PCI-DAS08

Analog input and Digital I/O

User’s Guide

Document Revision 4, May, 2005

Your new Measurement Computing product comes with a fantastic extra —

Management committed to your satisfaction!

Refer to www.mccdaq.com/execteam.html for the names, titles, and contact information of each key executive at

Measurement Computing.

Thank you for choosing a Measurement Computing product—and congratulations! You own the finest, and you can now

enjoy the protection of the most comprehensive warranties and unmatched phone tech support. It’s the embodiment of our

two missions:

To offer the highest-quality, computer-based data acquisition, control, and GPIB hardware and software

available—at the best possible price.

To offer our customers superior post-sale support—FREE. Whether providing unrivaled telephone technical and

sales support on our latest product offerings, or continuing that same first-rate support on older products and

operating systems, we’re committed to you!

Lifetime warranty: Every hardware product manufactured by Measurement Computing Corporation is warranted

against defects in materials or workmanship for the life of the product. Products found defective are repaired or replaced

promptly.

Lifetime Harsh Environment Warranty®: We will replace any product manufactured by Measurement Computing

Corporation that is damaged (even due to misuse) for only 50% of the current list price. I/O boards face some tough

operating conditionssome more severe than the boards are designed to withstand. When a board becomes damaged, just

return the unit with an order for its replacement at only 50% of the current list price. We don’t need to profit from your

misfortune. By the way, we honor this warranty for any manufacturer’s board that we have a replacement for.

30 Day Money Back Guarantee: You may return any Measurement Computing Corporation product within 30 days

of purchase for a full refund of the price paid for the product being returned. If you are not satisfied, or chose the wrong

product by mistake, you do not have to keep it. Please call for an RMA number first. No credits or returns accepted

without a copy of the original invoice. Some software products are subject to a repackaging fee.

These warranties are in lieu of all other warranties, expressed or implied, including any implied warranty of

merchantability or fitness for a particular application. The remedies provided herein are the buyer’s sole and exclusive

remedies. Neither Measurement Computing Corporation, nor its employees shall be liable for any direct or indirect,

special, incidental or consequential damage arising from the use of its products, even if Measurement Computing

Corporation has been notified in advance of the possibility of such damages.

HM PCI-DAS08.doc

Trademark and Copyright Information

TracerDAQ, InstaCal, Universal Library, Harsh Environment Warranty, Measurement Computing Corporation, and the

Measurement Computing logo are either trademarks or registered trademarks of Measurement Computing Corporation.

SoftWIRE is a registered trademark of SoftWIRE Technology, Inc.

Windows, Microsoft, and Visual Studio are either trademarks or registered trademarks of Microsoft Corporation.

LabVIEW is a trademark of National Instruments. All other trademarks are the property of their respective owners.

Information furnished by Measurement Computing Corporation is believed to be accurate and reliable. However, no

responsibility is assumed by Measurement Computing Corporation neither for its use; nor for any infringements of patents

or other rights of third parties, which may result from its use. No license is granted by implication or otherwise under any

patent or copyrights of Measurement Computing Corporation.

by any means, electronic, mechanical, by photocopying, recording, or otherwise without the prior written permission of

Measurement Computing Corporation.

Notice

Measurement Computing Corporation does not authorize any Measurement Computing Corporation product

for use in life support systems and/or devices without the written approval of the CEO of Measurement

Computing Corporation. Life support devices/systems are devices or systems which, a) are intended for

surgical implantation into the body, or b) support or sustain life and whose failure to perform can be

reasonably expected to result in injury. Measurement Computing Corporation products are not designed with

the components required, and are not subject to the testing required to ensure a level of reliability suitable for

the treatment and diagnosis of people.

iii

Table of Contents

Preface

About this User's Guide .......................................................................................................................v

What you will learn from this user's guide.........................................................................................................v

Conventions in this user's guide .........................................................................................................................v

Where to find more information........................................................................................................................vi

Chapter 1

Introducing the PCI-DAS08 .............................................................................................................. 1-1

Overview: PCI-DAS08 features ..................................................................................................................... 1-1

Software features............................................................................................................................................ 1-2

Chapter 2

Installing the PCI-DAS08 .................................................................................................................. 2-1

What comes with your shipment? .................................................................................................................. 2-1

Hardware ....................................................................................................................................................................... 2-1

Software......................................................................................................................................................................... 2-1

Documentation............................................................................................................................................................... 2-1

Optional components ..................................................................................................................................................... 2-2

Unpacking the board ...................................................................................................................................... 2-2

Installing the software .................................................................................................................................... 2-3

Installing the hardware ................................................................................................................................... 2-3

Configuring the hardware............................................................................................................................... 2-3

Connecting the board for I/O operations ........................................................................................................ 2-4

Connectors, cables – main I/O connector ...................................................................................................................... 2-4

Field wiring, signal termination and signal conditioning............................................................................................... 2-5

Chapter 3

Programming and Developing Applications .................................................................................. 3-1

Programming languages ................................................................................................................................. 3-1

Packaged application programs...................................................................................................................... 3-1

Register-level programming ........................................................................................................................... 3-1

Chapter 4

Specifications.................................................................................................................................... 4-1

Analog input ................................................................................................................................................... 4-1

Digital input / output ...................................................................................................................................... 4-2

Counter section............................................................................................................................................... 4-2

Power consumption ........................................................................................................................................ 4-3

Environmental ................................................................................................................................................ 4-3

Main connector and pin out............................................................................................................................ 4-3

Preface

About this User's Guide

What you will learn from this user's guide

This user's guide explains how to install, configure, and use the PCI-DAS08 so that you get the most out

of the analog input and digital I/O features.

This user's guide also refers you to related documents available on our web site, and to technical support

resources.

Conventions in this user's guide

For more information on …

Text presented in a box signifies additional information and helpful hints related to the subject matter you

are reading.

Caution! Shaded caution statements present information to help you avoid injuring yourself and

others, damaging your hardware, or losing your data.

<#:#> Angle brackets that enclose numbers separated by a colon signify a range of numbers, such as those

assigned to registers, bit settings, etc.

bold text Bold text is used for the names of objects on the screen, such as buttons, text boxes, and check

boxes. For example:

1. Insert the disk or CD and click the OK button.

italic text Italic text is used for the names of manuals and help topic titles, and to emphasize a word or

phrase. For example:

The InstaCal installation procedure is explained in the DAQ Software Quick Start.

Never touch the exposed pins or circuit connections on the board.

PCI-DAS08 User's Guide About this User's Guide

Where to find more information

The following electronic documents provide information that is relevant to the operation of the PCI-

DAS08.

The Specifications: PCI-DAS08 (the PDF version of Chapter 4 in this guide) is available on our web

site at www.mccdaq.com/pdfs/PCI-DAS08.pdf.

The Register Map for the PCI-DAS08 is available on our web site at

www.mccdaq.com/registermaps/RegMapPCI-DAS08.pdf.

MCC's DAQ Software Quick Start is available on our web site at

www.mccdaq.com/PDFmanuals/DAQ-Software-Quick-Start.pdf.

MCC's Guide to Signal Connections is available on our web site at

www.mccdaq.com/signals/signals.pdf.

The Universal Library User's Guide is available on our web site at

www.mccdaq.com/PDFmanuals/sm-ul-user-guide.pdf.

The Universal Library Function Reference is available on our web site at

www.mccdaq.com/PDFmanuals/sm-ul-functions.pdf.

MCC's Universal Library for LabVIEW™User’s Guide is available on our web site at

www.mccdaq.com/PDFmanuals/SM-UL-LabVIEW.pdf.

This user's manual is also available on our web site at www.mccdaq.com/PDFmanuals/PCI-DAS08.pdf.

Chapter 1

Introducing the PCI-DAS08

Overview: PCI-DAS08 features

This manual explains how to configure, install, and use your PCI-DAS08 board. The PCI-DAS08 is a

multifunction measurement and control board designed to operate in computers with PCI bus accessory

slots.

The PCI-DAS08 board provides the following features:

Eight single-ended 12-bit analog inputs

12-bit A/D resolution

Sample rates of up to 40 kHz

±5V input range

Three 16-bit counters

Seven digital I/O bits (three input, four output)

Connector compatible with Measurement Computing’s ISA-based CIO-DAS08 board

The PCI-DAS08 board is completely plug-and-play compliant, with no switches or jumpers to set.

Configuration is controlled by your system's plug-and-play software. A functional block diagram of the

PCI-DAS08 is shown here.

PCI

Controller

BADR1

Interrupt

Boot

EEPROM

Counter 2

Clock

(33 MHz/8)

Interrupt

Control

Decode/Status

Bus

Timing

Channel Select

Output Clock2

EXT_INT

Controller FPGA and Logic

LOCAL BUS

PCI BUS (5 V, 32-BIT, 33 MHZ)

Input

Port

Control

Input (2:0)

Digital I/O

82C54

16-bit Counters

Input Clock2

Counter 0

Control

Counter 1

Counter 2

Input Clock0

Gate0

Output Clock0

Input Clock1

Gate1

Output Clock1

Gate2

Output Clock2

Output

Port

Output (3:0)

ADC and MUX

Control

10 Volt

Reference

Channel Select

Gain and Offset Cal

Mux

Analog In

8 CH S.E.

Buffer

12-bit, 100 kHz

Start EOC

Buffe

BADR2

A/D

Control

Figure 1-1. PCI-DAS08 block diagram

1-1

PCI-DAS08 User's Guide Introducing the PCI-DAS08

Software features

The following software ships with the PCI-DAS08 free of charge.

InstaCal installation, calibration, and test utility

TracerDAQ™ suite of virtual instruments

SoftWIRE® for Visual Studio® .NET graphical programming

MCC DAQ Components for VS .NET (installed with SoftWIRE® for VS .NET)

For information on the features of InstaCal, TracerDAQ, and SoftWIRE, refer to the DAQ Software

Quick Start booklet that ships with the PCI-DAS08.

1-2

Chapter 2

Installing the PCI-DAS08

What comes with your shipment?

As you unpack your board, make sure each of the items shown below is included:

Hardware

PCI-DAS08

Software

The Measurement Computing Data Acquisition Software CD contains the following software:

InstaCal installation, calibration, and test utility

TracerDAQ™ suite of virtual instruments

SoftWIRE® for VS .NET

SoftWIRE MCC DAQ Components for .NET

Documentation

In addition to this hardware user's guide, you should also receive the DAQ Software Quick Start

(available in PDF at www.mccdaq.com/PDFmanuals/DAQ-Software-Quick-Start.pdf). Please read this

booklet completely before installing any software and hardware.

2-1

Table des matières

Autres manuels Measurement Computing Système d'E/S

Measurement Computing

Measurement Computing USB-DIO96H Manuel utilisateur

Measurement Computing

Measurement Computing PCI-DUAL-AC5 Manuel utilisateur

Measurement Computing

Measurement Computing USB-1208HS-2AO Manuel utilisateur

Measurement Computing

Measurement Computing USB-3105 Manuel utilisateur

Measurement Computing

Measurement Computing USB-1208LS Manuel utilisateur

Measurement Computing

Measurement Computing PCI-PDISO16 Manuel utilisateur

Measurement Computing

Measurement Computing USB-1608FS-Plus-OEM Manuel utilisateur

Measurement Computing

Measurement Computing USB-2404-60 Manuel utilisateur

Measurement Computing

Measurement Computing USB-3102 Manuel utilisateur

Measurement Computing

Measurement Computing PCI-DIO96 Manuel utilisateur

Measurement Computing

Measurement Computing USB-1208FS-Plus Manuel utilisateur

Measurement Computing

Measurement Computing USB-DIO96H Manuel utilisateur

Measurement Computing

Measurement Computing CIO-DIO96 Manuel utilisateur

Measurement Computing

Measurement Computing miniLAB 1008 Manuel utilisateur

Measurement Computing

Measurement Computing PCI-DIO24/LP Manuel utilisateur

Measurement Computing

Measurement Computing USB-3104 Manuel utilisateur

Measurement Computing

Measurement Computing PCI-DAS6013 Manuel utilisateur

Measurement Computing

Measurement Computing PCI-DAS4020/12 Manuel utilisateur

Measurement Computing

Measurement Computing USB-DIO24H/37 Manuel utilisateur

Measurement Computing

Measurement Computing USB-1608FS Manuel utilisateur

Measurement Computing

Measurement Computing USB-3103 Manuel utilisateur

Measurement Computing

Measurement Computing USB 1024ls Mode d’emploi

Measurement Computing

Measurement Computing PCI-DAS1000 Manuel utilisateur

Measurement Computing

Measurement Computing E-DIO24 Manuel utilisateur

Manuels Système d'E/S populaires d'autres marques

WAGO

WAGO 750-344 Manuel utilisateur

Teknim

Teknim TWM-1887 Mode d’emploi

Intelligent Appliance

Intelligent Appliance IA-2662-E Manuel utilisateur

BERGHOF

BERGHOF ECC DIO 16/16 Mode d’emploi

Advantech

Advantech PCM-27J3AU Manuel d'installation et d'exploitation

Festo

Festo CP-E08-M12-CL Manuel utilisateur

Hitachi

Hitachi HX-RIO3 Series Manuel utilisateur

NUUO

NUUO SCB-A08 Manuel utilisateur

M-system

M-system R3Y-RS8 Manuel utilisateur

jablotron

jablotron JB-110N Manuel utilisateur

Omron

Omron SYSMAC C200H Manuel utilisateur

DOLD

DOLD SAFEMASTER M Manuel utilisateur

ABB

ABB OPT-MF-001 Manuel utilisateur

Omron

Omron SYSMAC C2000H Manuel utilisateur

Helmholz

Helmholz TB20 Manuel utilisateur

ICP DAS USA

ICP DAS USA tM-AD2 Manuel utilisateur

Automationdirect.com

Automationdirect.com DL305 Manuel utilisateur

WAGO

WAGO I/O-SYSTEM 750 Manuel utilisateur
