Micronics D5CUB ISA Manuel utilisateur
D5CUB PCI/ISA
System Board Manual
DocumentNumber:06-00287-02,Rev.B
June1996
221Warren Ave.,Fremont, CA 94539-7085
D5CUB System Board Manual
2
Copyright Notices
Copyright1996 MicronicsComputers,Inc. Theinformationcontained
in the D5CUB PCI/ISA system board manual has been carefully checked
andisbelievedtobeaccurate.Micronicsassumesnoresponsibilityforany
inaccuraciesthatmaybecontainedinthisdocument.Micronicsmakesno
commitments to update or to keep the information in this manual at a
current level when changes are made to the product.
Micronics reserves the right to make improvements to this document
and/or product at any time and without notice. All Rights Reserved. No
part of this document may be photocopied, reproduced, translated, or
reduced to any medium or machine form without prior, written consent
from Micronics.
Portions of the Manual
Portions of this manual were copied (with permission) from Award
Software Inc. and Micro Computer Systems, Inc. All rights reserved.
Trademarks
Award Modular BIOS is a registered trademark of Award Software Inc.
IBM is a registered trademark of International Business Machines. Mi-
crosoftand WindowsareregisteredtrademarksofMicrosoftCorporation.
Intel and PCI are registered trademarks of Intel Corporation. All other
productnamesmentionedhereinareusedforidentificationpurposesonly
and may be the trademarks of their respective companies.
D5CUB System Board Manual 1
Table of Contents
Introduction 5
Features 6
Software Compatibility 7
Before You Begin 8
Section 1 - Quick Installation 9
Installing the D5CUB 9
Section 2 - Configuring the D5CUB 13
Static Electricity 13
Office Environment 13
D5CUB System Board 14
Jumper Settings 15
Section 3 - Installing the D5CUB 21
Introduction 21
System Memory Support 21
Installing the D5CUB 22
Tools Required 22
Equipment Required 22
System Memory 23
SIMMs Supported 23
Upgrading Rules 23
Mixing EDO and FPM Memory 24
Memory Configurations 25
Installing the SIMMs 26
Removing SIMMs 26
Installing a CPU 27
Installing a PCI Peripheral Card 28
Installing an ISA Peripheral Card 29
D5CUB System Board Manual
Installing a CD-ROM Drive 30
Installing the Sound Interface Card 31
Connecting Sound Devices 32
Section 4 - The BIOS Setup Utility 35
Configuration 35
Initial Bootup 35
Setup 35
Running the Setup Procedure 37
Standard CMOS Setup 38
BIOS Features Setup 40
Chipset Features Setup 43
Power Management Setup 44
PnP/PCI Configuration Setup 46
Load BIOS Defaults 48
Load Setup Defaults 48
Integrated Peripherals 49
Supervisor Password 51
User Password 51
IDE HDD Auto Detection 52
HDD Low Level Format 53
Save and Exit Setup 54
Exit Without Saving 54
Section 5 - Installing Sound Device Drivers 55
About Device Drivers 55
Installing the Sound Drivers 56
Appendix A - Technical Information 57
Specifications 57
Environmental Specifications 58
Temperature Range 58
2
D5CUB System Board Manual
Relative Humidity 58
Battery Disposal 59
Technical Support 60
Online Services 61
Appendix B - Post Messages 63
Appendix C - Hard Disk Drive Types 65
Appendix D - Updating the System BIOS 67
Appendix E - Compatibility 69
Limited Warranty 72
Non-Warranty Service 73
FCC Statement 74
Declaration of Conformity 75
Index 76
3
D5CUB System Board Manual
4
List of Figures
Figure 1.1: Power-Up Screen 10
Figure 2.1: D5CUB System Board 14
Figure 3.1: Installing a 72-Pin SIMM 26
Figure 3.2: Installing a CPU 28
Figure 3.3: Installing an ISA Peripheral Card 29
Figure 3.4: Connecting the Sound Interface Card 32
Figure 4.1: Power-Up Screen 36
Figure 4.2: Main CMOS Setup Screen 37
Figure 4.3: Standard CMOS Setup Screen 38
Figure 4.4: BIOS Features Setup Screen 40
Figure 4.5: Chipset Features Setup Screen 43
Figure 4.6: Power Management Screen 44
Figure 4.7: PnP/PCI Configuration Screen 46
Figure 4.8: Integrated Peripherals Screen 49
Figure 4.9: IDE HDD Auto Detection Screen 52
Figure 4.10: HDD Low Level Format Screen 53
List of Tables
Table 2.1: System Speed Selection (Intel) 15
Table 2.2: System Speed Selection (Cyrix) 15
Table 2.3: Power Supply Voltage Selection 16
Table 2.4: Pentium CPU Type Selection 16
Table 2.5: TAG SRAM Type Selection 16
Table 2.6: Multi I/O Chipset Selection 17
Table 2.7: Sound Interface Selection 17
Table 2.8: CPU Internal Cache Selection 17
Table 2.9: Clear CMOS Memory Selection 18
Table 2.10: Clock Ratio Selection 18
Table 2.11: Jumper Settings & Functions 19
Table 2.12: Connector Settings and Functions 20
Table 3.1: Memory Configurations 25
D5CUB System Board Manual
Introduction
Thank you for choosing the D5CUB system board. The
D5CUB provides the latest enhancements in system-
board technology for high-performance desktops.
Based on the Intel 430HX PCIset, the D5CUB provides
enhanced PCI throughput and performance for today’s
demanding applications. The onboard voltage regulator
permitsthe use of Intel’s fastestprocessors andthe Cyrix
6x86 processor.
The D5CUB comes with many features. These include
support for Fast Page Mode (FPM) and Extended Data
Out (EDO) memory, Error Checking and Correction
(ECC), pipelined-burst level 2 cache, the Award Plug
andPlay BIOSandanoptionalfeatureforintegrated 16-
bit sound.
Micronicsbuildsallproductstoexactingstandards,using
the highest quality components available. We are proud
to provide this system board and believe you will be
pleased with your purchase.
5
D5CUB System Board Manual6
Features
The D5CUB includes the following features:
SingleZIF socket7xxxxxxxxxxxxxxxxxxxxxxxxxxxx
SupportsIntel75 - 200 MHz Pentiumand Pentium
iiiiiOverdrive processors xxxx xxxx xxxx xxxx xxxx
SupportsCyrix6x86100-133MHzprocessorsxxxxxxxx
VRE support
Intel 430HX PCIset
Intel PIIX 3
SMC 669/UMC8669/ALI M5113 I/O chip
Three32-bitPCIslotsxxxx xxxxxxxxxxxxxxxx xxxx
Two 16-bit ISA slots xxxx xxxx xxxx xxxx xxxx iiiii
One shared PCI/ISA slot xxxx xxxx xxxx xxxx xxxx
16 KB on-chip Level 1 write-back cache xxxx xxxx iii
Up to 512K pipelined burst external Level 2 cache
Support for up to 256MB of onboard system memory
Four 32/36-bit, 72-pin, double-sided SIMM sockets to
accommodate: xxxx xxxx xxxx xxxx xxxxxx xxxx iiiii
1MB x 32/36 (4MB)xx4MB x 32/36 (16MB)xxxx iiiii
2MB x 32/36 (8MB)xx8MB x 32/36 (32MB)xxxx
16 MB x 32/36 (64 MB)xxxx xxxx xxxx
Supports EDO memory
ECC support via chipset
PCIlocalbusIDExxxxxxxxxxxxxxxxxxxxxxxxxxxx
Mode 4 Enhanced IDE with Bus Mastering xxxx xxxx
Two resident 40-pin IDE connectors
iiiii(Primaryand Secondary IDE)xxxx xxxxxxxx xxxx
Auto detection of add-in IDE interface boards xxxx
Multiple-sector transfer support
Floppycontrollerfortwofloppydrives(supports2.88MB,
1.44MB, 1.2MB, 720K, and/or 360K floppy drives)
Auto detection of add-in floppy controllers
D5CUB System Board Manual 7
Twoonboard16550-compatibleserialportsxxxxxxxx
OneonboardparallelportwithECPandEPPsupportxx
Field upgradeable Award BIOSxxxx xxxx
PCI auto configuration xxxx xxxx xxxx xxxx xxxx
Plug and Play ready xxxx xxxx xxxx xxxx xxxx xxxx
Auto detection of memory sizexxxx xxxx xxxx xxxx
AutodetectionanddisplayofECCandEDOmemoryx
Auto configuration of IDE hard disk types
ESS1788F Soundxxxx xxxxxxxx xxxxxxxx xxxxxxx
Sound Blaster-compatible 16-bit Stereo xxxx xxxx
Input/Output, Game and MIDI portsxxxx xxxx xxxx
iiiii(sound support is optional)
Software Compatibility
The D5CUB system board has been thoroughly tested for
compatibility with a variety of operating systems and envi-
ronments, including:
Windows 95 and Windows NT
OS/2 Warp
SCO UNIX and Open Desktop
Novell Netware
MS-DOS 5.0 and 6.2
PC-DOS
Solaris
D5CUB System Board Manual
8
Before You Begin
This manual will familiarize you with the features, installa-
tionand use ofyour D5CUB.There are severalsymbols and
conventionsusedthroughoutthismanualtohelp drawyour
attention to a feature or to focus on important information:
When you see the Magnifying Glass, it refers
to something you should take a closer look at
before proceeding further.
WhenyouseetheExclamationMark,itgives
important information on avoiding damage.
Common Names
DRAM Dynamic Random Access Memory
ECC Error Checking and Correction
ECP Enhanced Communications Port
EDO Extended Data Out
FPM Fast Page Mode
IDE Integrated Drive Electronics
PCI Peripheral Component Interconnect
SIMM Single Inline Memory Module
VR Voltage Regulated
VRE Voltage Regulated Extension
