2003 Microchip Technology Inc. DS39582B-page 1

PIC16F87XA

Devices Included in this Data Sheet:

High-Performance RISC CPU:

• Only 35 single-word instructions to learn

• All single-cycle instructions except for program

branches, which are two-cycle

• Operating speed: DC – 20 MHz clock input

DC – 200 ns instruction cycle

• Up to 8K x 14 words of Flash Program Memory,

Up to 368 x 8 bytes of Data Memory (RAM),

Up to 256 x 8 bytes of EEPROM Data Memory

• Pinout compatible to other 28-pin or 40/44-pin

PIC16CXXX and PIC16FXXX microcontrollers

Peripheral Features:

• Timer0: 8-bit timer/counter with 8-bit prescaler

• Timer1: 16-bit timer/counter with prescaler,

can be incremented during Sleep via external

crystal/clock

• Timer2: 8-bit timer/counter with 8-bit period

• Two Capture, Compare, PWM modules

- Capture is 16-bit, max. resolution is 12.5 ns

- Compare is 16-bit, max. resolution is 200 ns

- PWM max. resolution is 10-bit

• Synchronous Serial Port (SSP) with SPI™

(Master mode) and I2C™(Master/Slave)

• Universal Synchronous Asynchronous Receiver

Transmitter (USART/SCI) with 9-bit address

detection

• Parallel Slave Port (PSP) – 8 bits wide with

external RD, WR and CS controls (40/44-pin only)

• Brown-out detection circuitry for

Brown-out Reset (BOR)

Analog Features:

• 10-bit, up to 8-channel Analog-to-Digital

Converter (A/D)

• Brown-out Reset (BOR)

• Analog Comparator module with:

- Two analog comparators

- Programmable on-chip voltage reference

(VREF) module

- Programmable input multiplexing fromdevice

inputs and internal voltage reference

- Comparator outputs are externally accessible

Special Microcontroller Features:

• 100,000 erase/write cycle Enhanced Flash

program memory typical

• 1,000,000 erase/write cycle Data EEPROM

memory typical

• Data EEPROM Retention > 40 years

• Self-reprogrammable under software control

• In-Circuit Serial Programming™ (ICSP™)

via two pins

• Single-supply 5V In-Circuit Serial Programming

• Watchdog Timer (WDT) with its own on-chip RC

oscillator for reliable operation

• Programmable code protection

• Power saving Sleep mode

• Selectable oscillator options

• In-Circuit Debug (ICD) via two pins

CMOS Technology:

• Low-power, high-speed Flash/EEPROM

technology

• Fully static design

• Wide operating voltage range (2.0V to 5.5V)

• Commercial and Industrial temperature ranges

• Low-power consumption

• PIC16F873A

• PIC16F874A •PIC16F876A

•PIC16F877A

Device

Program Memory Data

SRAM

(Bytes)

EEPROM

(Bytes) I/O 10-bit

A/D (ch) CCP

(PWM)

MSSP

USART Timers

8/16-bit Comparators

Bytes # Single Word

Instructions SPI Master

I2C

PIC16F873A 7.2K 4096 192 128 22 5 2 Yes Yes Yes 2/1 2

PIC16F874A 7.2K 4096 192 128 33 8 2 Yes Yes Yes 2/1 2

PIC16F876A 14.3K 8192 368 256 22 5 2 Yes Yes Yes 2/1 2

PIC16F877A 14.3K 8192 368 256 33 8 2 Yes Yes Yes 2/1 2

28/40/44-Pin Enhanced Flash Microcontrollers
