INSTALLATION INSTRUCTIONS FOR PART 99-9000

APPLICATIONS

CAUTION: Metra recommends disconnecting the

negative battery terminal before beginning any

installation. All accessories, switches, and especially

air bag indicator lights must be plugged in before

reconnecting the battery or cycling the ignition.

NOTE: Refer to the instructions included with the

aftermarket radio.

• DINheadunitprovision

• Variousmountingdepths

•A)Underdashhousing•B)(8)Phillipsscrews

KIT FEATURES

KIT COMPONENTS

•Phillipsscrewdriver•CuttingTool•Adjustablewrench

TOOLS REQUIRED

Universal

99-9000

CF-104UD, SEA/HOS, SEA/HOS-W

A B

99-9000

All Vehicles

1. Ifan“openback”installationis

desired(foradditionaldepth),cut

theUnderdashHousingalongthe

scoredlineandremovetherear

portionoftheHousing.(FigureA)

Dash Disassembly

(Figure A) (Figure A)

DIN head unit provision

1. SlidetheDINcageintothekit

andsecurebybendingthemetal

lockingtabsdown.

2. Slidetheaftermarketheadunitinto

thecageuntilsecure.(FigureA)

3. Locatethefactorywiringharness

inthedash.Metrarecommends

usingthepropermatingadapter

fromMetraorAXXESS.

Kit Assembly

99-9000

DIN head unit provision (continued)

4. Placetheheadunit/kit

assemblyunderthedashuntil

thedesiredmountinglocationhas

beenestablished.(FigureB)

5. Markthescrewholesonto

the dash.

6. Re-connectthebattery

terminalandtesttheunitfor

proper operation.

7. Mounttheheadunit/kit

assemblytothepre-marked

holesonthedashwith(8)Phillips

screwssupplied(If the back of

the Underdash Housing was

removed in Step #1, fewer screws

will be used).(FigureC)

(Figure B)

Kit Assembly

(Figure C)
