using ScanWizard Graph Software .................................................... 19

Maintenance ......................................................................................22

Appendix ...........................................................................................23

Optional Magnet Helpers.................................................................. 23

Troubleshooting .............................................................................. 25

Specications ................................................................................. 26

ObjectScan 1600 User's Manual 7

Knowing about Your Scanner

The ObjectScan 1600 is a professional scanner exclusively designed for

transferring originals of samples into digital formats. It is ideal for capturing

images for small and stereoscopic objects and these images can be used in many

categories, such as collections, teaching, researching, manufacturing and web

business. At the same time, the ObjectScan 1600 is also able to scan paper

materials, for example, prints and researching papers.

Features of the ObjectScan 1600

The ObjectScan 1600 comes with several important features, including the

following:

• Non-contact scan (on-top scan) Design — The ObjectScan 1600 takes on a

design of a non-contact scan (on-top scan) structure. Under this structure,

users have no needs to spin sample face down on the scan bed, and enjoy

the scan work without worrying about the problems that traditional atbed

scanners deal with, such as damage problem caused by directly contact

each other. The ObjectScan 1600 is perfect for digitalizing the originals of

samples.

• Energy-saving tri-wave LED light source — Adopting tri-wave LEDs as the

light source, when the scanner is detected by the system, there are no

requirements for any warm-up time before carrying out the scan, which

boots your productivity and reduces energy costs amazingly. With its stable

performance, the image quality will remain consistent even after used for a

certain period of time.

• Color CCD with 1600-dpi high resolution — The ObjectScan 1600 has a

color linear CCD with resolution that reaches up to 1,600 pixels per inch.

Thus, it can clearly capture images for shapes and textures of objects,

presenting original appearances of objects precisely and decreasing the

happenings of damages on objects when doing researches.

• Microtek ScanWizard Graph software — ScanWizard Graph is software

exclusively designed for scanning large-format graphs and objects. It is

provided with series of advanced functions and tools, providing instant and

complete helps to users who can therefore control the scanner easily and get

the best image results.

8 ObjectScan 1600 User's Manual

System Requirements

• DVD-ROM drive (for installing software)

• Color display with 24-bit color output capability

• 8 GB RAM or more recommended

• Intel Core i5 at 3.0 GHz PC or higher with USB 2.0 port

• Microsoft Windows 7 (64-bit), 8 (64-bit) or 10 (64-bit)

ObjectScan 1600 User's Manual 9

Taking a Closer Look

Front View

No. Names of Parts Functions of Parts

1 Indicators Displays the status of the scanner.

(Green and Orange)

2 Drawer of the Scanner Carries the upper scan bed and the lower scan bed of the scanner.

3 Handle of the Drawer Holds to open or close the drawer of the scanner.

4 Right Handle Holds to move the scanner.

10 ObjectScan 1600 User's Manual

Back View

No. Names of Parts Functions of Parts

1 Power Connector Connects the scanner to the power cord.

2 Power Button Turns the scanner on or off.

3 Hi-Speed USB Port Connects the Hi-Speed USB (USB 2.0) cable to the computer.

4 Left Handle Holds to move the scanner.

Autres manuels pour ObjectScan 1600

Table des matières

Autres manuels Microtek Scanner

Microtek

Microtek ScanMaker 8700 Manuel utilisateur

Microtek

Microtek ScanMaker i800 Manuel

Microtek

Microtek FileScan 3125c Manuel utilisateur

Microtek

Microtek ScanMaker V6UPL Manuel utilisateur

Microtek

Microtek XT5750 HS Manuel utilisateur

Microtek

Microtek ArtixScan F2 Mode d’emploi

Microtek

Microtek ArtixScan 3200XL Mode d’emploi

Microtek

Microtek ArtixScan DI 3130c Mode d’emploi

Microtek

Microtek ArtixScanDI 4020 Plus Mode d’emploi

Microtek

Microtek ScanMaker 4600 Manuel utilisateur

Microtek

Microtek ArtixScan 120tf Manuel utilisateur

Microtek

Microtek ScanMaker i900 Manuel utilisateur

Microtek

Microtek ArtixScan DI 2020 Instructions de montage

Microtek

Microtek ObjectScan 1600 Manuel utilisateur

Microtek

Microtek Bio-5050 Manuel utilisateur

Microtek

Microtek ScanMaker 3800 Manuel utilisateur

Microtek

Microtek ScanMaker 3880 Manuel utilisateur

Microtek

Microtek ScanMaker 5700 Manuel utilisateur

Microtek

Microtek ScanMaker i480 Mode d’emploi

Microtek

Microtek ScanMaker 3700 Manuel utilisateur

Microtek

Microtek ScanMaker s380 Mode d’emploi

Microtek

Microtek ScanMaker 5950 Manuel utilisateur

Microtek

Microtek ScanMaker 1000XL Plus Manuel utilisateur

Microtek

Microtek ScanMaker IIG Manuel utilisateur

Manuels Scanner populaires d'autres marques

Plustek

Plustek Scanner Manuel utilisateur

Z/I Imaging

Z/I Imaging PhotoScan 2001 Manuel utilisateur

Renkforce

Renkforce DS100-5M Manuel utilisateur

Image Access

Image Access WideTEK A2 Manuel utilisateur

Canon

Canon imageFORMULA CR-120N Manuel utilisateur

Fujitsu

Fujitsu FI-4860C2 Manuel utilisateur

GeoSlam

GeoSlam ZEB Horizon Instructions d'installation

Kodak

Kodak i5800 Scanner Manuel utilisateur

Kodak

Kodak i7300 Manuel utilisateur

Revopoint

Revopoint POP Manuel utilisateur

Fujitsu

Fujitsu fi-4860C Manuel utilisateur

Eddyfi Technologies

Eddyfi Technologies Floormap X Manuel utilisateur

Faselase

Faselase F6 Manuel utilisateur

Fujitsu

Fujitsu CardMinder Manuel utilisateur

Uniden

Uniden BC340CRS Manuel utilisateur

Infinite Peripherals

Infinite Peripherals INFINEA TAB M Manuel utilisateur

Mustek

Mustek PageExpress 4800 Pro Manuel utilisateur

Optex

Optex 750830 Manuel utilisateur
