Microtek JTX V9s Manuel utilisateur
i
FCC Compliance Statement
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions:
1. this device may not cause harmful interference, and
2. this device must accept any interference received, including interfer-
ence that may cause undesired operation.
FCC WARNING
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interfer-
ence in a residential installation.
This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a par-
ticular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interfer-
ence by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and the receiver.
•Connect the equipment into an outlet different from that to which
the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Caution:
To comply with the limits for an FCC Class B computing device, always
use the shielded signal cord supplied with this unit.
The Federal Communications Commission warns that changes or modifi-
cations of the unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
ii
CE mark for Class B ITE (Following European standard EN55022/1998;
EN61000-3-2/1995; EN61000-3-3/1995, EN55024/1998,
EN60950/1992+A1+A2+A3+A4+A11)
Radio Frequency Interference Statement
Warning:
This is a Class B product. In a domestic environment, this product may
cause radio interference in which case the user may be required to take
adequate measures.
Canadian Doc Notice
For Class B Computing Devices
This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus as set out in the Radio Interference
Regulation of the Canadian Department of Communications.
“Le présent appareil numérique n’èmet pas de bruits radioélectriques dé-
passant les limites applicables aux appareils numériques de la class B
prescrites dans le Règlement sur le brouillage radioélectrique édicté par
le ministère des Communications du Canada.”
iii
TABLE OF CONTENTS
TABLE OF CONTENTS ..........................................................................................III
Your New LCD Monitor 1
Unpacking 1
Identifying Components 3
Adjusting the Viewing Angle 6
Connecting AC Power, Video and Audio Cable 7
Power Management System 7
The LCD Monitor’s Display Controls 8
Adjusting the Monitor’s Display 9
LCD Monitor Specifications 17
Supported Timing 19
LCD Monitor Wall Mounting 20
Troubleshooting 22
1
The LCD Monitor
Your New LCD Monitor
Your LCD Monitor has been designed to be versatile, ergonomic and user-
friendly. The LCD Monitor is capable of displaying most standards, from
640x400 VGA to 1280x1024 SXGA. The digital controls located on the
front panel allow the user to easily adjust the Monitor’s display parameters,
and the LCD Monitor’s small footprint gives you more room in your work-
space for other peripherals. Lightweight and compact, the LCD Monitor is
the perfect solution for users on the go. You can use the LCD Monitor for
everything from making business presentations to playing computer games.
The two stereo speakers allow you to further expand your computer’s mul-
timedia capabilities by connecting your computer’s Audio out port to the
LCD Monitor’s Audio in port. The Monitor also has a wall-mountable stand
for added convenience.
The architecture of the LCD Monitor incorporates an LCD panel that pro-
duces a clear display with low radiation emission. And with its low power
consumption, the LCD Monitor helps you reduce your power bill.
Unpacking
Before unpacking your LCD Monitor, prepare a suitable workspace for
your LCD Monitor and computer. Look for a stable, level and clean sur-
face near a wall outlet. Even though the LCD Monitor uses very little
power, you should put it in a location which allows sufficient airflow to
ensure that the LCD Monitor and your computer do not overheat. Set
up your LCD Monitor so that the panel is not facing a window where
sunlight often comes in. The glare caused by sunlight reflecting off of
the LCD Monitor’s screen will make it difficult to use the Monitor for
viewing.
2
Note: Using a computer for an extended period of time with a poor workstation set-
up and incorrect working habits can cause health problems. The science of ergo-
nomics studies the relationship between health and a suitable working
environment. There is a section on ergonomics at the end of this chapter. For
more information on ergonomics, contact your nearest computer bookstore, or
local library. The Internet also has information on this and other subjects.
After unpacking your LCD Monitor; make sure the following items are in-
cluded in the box and are in good condition:
•LCD Monitor
•Monitor-to-PC Analog signal cable (15-pin)
•Monitor-to-PC Digital signal cable (24-pin)
•Stereo Jack Audio Cable
•AC Adapter
•Power cord
•User’s manual
If you find any item to be missing or appear to be damaged, contact your
dealer immediately. Do not throw away the packing material or shipping
carton in case you need to ship or store the LCD Monitor in the future.
3
Identifying Components
A. The LCD Monitor — Front View
Figure 1-1: The LCD Monitor Front View
1. Power-On Indicator
This LED indicator stays lit when the power is on and blinks
when the LCD monitor is in power-saving mode.
2. Monitor Stand
3. LCD Screen
The LCD monitor screen is a 19-inch TFT 1280 x 1024 screen.
4. LCD Monitor Control Panel
Refer to Chapter 2 for more details.
4
B. "Hot Keys" for Quick Adjustment of Monitor Settings
Figure 1-2: "Hot Keys"
1. Auto-adjust "hot key":
Press button 2 to apply the monitor setting auto-
matically. A small “AUTO ADJUST” OSD is also
displayed.
2. Adjust-volume "hot key":
Press button 3 to allow you to adjust the audio
volume directly.
5
3. Contrast-adjust "hot key":
Press button 4 to allow you to adjust the contrast of
the display directly.
** To close the small OSD windows, press the power button (button 5).
