INSTALLATION INSTRUCTIONS FOR PART 95-5810

95-5810

KIT FEATURES

• Doubl DIN Radio Provision

• Stack d ISO Mount Units Provision

A) Doubl DIN Trim Plat B) Doubl DIN Brack ts

KIT COMPONENTS

Small Flat Blad Scr wdriv r/ Pan l R moval Tool

• Sock t S t

1-800-221-0932

www.metraonline.com

TOOLS REQUIRED:

APPLICATIONS

LINCOLN Town Car

2003-2011

WIRING AND ANTENNA CONNECTIONS (Sold Separately)

Har ess:

• 70-5520 - Ford har ess 2003-up

• 70-5521 - Ford amp har ess 2003-up

A te a Adapter:

• Not required

Da h Di a embly

- LINCOLN Town Car 2003-2011 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Kit A embly

- Double DIN Radio Provision . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

- S acked ISO Moun Uni s Provision . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Final A embly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

TABLE OF CONTENTS

95-5810

*Note:

Refer also to the instructions included with the aftermarket radio.

KNOWLEDGE IS POWER

Enhance your installation and fabrication skills by

enrolling in the most recognized and respected

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for more information and take

steps toward a better tomorrow.

95-5810 DASH DISASSEMBLY

LINCOLN TOWN CAR 2003-2011

50 60 70

100

140

180

110

120

RN21

MPH

0.0

MILES

LINCOLN

Disconn ct th n gativ batt ry t r-

minal to pr v nt an accid ntal short

circuit.

R mov (2) 7mm bolts facing upward

abov instrum nt clust r/gaug s.

(Figure A)

Car fully unsnap and r mov dash

pan l surrounding radio and instru-

m nt clust r/gaug s.

(Figure B)

R mov (2) 7mm bolts abov clock

pan l and r mov pan l).

(Figure C)

R mov (4) 7mm bolts s curing radio.

Continue to kit assembly.

95-5810 KIT ASSEMBLY

DOUBLE DIN RADIO PROVISION

Attach th Doubl DIN brack ts to th

aft rmark t radio using th scr ws

suppli d with th radio.

(Figure A)

Plac th Doubl DIN trim plat ov r

th radio fac th n s cur th ntir

ass mbly into th sub dash.

(Figure B)

Continue to final assembly.

*Note: Refer also to the instructions included with the aftermarket radio.

95-5810 KIT ASSEMBLY

STACKED ISO MOUNT UNITS PROVISION

Attach th Doubl DIN brack ts to th

aft rmark t units using th scr ws

suppli d with th units.

(Figure A)

Plac th Doubl DIN trim plat ov r

th unit fac s th n s cur th ntir

ass mbly into th sub dash.

(Figure B)

Continue to final assembly.

*Note: Refer also to the instructions included with the aftermarket radio.

95-5810 FINAL ASSEMBLY

FINAL ASSEMBLY

(A) Strip wire end back 1/2"

B) Twi t end together

C) Solder

D) Tape

Locat th factory wiring harn ss in th dash. M tra r comm nds using th

prop r mating adapt r and making conn ctions as shown. (Isolat and individ-

ually tap off th nds of any unus d wir s to pr v nt l ctrical short circuit.)

R -conn ct th n gativ batt ry t rminal and t st th unit for prop r op ration.

R ass mbl radio and dash ass mbli s in r v rs ord r of disass mbly.

FINAL WIRING CONNECTIONS

Make wiring onne tions using the EIA olor ode hart shown below and the instru tions in luded with the

head unit. Metra re ommends making onne tions as shown below; Strip, Spli e, Solder, Tape. Isolate and

individually tape off ends of any unused wires to prevent ele tri al short ir uit.

METRA / EIA WIRING CODE

12V Ignition / A . . . . . . . . . . Red

12V Batt / Memory. . . . . . . . . Yellow

Ground. . . . . . . . . . . . . . . . . . Bla k*

Power Antenna. . . . . . . . . . . . Blue

Amp Turn-On . . . . . . . . . . . . . Blue / White

Amp Ground. . . . . . . . . . . . . . Bla k / White

Illumination . . . . . . . . . . . . . . Orange

Dimmer . . . . . . . . . . . . . . . . . Orange / White

Right Front (+) . . . . . . . . . . . . Gray

Right Front (-). . . . . . . . . . . . . Gray/ Bla k

Left Front (+) . . . . . . . . . . . . . White

Left Front (-). . . . . . . . . . . . . . White / Bla k

Right Rear (+) . . . . . . . . . . . . Violet

Right Rear (-) . . . . . . . . . . . . . Violet / Bla k

Left Rear (+) . . . . . . . . . . . . . Green

*NOTE: When a Bla k wire is not present, ground radio to vehi le hassis.

All olors may not be present on all leads due to manufa turer’s spe ifi ations.

95-5810

NOTES

95-5810 INSTRUCTIONS
