Explorer 16 Development Board

User’s Guide

Addendum for PIC32MX

Information contained in this publication regarding device

applications and the like is provided only for your convenience

and may be superseded by updates. It is your responsibility to

ensure that your application meets with your specifications.

MICROCHIP MAKES NO REPRESENTATIONS OR

WARRANTIES OF ANY KIND WHETHER EXPRESS OR

IMPLIED, WRITTEN OR ORAL, STATUTORY OR

OTHERWISE, RELATED TO THE INFORMATION,

INCLUDING BUT NOT LIMITED TO ITS CONDITION,

QUALITY, PERFORMANCE, MERCHANTABILITY OR

FITNESS FOR PURPOSE. Microchip disclaims all liability

arising from this information and its use. Use of Microchip

devices in life support and/or safety applications is entirely at

the buyer’s risk, and the buyer agrees to defend, indemnify and

hold harmless Microchip from any and all damages, claims,

suits, or expenses resulting from such use. No licenses are

conveyed, implicitly or otherwise, under any Microchip

intellectual property rights.

Trademarks

The Microchip name and logo, the Microchip logo, Accuron,

dsPIC, KEELOQ, KEELOQ logo, MPLAB, PIC, PICmicro,

PICSTART, PRO MATE, rfPIC and SmartShunt are registered

trademarks of Microchip Technology Incorporated in the

U.S.A. and other countries.

FilterLab, Linear Active Thermistor, MXDEV, MXLAB,

SEEVAL, SmartSensor and The Embedded Control Solutions

Company are registered trademarks of Microchip Technology

Incorporated in the U.S.A.

Analog-for-the-Digital Age, Application Maestro, CodeGuard,

dsPICDEM, dsPICDEM.net, dsPICworks, dsSPEAK, ECAN,

ECONOMONITOR, FanSense, In-Circuit Serial

Programming, ICSP, ICEPIC, Mindi, MiWi, MPASM, MPLAB

Certified logo, MPLIB, MPLINK, mTouch, PICkit, PICDEM,

PICDEM.net, PICtail, PIC32 logo, PowerCal, PowerInfo,

PowerMate, PowerTool, REAL ICE, rfLAB, Select Mode, Total

Endurance, UNI/O, WiperLock and ZENA are trademarks of

Microchip Technology Incorporated in the U.S.A. and other

countries.

SQTP is a service mark of Microchip Technology Incorporated

in the U.S.A.

All other trademarks mentioned herein are property of their

respective companies.

Printed on recycled paper.

Note the following details of the code protection feature on Microchip devices:

• Microchip products meet the specification contained in their particular Microchip Data Sheet.

• Microchip believes that its family of products is one of the most secure families of its kind on the market today, when used in the

intended manner and under normal conditions.

• There are dishonest and possibly illegal methods used to breach the code protection feature. All of these methods, to our

knowledge, require using the Microchip products in a manner outside the operating specifications contained in Microchip’s Data

Sheets. Most likely, the person doing so is engaged in theft of intellectual property.

• Microchip is willing to work with the customer who is concerned about the integrity of their code.

• Neither Microchip nor any other semiconductor manufacturer can guarantee the security of their code. Code protection does not

mean that we are guaranteeing the product as “unbreakable.”

Code protection is constantly evolving. We at Microchip are committed to continuously improving the code protection features of our

products. Attempts to break Microchip’s code protection feature may be a violation of the Digital Millennium Copyright Act. If such acts

allow unauthorized access to your software or other copyrighted work, you may have a right to sue for relief under that Act.

Microchip received ISO/TS-16949:2002 certification for its worldwide

headquarters, design and wafer fabrication facilities in Chandler and

Tempe, Arizona; Gresham, Oregon and design centers in California

and India. The Company’s quality system processes and procedures

are for its PIC®MCUs and dsPIC®DSCs, KEELOQ®code hopping

devices, Serial EEPROMs, microperipherals, nonvolatile memory and

analog products. In addition, Microchip’s quality system for the design

and manufacture of development systems is ISO 9001:2000 certified.

EXPLORER 16 DEVELOPMENT BOARD

USER’S GUIDE ADDENDUM FOR PIC32MX

Chapter 1. Programming Tutorial for PIC32MX

1.1 INTRODUCTION

This chapter is a self-paced tutorial to get you started using the Explorer 16 Develop-

ment Board with a PIC32MX Plug-In Module (PIM).

1.2 HIGHLIGHTS

Items discussed in this chapter include:

• Installing Explorer 16 with PIC32MX Software and Documentation

• Using the Explorer 16 Out of the Box

• Explorer 16 Development Board Demonstration Programs

• Tutorial Overview

• Creating the Project

• Building the Code

• Programming the Device

• Tutorial Program Operation

1.3 INSTALLING EXPLORER 16 WITH PIC32MX SOFTWARE AND

DOCUMENTATION

The Explorer 16 Development Board PIC32MX CD contains the Microchip MPLAB®

IDE integrated development environment and MPLAB®C32 C Compiler, the

Explorer 16 Development Board User’s Guide Addendum, and the files and software

to create the tutorial project. Insert the disc into your CD drive and an automatic

installation application will guide you through installation of the tools and documents.

1.4 USING THE EXPLORER 16 OUT OF THE BOX

Although intended as a development platform, the Explorer 16 board can also be used

directly from the box as a demonstration board for PIC32MX devices. The program

(UartBasicLab.hex) discussed in Section 1.11 “PIC32MX Tutorial Program Opera-

tion” is preprogrammed into the PIC32MX PIM and is ready for immediate use.

To get started with the board:

1. For Explorer 16 boards without a permanently mounted PIC32MX device: care-

fully remove the mounted PIM and install the PIC32MX360F512L PIM in its place

with the notched corner of the PIM oriented to the upper-left corner of the board.

2. Verify that switch S2 is set in the “PIM” position.

3. Verify that the jumper on JP2 is installed (to enable the LEDs).

4. Apply power to the board (9 VDC) at power input J2.

For information on acceptable power sources, see Appendix A. “Explorer 16

Development Board Schematics”.

Explorer 16 Development Board User’s Guide Addendum for PIC32MX

1.5 EXPLORER 16 DEVELOPMENT BOARD DEMONSTRATION PROGRAM

The CD contains a sample demonstration program for the PIC32MX360F512L device.

It may be used with the included PIC32MX PIM by reprogramming the device using

MPLAB®REAL ICE™ in-circuit emulator.

The example code preprogrammed on the PIM is also included on the Explorer 16 CD.

All project files have been included, so that the code may be used directly to restore

the PIM to its original state for cases in which the PIM is programmed for another appli-

cation. It is also useful if you would like to use the tutorial code as a platform for further

experimentation.

1.6 TUTORIAL OVERVIEW

The tutorial in this chapter demonstrates features of the MPLAB IDE and REAL ICE as

they are used with the Explorer 16 Development Board. As presented, it is designed

for use with the PIC32MX360F512L specifically. However, the same procedures and

toolsuites can also be used with other PIC32MX devices.

The PIC32MX tutorial project demonstrated here, UartBasicLab.mcp, is written in C

for the MPLAB C32 C compiler. The program displays the build date and time to the

Microsoft Windows®HyperTerminal on a personal computer (PC) via UART. The pro-

gram also accepts user input from the HyperTerminal. The UartBasicLab program is

described in more detail in Section 1.11 “PIC32MX Tutorial Program Operation”.

After completing this tutorial, you should be able to complete the following tasks:

• Create a project using the Project Wizard

• Set the Configuration bits, and compile and link the code.

• Set up MPLAB IDE integrated development environment to use the MPLAB REAL

ICE in-circuit emulator

• Program the PIC32MX360F512L with the MPLAB REAL ICE in-circuit emulator

Programming Tutorial for PIC32MX

1.7 CREATING THE PROJECT

The first step is to create a project and a workspace in MPLAB IDE. Typically, there is

a single project per workspace.

MPLAB IDE contains a Project Wizard to help create new projects.

Perform the following steps to create the tutorial project.

1. Start MPLAB IDE.

2. From the menu bar, click File >Close Workspace to close any workspace that

might be open.

3. Click Project > Project Wizard... to start the wizard.

4. From the Welcome screen, click Next > to display the Project Wizard – Step One:

dialog window (Figure 1-1).

FIGURE 1-1: SELECTING THE DEVICE

5. From the Device drop-down list, select “PIC32MX360F512L”. Click Next >.

The Project Wizard – Step Two: dialog displays, as shown in Figure 1-2.

Explorer 16 Development Board User’s Guide Addendum for PIC32MX

1.7.1 Select the Language Toolsuite

FIGURE 1-2: SELECTING THE TOOLSUITE

1. From the Active Toolsuite drop-down list, select “Microchip PIC32 C-Compiler

Toolsuite”. This toolsuite includes the assembler and linker that will be used.

If Microchip PIC32 C-Compiler is not available in the list, check the “Show all

installed toolsuites” box and click Help! My Suite Isn’t Listed.

2. In the Toolsuite Contents combo box, select “MPLAB C32 C Compiler

(pic32-gcc.exe)”.

3. Click Next >.

The Project Wizard – Step Three: dialog box displays, as shown in Figure 1-3.

Programming Tutorial for PIC32MX

1.7.2 Name Your Project

FIGURE 1-3: NAMING YOUR PROJECT

1. Select Create New Project File, click Browse... and navigate to

C:\Program Files\Microchip\pic32_solutions\labs\uart_basic_lab

to place your project and name the project “UartBasicLab”.

C:\Program Files\Microchip\pic32_solutions\labs\uart_basic_lab

is the default location for the project. The folder was created and the source files

were copied during the initial installation.

2. Click Next > to continue.

The Project Wizard – Step Four: dialog displays, as shown in Figure 1-4.

Explorer 16 Development Board User’s Guide Addendum for PIC32MX

1.7.3 Add a File to the Project

1. In the left pane, select uart_basic_lab.c from the following folder:

C:\Program Files\Microchip\pic32_solutions\labs\uart_basic_lab

2. Click Add >> to add the file to the project.

3. Click Next > to continue.

FIGURE 1-4: ADDING A FILE TO THE PROJECT

4. When the summary screen displays, click Finish. A project and workspace have

now been created in MPLAB IDE.

UartBasicLab.mcw is the workspace file and UartBasicLab.mcp is the project file.

Programming Tutorial for PIC32MX

1.8 BUILDING THE PROJECT

1.8.1 Set the Configuration Bits

Before building the project, the configuration bits should be set properly. In this example

the configuration settings are mentioned in the source file.

Perform the following steps to set the configuration bits:

1. From the menu bar, click Configure > Configurations Bits....

2. In the configuration settings window (Figure 1-6), check the box “Configuration

Bits set in code” to ensure that the settings are taken from the source file.

FIGURE 1-5: SETTING CONFIGURATION BITS

1.8.2 Make the Project

From the menu bar, click Project > Make to build the project.

Monitor the progress of the build in the Output window, as shown Figure 1-6.

When the “BUILD SUCCEEDED:” message displays, you are ready to program the

device.

FIGURE 1-6: MONITORING BUILD OUTPUT

Explorer 16 Development Board User’s Guide Addendum for PIC32MX

1.9 PROGRAMMING THE DEVICE

1.9.1 Select the Tool

From the menu bar, click Debugger >Select Tool >REAL ICE.

If prompted for the firmware update, click Ok to update. Make sure that the MPLAB

REAL ICE in-circuit emulator is connected to the PC and to the Explorer 16 Board.

1.9.2 Program the Device

Perform the following steps to program the device:

1. Click the “Program” icon (Figure 1-7) in the MPLAB REAL ICE in-circuit emulator

window to program the device.

FIGURE 1-7: PROGRAM ICON IN MPLAB®REAL ICE™ WINDOW

A Programming Warning window (Figure 1-8) is displayed to warn you about

overwriting the memory.

2. Click Yes.

FIGURE 1-8: PROGRAMMING WARNING WINDOW

Monitor the Output window (Figure 1-9) for progress as the device is programmed. A

verification will notify you that the programming and verification is complete.

Autres manuels pour Explorer 16

Table des matières

Autres manuels Microchip Technology Matériel informatique

Microchip Technology

Microchip Technology AVR128DA48 Curiosity Nano Guide d'installation

Microchip Technology

Microchip Technology DS61160A Manuel utilisateur

Microchip Technology

Microchip Technology Adaptec HBA 1100 Manuel utilisateur

Microchip Technology

Microchip Technology AVR64EA48 Manuel utilisateur

Microchip Technology

Microchip Technology Microsemi miSLIC Le9642 Manuel utilisateur

Microchip Technology

Microchip Technology MPLAB REAL ICE In-Circuit Emulator Manuel

Microchip Technology

Microchip Technology PIC-BLE Manuel d'installation

Microchip Technology

Microchip Technology PD-90 G Series Manuel utilisateur

Microchip Technology

Microchip Technology dsPIC33 series Manuel utilisateur

Microchip Technology

Microchip Technology MCP6S22 PGA PICtail Manuel utilisateur

Microchip Technology

Microchip Technology LX7720 Manuel utilisateur

Microchip Technology

Microchip Technology Photodiode PGAPICtail Manuel utilisateur

Microchip Technology

Microchip Technology AVR128DB48 Curiosity Nano Manuel d'installation

Microchip Technology

Microchip Technology MCP42XX Manuel utilisateur

Microchip Technology

Microchip Technology TB3287 Manuel de référence

Microchip Technology

Microchip Technology PolarFire MPFS-DISCO-KIT Manuel utilisateur

Microchip Technology

Microchip Technology MCP39F501 Manuel utilisateur

Microchip Technology

Microchip Technology dsPIC33CK Manuel utilisateur

Microchip Technology

Microchip Technology RN4870 Manuel utilisateur

Microchip Technology

Microchip Technology PD-USB-DP60 Manuel utilisateur

Microchip Technology

Microchip Technology VSC8211 Manuel utilisateur

Microchip Technology

Microchip Technology EVB-LAN9253-ADD-ON Manuel utilisateur

Microchip Technology

Microchip Technology MPLAB REAL ICE Manuel utilisateur

Microchip Technology

Microchip Technology CAN/LIN/J2602 PICtail Plus Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur
