ExpLoRer Starter Kit User Guide

Introducing: ExpLoRer

Why Arduino??

Open Source

Industry standard

Easily accessible

Free IDEs

No flashing tools needed –only a USB cable

Simple structure (setup & loop) with examples

Excellent HAL

Re-use projects across AVR, PIC, Cortex

cores

Hugely popular!

ExpLoRer - Arduino

Micro USB:

Arduino IDE

& charging

LiR2450

rechargeable

battery

120mAh, 3.6V

Atmel SAM-D21

Cortex®-M0+ based

microcontroller

Standard headers

for feature expansion

(sensors, GPS, solar)

ExpLoRer - Wireless

RN4871

BT-Smart

RN2483a

LoRaWAN

Low-cost

(removable)

PCB IFA

antenna

Footprint for

optional SMA

ExpLoRer

RGB LED for status

Indication

Standard headers

for feature expansion

(sensors, GPS, solar)

MCP9700AT

Temperature

Sensor

Blue

LED

ExpLoRer - Security

ECC508A

Crypto Device

ExpLoRer

Micro USB:

Arduino IDE

& charging

LiR2450

rechargeable

battery

120mAh, 3.6V

RGB LED for status

Indication

RN4871

BT-Smart

Atmel SAM-D21

Cortex®-M0+ based

microcontroller

RN2xx3

LoRaWAN

Low-cost

(removable)

PCB IFA

antenna

Footprint for

optional SMA

Standard headers

for feature expansion

(sensors, GPS, solar)

ECC508A

Crypto Device

MCP9700AT

Temperature

Sensor

Blue

LED

Specifications

Microcontroller

Microchip ATSAMD21J18

-Bit ARM Cortex M0+

Compatibility

Arduino M0 Compatible

Size

x 53 mm

Operating Voltage

3.3V

I/O Pins

Analog Output Pin

-bit ADC

External Interrupts

Available on all pins

DC Current per I/O pin

7 mA

Flash Memory

256

KB (internal)

and

4MB (external SST25PF040C flash)

SRAM

32KB

EEPROM

Up to 16KB by emulation

Specifications

Clock Speed

48 MHz

Power

5V USB power and/or 3.7

Lithium battery

Charging

Solar charge controller, up to 500mA

charge current

LED

RGB LED, Blue LED

LoRa

Microchip

RN2483a Module

Bluetooth

Microchip

RN4871 Module

CryptoAuthentication

Microchip ATECC508A

Temperature sensor

Microchip MCP9700AT

USB

Micro USB

Port
