MedRx AVANT Stealth A2D Manuel utilisateur

TRAINING MANUAL

This Page Left Intentionally Blank

ADP-I-MADPT-2 MedRx Avant Stealth Training Manual

Effective Date: 10/14/2013

Contents

Introduction…………………………………………………………………………………………....

AVANT™ Stealth Audiometer Software Overview ………………………………………………

AVANT™ Stealth Audiometer Software Options ..………………………………………………

Preparing for Testing ………………………………………………………………………………..

Placing The Earphones On The Patient ………………………………………………………….

Placing the Bone Conductor ….……………………………………………………………………

Performing Audiometric Testing ……………………………………………………………………

Pure Tone Audiometry……………………………………………………………………………....

Speech Audiometry ………………………………………………………………………………….

Hearing Loss Simulator ……………………………………………………………………………..

Master Hearing Aid ………………………………………………………………………………….

Printing ……………………………………………………………………………………………….

Limited Warranty …………………………………………………………………………………….

#0086

www.medrx-usa.com

1200 Starkey Rd., #105, Largo FL 33771 U.S.A.

Toll Free: (888) 392-1234 • (727) 584-9600

Fax: (727) 584-9602 • Email: medrx@medrx-usa.com

MedRx's Authorized Representative in Europe

(Regulatory affairs only)

Emergo Europe, Molenstraat 15

2513 BH The Hague, The Netherlands

ADP-I-MADPT-2 MedRx Avant Stealth Training Manual

Effective Date: 10/14/2013

Introduction

The AVANT Stealth Audiometer represents a new era of PC-based diagnostic audiometry for your office.

This PC-Based system supports current ANSI and IEC audiometric tests. This manual assumes that the

system hardware and software are installed and working properly. Please refer to the MedRx AVANT

Stealth Audiometer Installation Manual for assistance. The AVANT Stealth Audiometer Installation

Manual is included in the original AVANT Stealth Audiometer packaging in both printed and PDF

formats.

The scope of this manual is to get you “up and running” with the AVANT Stealth Audiometer System.

Please consult the interactive Help System within the software for more detailed information of features

and functionality. To access this tool, press the F1 key at any time, or click the Help icon or the menu bar

with your mouse.

ADP-I-MADPT-2 MedRx AVANT Stealth Training Manual Page 4

Effective Date: 10/14/2013

The AVANT Stealth

Audiometer Software

General Overview

The AVANT Stealth Audiometer software can run stand-alone or through the NOAH™ System or the

TIMS®Office System.

Launching the Software

Stand Alone

NOAH and TIMS

1. Launch NOAH.

2. In NOAH 4:

•Click AVANT STEALTH icon on the

toolbar.

3. In NOAH 3:

•Open the Module Selection screen.

•Click the Measurement Tab.

•Double click the AVANT Stealth icon.

1. Double click the AVANT Stealth

shortcut on your Windows Desktop.

ADP-I-MADPT-2 MedRx AVANT Stealth Training Manual Page 5

Effective Date: 10/14/2013

Software Options

Basic Options

Several option screens are available which allow the user to customize the AVANT Stealth Audiometer

Software to meet their needs.

Access these options from the File Menu on

the AVANT Audiometer Main Screen as

shown below.

The Options may also be accessed from

the Audio screen by clicking Options on

the menu as shown below.

The screen shots below detail the Basic Options available in the AVANT Stealth Audiometer software.

The View tab allows you to set the

default appearance of the test screen.

The Audiometry tab sets the look and

behavior of the AVANT Stealth Audiometer.

ADP-I-MADPT-2 MedRx AVANT Stealth Training Manual Page 6

Effective Date: 10/14/2013

Option 1: On the Audiometry Options screen

click Transducers to assign specific

transducers to the audiometer outputs.

Option 2: You can change transducers by

Right-Clicking on any transducer icon on the

Audiometry screen.

The Transducers dialog box will then appear. Select the appropriate transducer for each output.

To add or remove outputs, click Outputs to enable or disable transducer buttons on the

Audiometry screen

The MHA/HLS tab sets the default look and

behavior of the Master Hearing Aid and

Hearing Loss Simulator.

If your system has a Tympanometer

connected, this tab will assist in

configuring the look of the display.

NOTE: Remember, that more information is always available in the Interactive Help System by clicking

the Help Icon or pressing the F1 key.

ADP-I-MADPT-2 MedRx AVANT Stealth Training Manual Page 7

Effective Date: 10/14/2013

Advanced Options

The Advanced Options screen allows you to

configure your system to meet your individual

clinical needs. It also provides MedRx

Technical Support with tools for helping you

troubleshoot technical issues. Access this

screen from the File Menu on the AVANT

Stealth Main Screen as shown to the right.

The key features of each tab are described below. For more in-depth information, consult the interactive

Help system within the software by pressing the F1 key or clicking the Help icon.

The General Tab configures the overall AVANT

Stealth Audiometer behavior with respect to

other Windows programs, specifically NOAH.

Use the Audio Tab to select the proper audio device

for your AVANT Stealth Audiometer. This tab also

provides access to the Windows Audio controls. Note:

The device settings may vary with different computers. Consult

technical support before changing.

If your system has a Video Otoscope, the

Video Tab allows you to select the appropriate

device driver.

If your system has a Tympanometer connected, use

this tab to identify it and ensure the driver and

software that control it are correctly installed.

ADP-I-MADPT-2 MedRx AVANT Stealth Training Manual Page 8

Effective Date: 10/14/2013

Preparing for Testing

Connecting the Peripherals

After you install the software for your AVANT Stealth

Audiometer you need to connect the rest of the

peripherals before testing a patient. (See the AVANT

Stealth Audiometer Installation Manual).

Using the pictures below, locate each of the

accessories and plug them into the labeled jacks on

your Stealth.

The External Power Supply is required to utilize the

built-in 2x20 Watt Amplifiers and the High Frequency

Option.

Insert Earphones TDH-39 or DD45

Earphones HDA 200 (Optional)

High Frequency Operator Mic &

Monitor Speakers (Optional)

Bone Conductor Power Supply USB Cable Patient Response

Switch Talkback Mic

ADP-I-MADPT-2 MedRx AVANT Stealth Training Manual Page 9

Effective Date: 10/14/2013

Placing the Earphones on the Patient

The AVANT Stealth Audiometer standard configuration includes Eartone 3A Insert Earphones. TDH 39

earphones are also available by request. The figures below illustrate how to properly place these

earphones on the patient.

Eartone 3A Insert Earphones

IMPORTANT: The foam tips used for the Eartone 3A earphones are for SINGLE PATIENT USE ONLY.

Do not attempt to wash and re-use them.

1. Place a new set of foam tips on the earphone tubes as shown.

•NOTE: When removing foam tips after use, be sure the clear

plastic tubing nipple remains attached to the long earphone

tube.

2. Carefully compress the tip between your

fingers to allow it to fit into the patient’s

ear canal as shown. Do not roll the tip

between your fingers.

3. Pull up and back on the patient’s pinna to

straighten the ear canal.

4. Place the compressed foam tip deep

within the ear canal.

5. When properly placed, the outer surface

of the insert tip will be flush with the

opening of the ear canal as shown.



ADP-I-MADPT-2 MedRx AVANT Stealth Training Manual Page 10

Effective Date: 10/14/2013
