The Easy flush-mount module for push-
button 4-fold can only be used in conjunc-
tion with the EIB Easy base unit (Article no.
7900 29) or another external EIB Easy set-
ting device.
The Easy flush-mount module for push-
button 4-fold requires a bus line. Informa-
tion on laying the bus line can be found in
the "base unit" operating instructions and
in the ZVEI/ZVEH "Building management
system, Basic principles" handbook.
The relevant norms, guidelines, rules and
regulations of each country apply. Any
work on the installation bus must only be
carried out by qualified electricians. The
device should be protected against mois-
ture, dirt and damage during transporta-
tion, storage and operation. Do not operate
the device beyond the specified technical
data.
Important information
Anleitung_767003.book Seite 16 Dienstag, 15. Oktober 2002 9:36 09
17
The Easy flush-mount module for push-
button 4-fold has the following functions,
the settings for which are made on the
base unit:
- Switching
Switch on by pressing top/left push-but-
ton. Switch off by pressing bottom/right
push-button.
Note
The red LED (status indicator) on the
push-button 4-fold is on while the actu-
ator is enabled.
- Dimming
Switch on by briefly pressing top/left push-
button (< 0.8 s).
Switch off by briefly pressing bottom/right
push-button (< 0.8 s).
Increase light by pressing top/left push-
button for longer (> 0.8 s).
Decrease light by pressing bottom/right
push-button for longer (> 0.8 s).
Note
The red LED (status indicator) on the
push-button 4-fold is on while the actu-
ator is enabled.
Function
Anleitung_767003.book Seite 17 Dienstag, 15. Oktober 2002 9:36 09
18
-Blind
Open blind by pressing top/left push-but-
ton for longer (> 0.8 s).
By briefly pressing top/left push-button
(< 0.8 s), the blind stops opening, or the
slats are opened one by one.
Close blind by pressing bottom/right push-
button for longer (> 0.8 s).
By briefly pressing bottom/right push-but-
ton (< 0.8 s), the blind stops closing, or the
slats are closed one by one.
-Timermode
(The timer mode corresponds to the stair-
case automatic function)
Switch on (e.g. staircase automatic func-
tion) by pressing top/left push-button.
Switch off (e.g. staircase automatic func-
tion) by pressing bottom/right push-but-
ton.
Note
The red LED (status indicator) on the
push-button 4-fold is on while the actu-
ator is enabled.
