McCulloch TRIMMAC Manuel utilisateur

GB Operator!s manual 2-13

SEBruksanvisning 14-25

DKBrugsanvisning 26-38

FIKäyttöohje 39-51

NOBruksanvisningen 52-63

FRManuel d!utilisation 64-77

NL Gebruiksaanwijzing 78-91

ITIstruzioni per l!uso 92-105

ES Manual de instrucciones 106-119

DE Bedienungsanweisung 120-133

PTInstruções para o uso 134-147

HU Használati utasítás 148-160

PL Instrukcja obsĝugi 161-174

EE Käsitsemisõpetus 175-187

LVLieto"anas pamÛcďba 188-200

LT Naudojimosi instrukcijos 201-213

SKNávod na obsluhu 214-226

HRPriruìnik 227-238

SINavodila za uporabo 239-251

CZNávod k pou#ití 252-264

RO InstrucŇiuni de utilizare 265-277

BGəɣɓɗɋɗɍɚɛɋɗ ɐɉ

Ɏɓɚɘɔɗɉɛɉɟɑɨ 278-295

RU əɜɓɗɋɗɍɚɛɋɗ ɘɗ

ɦɓɚɘɔɜɉɛɉɟɑɑ 296-307

GROǰǳǯȌǱǿ ȅǾȋȀǱȇǿ 308-319

TR Kullanõm kõlavuzu 320-332

LT25NCOP

TRIMMAC

IDENTIFICATION (WHAT IS WHAT?)

Assist Handle

Shield

Trimmer

Head

Shaft

Muffler

Fuel Mix Fill Cap

Starter Handle

ON/OFF Switch

Throttle Trigger

Choke Lever

Spark Plug

Locking Sleeve

Assembly

Primer Bulb

Manual

Wrench

IDENTIFICATION OF SYMBOLS

A. WARNING! This trimmer can be dangerous! Careless or improper use can cause

serious or even fatal injury.

B. Read and understand the instruction manual before using the trimmer.

C. With this handle, only use trimmer head. Never use blades or flailing devices with this

tool.

D. WARNING! The trimmer line can throw objects violently. You can be blinded or

injured. Always wear eye protection.

E. Always use:

Ear protection

Protective glasses or visor

F. Assist handle to be positioned only below the arrow.

G. The operator of the machine must insure that no one comes within a 15 meter radius

while working. When several operators are working within the same area a safety dis-

tance of at least 15 meters must be observed.

H. Use unleaded or quality leaded petrol and two--stroke oil mixed at a ratio of 2.5%.

I. Engine ON/OFF Switch.

J. Guaranteed sound power level according to Directive 2000/14/EC

K.Sound pressure level at 7,5 meters

D E

SAFETY RULES

WARNING: When using gardening

appliances, basic safety precautions should al-

ways be followed to reduce the risk of fire and

serious injury. Read and follow all instructions.

This power unit can be dangerous! Operator is

responsible for following instructions and warn-

ings on unit and in manual. Read entire instruc-

tion manual before using unit! Be thoroughly fa-

miliar with the controls and the proper use of the

unit. Restrict the use of this unit to persons who

read, understand, and follow instructions and

warnings on unit and in manual. Never allow

children to operate this unit.

SAFETY INFORMATION

ON THE UNIT

INSTRUCTION

MANUAL

DANGER: Never use blades, wire, or

flailing devices. This unit is designed for line

trimmer use only. Use of any other accessories

or attachments will increase the risk of injury.

WARNING: Trimmer line throws ob-

jects violently. You and others can be blinded/

injured. Wear safety glasses and leg protec-

tion. Keep body parts clear of rotating line.

Keep children, bystanders, and animals 15 me-

ters away. If approached stop unit immediately.

If situations occur which are not covered in

this manual, use care and good judgement. If

you need assistance, contact your authorized

service dealer.

OPERATOR SAFETY

WARNING: This machine produces

an electromagnetic field during operation. Under

some circumstances, this field may interfere

with active or passive medical implants. To re-

duce the risk of serious or fatal injury, we recom-

mend persons with medical implants to consult

their physician and the medical implant

manufacturer before operating this machine.

SDress properly. Always wear safety

glasses or similar eye protection when op-

erating, or performing maintenance, on

your unit (safety glasses are available).

Eye protection should be marked Z87.

SAlways wear face or dust mask if operation

is dusty.

SAlways wear heavy, long pants, long

sleeves, boots, and gloves. Wearing safety

leg guards is recommended.

SAlways wear foot protection. Do not go

barefoot or wear sandals. Stay clear of

spinning line.

SSecure hair above shoulder length. Secure

or remove loose clothing or clothing with

loosely hanging ties, straps, tassels, etc.

They can be caught in moving parts.

SBeing fully covered also helps protect you

from debris and pieces of toxic plants

thrown by spinning line.

SStay alert. Do not operate this unit when you

are tired, ill, upset or under the influence of al-

cohol, drugs, or medication. Watch what you

are doing; use common sense.

SWear hearing protection.

SMufflers fitted with catalytic converters get

very hot during use and remain so for some

time after stopping. This also applies at idle

speed. Contact can result in burns to the skin.

Remember the risk of fire!

SNever start or run inside a closed room or

building. Breathing exhaust fumes can kill.

SKeep handles free of oil and fuel.

UNIT / MAINTENANCE SAFETY

SDisconnect the spark plug before performing

maintenance except carburetor adjustments.

SLook for and replace damaged or loose

parts before each use. Look for and repair

fuel leaks before use. Keep in good working

condition.

SReplace trimmer head parts that are

chipped, cracked, broken, or damaged in

any other way before using the unit.

SMaintain unit according to recommended pro-

cedures. Keep cutting line at proper length.

SUse only 2 mm diameter line. Never use wire,

rope, string, etc.

SInstall required shield properly before using

the unit. Use only specified trimmer head;

make sure it is properly installed and se-

curely fastened.

SMake sure unit is assembled correctly as

shown in this manual.

SMake carburetor adjustments with lower

end supported to prevent line from contact-

ing any object.

SKeep others away when making carburetor

adjustments.

SUse only recommended accessories and

replacement parts.

SHave all maintenance and service not ex-

plained in this manual performed by an au-

thorized service dealer.

FUEL SAFETY

SMix and pour fuel outdoors.

SKeep away from sparks or flames.

SUse a container approved for fuel.

SDo not smoke or allow smoking near fuel or

the unit.

SAvoid spilling fuel or oil. Wipe up all fuel spills.

SMove at least 3 meters away from fueling

site before starting engine.

SStop engine and allow to cool before re-

moving fuel cap.

SAlways store gasoline in a container ap-

proved for flammable liquids.

CUTTING SAFETY

WARNING: Inspect the area before

each use. Remove objects (rocks, broken

glass, nails, wire, etc.) which can be thrown

by or become entangled in line. Hard objects

can damage the trimmer head and be thrown

causing serious injury.

SUse only for trimming, scalping, mowing

and sweeping. Do not use for edging, prun-

ing or hedge trimming.

SKeep firm footing and balance. Do not over-

reach.

SKeep all parts of your body away from muf-

fler and spinning line. Keep engine below

waist level. A hot muffler can cause serious

burns.

SCut from your right to your left. Cutting on

left side of the shield will throw debris away

from the operator.

SUse only in daylight or good artificial light.

SUse only for jobs explained in this manual.

TRANSPORTING AND STORAGE

SAllow the engine to cool; secure unit before

storing or transporting in vehicle.

SEmpty fuel tank before storing or transport-

ing the unit. Use up fuel left in the carburetor

by starting engine and letting it run until it

stops.

SStore unit and fuel in an area where fuel va-

pors cannot reach sparks or open flames

from water heaters, electric motors or

switches, furnaces, etc.

SStore unit so line limiter cannot accidentally

cause injury. Unit can be hung by the shaft.

SStore the unit out of the reach of children.

SSecure the machine during transport.

SPECIAL NOTICE: Exposure to vibra-

tions through prolonged use of gasoline pow-

ered hand tools could cause blood vessel or

nerve damage in the fingers, hands, and

joints of people prone to circulation disorders

or abnormal swellings. Prolonged use in cold

weather has been linked to blood vessel dam-

age in otherwise healthy people. If symptoms

occur such as numbness, pain, loss of

strength, change in skin color or texture, or

loss of feeling in the fingers, hands, or joints,

discontinue the use of this tool and seek med-

ical attention. An anti-vibration system does

not guarantee the avoidance of these prob-

lems. Users who operate power tools on a

continual and regular basis must monitor

closely their physical condition and the condi-

tion of this tool.

ASSEMBLY

WARNING: Make sure unit is proper-

ly assembled and all fasteners are secure.

Examine parts for damage. Do not use dam-

aged parts.

It is normal for the fuel filter to rattle in the

empty fuel tank.

Finding fuel or oil residue on muffler is normal

due to carburetor adjustments and testing

done by the manufacturer.

SHAFT ASSEMBLY

CAUTION: When assembling shaft, place

the unit on a flat surface for stability.

1. Align grooves on upper and lower shafts.

Upper Shaft

Lower Shaft

Grooves

2. Push the two shafts together until the lower

shaft is fully seated in the upper shaft (the

shafts lock into place).

3. Slide lower locking sleeve assembly over

upper locking sleeve assembly and tight-

en by turning clockwise.

Upper

ocking

Sleeve Assembly

Lower Locking

Sleeve Assembly

NOTE: If locking sleeve assembly will not

tighten, the shafts are not fully seated.

ADJUSTING THE HANDLE

WARNING: When adjusting the assist

handle, be sure it remains above the locking

sleeve assembly and below the mark or arrow

on the shaft.

1. Loosen wing nut on handle.

2. Rotate the handle on the shaft to an up-

right position; retighten wing nut.

ATTACHING THE SHIELD

WARNING: The shield must be prop-

erly installed. The shield provides partial

protection from the risk of thrown objects to

the operator and others and is equipped with

a line limiter which cuts excess line. The line

limiter (on underside of shield) is sharp and

can cut you.

1. Remove nut from shield.

2. Insert bracket into slot on shield.

3. Pivot shield until bolt passes through hole

in bracket.

4. Reinstall nut and tighten securely with

wrench (provided).

Nut

Bracket

Shield

Slot

Wrench

OPERATION

WARNING: Be sure to read the fuel

information in the safety rules before you be-

gin. If you do not understand the safety rules,

do not attempt to fuel your unit. Contact an

authorized service dealer.

FUELING ENGINE

WARNING: Remove fuel cap slowly

when refueling.

This engine is certified to operate on un-

leaded petrol. Before operation, petrol must

be mixed with a good quality 2--cycle air--

cooled engine oil designed to be mixed at a

ratio of 40:1. A 40:1 ratio is obtained by mixing

5 liters of unleaded petrol with 0,125 liter of oil.

DO NOT USE automotive oil or marine oil.

These oils will cause engine damage. When

mixing fuel, follow instructions printed on oil

container. Once oil is added to petrol, shake

container momentarily to assure that the fuel

is thoroughly mixed. Always read and follow

the safety rules relating to fuel before fueling

your unit.

CAUTION: Never use straight petrol in your

unit. This will cause permanent engine dam-

age.

FUEL REQUIREMENTS

Use good quality unleaded petrol. The lowest

recommended octane grade is 90 (RON).

IMPORTANT

Use of alcohol blended fuels (more than 10% al-

cohol) can cause major engine performance

and durability problems.

WARNING: Incorrect use of fuel and/

or lubricants will cause problems such as:

improper clutch engagements, overheat-

ing, vapor lock, power loss, lubrication defi-

ciency, deterioration of fuel lines, gaskets

and internal carburetor components, etc.

Alcohol blended fuels will cause a high ab-

sorption of moisture in the fuel/oil mixture,

causing the separation of oil and fuel.

HOW TO STOP YOUR UNIT

STo stop the engine, move the ON/OFF

switch to the OFF position.

Starting Position

HOW TO START YOUR UNIT

WARNING: The trimmer head will

turn while starting the engine. Avoid any con-

tact with the muffler. A hot muffler can cause

serious burns.

STARTING A COLD ENGINE (or a

warm engine after running out of

fuel)

1. Set unit on a flat surface.

2. Move ON/OFF switch to the ON position.

3. Slowly press the primer bulb 6 times.

4. Move choke lever to FULL CHOKE posi-

tion.

5. Squeeze and hold trigger through all re-

maining steps.

Starter Handle

Primer

Bulb

Choke

Lever

Thottle

Trigger

6. Pull starter rope handle sharply until en-

gine sounds as if it is trying to start, but do

not pull rope more than 6 times.

7. As soon as engine sounds as if it is trying to

start, move choke lever to HALF CHOKE.

8. Pull starter rope sharply until engine runs,

but no more than 6 pulls. If the engine

doesn t start after 6 pulls (at the HALF

CHOKE position), move the choke lever to

the FULL CHOKE position and press the

primer bulb 6 times. Squeeze and hold the

throttle trigger and pull the starter rope 2

more times. Move the choke lever to the

HALF CHOKE position and pull the starter

rope until the engine runs, but no more than

6 pulls. NOTE: If engine still doesn t start,

it is probably flooded. Proceed to START-

ING A FLOODED ENGINE.

9. Once the engine starts, allow it to run 10

seconds, then move the choke lever to

RUN. Allow the unit to run for 60 more

seconds at RUN before releasing the

throttle trigger. NOTE: If engine dies with

the choke lever in the RUN position, move

the choke lever to the HALF CHOKE

position and pull the rope until engine

runs, but no more than 6 pulls.

STARTING A WARM ENGINE

1. Move ON/OFF switch to the ON position.

2. Move the choke lever to the HALF

CHOKE position.

3. Squeeze and hold the throttle trigger.

Keep throttle trigger fully squeezed until

the engine runs smoothly.

4. Pull starter rope sharply until engine runs,

but no more than 5 pulls.

5. Allow engine to run 15 seconds, then move

the choke lever to the RUN position.

NOTE: If engine has not started, pull starter

rope 5 more pulls. If engine still does not run, it

is probably flooded.

STARTING A FLOODED ENGINE

Flooded engines can be started by placing

the choke lever in the RUN position; then, pull

the rope to clear the engine of excess fuel.

This could require pulling the starter handle

many times depending on how badly the unit

is flooded. If the unit still doesn t start, refer to

TROUBLESHOOTING TABLE.

OPERATING INSTRUCTIONS

OPERATING POSITION

Cut from your right to your left.

ALWAYS WEAR:

Long

Pants

Heavy

Shoes

Eye protection

Hearing

protection

WARNING: Always wear eye protec-

tion and hearing protection. Never lean over

the trimmer head. Rocks or debris can rico-

chet or be thrown into eyes and face and

cause blindness or other serious injury.

Do not run the engine at a higher speed than

necessary. The cutting line will cut efficiently

when the engine is run at less than full throttle.

At lower speeds, there is less engine noise and

vibration. The cutting line will last longer and will

be less likely to "weld# onto the spool.

Always release the throttle trigger and allow the

engine to return to idle speed when not cutting.

To stop engine:

SRelease the throttle trigger.

SMove the ON/OFF switch to the OFF posi-

tion.

TRIMMER LINE ADVANCE

Advance line by tapping the bottom of the cut-

ting head lightly on the ground while engine is

running at full speed. The metal line limiter

blade attached to the guard will cut the line to

the proper length.

WARNING: Use only 2 mm diameter

line. Other sizes and shapes of line will not ad-

vance properly and will result in improper cut-

ting head function or can cause serious injury.

Do not use other materials such as wire,

string, rope, etc. Wire can break off during

cutting and become a dangerous missile that

can cause serious injury.

CUTTING METHODS

WARNING: Use minimum speed and

do not crowd the line when cutting around

hard objects (rock, gravel, fence posts, etc.),

which can damage the trimmer head, become

entangled in the line, or be thrown causing a

serious hazard.

SThe tip of the line does the cutting. You will

achieve the best performance and mini-

mum line wear by not crowding the line into

the cutting area. The right and wrong ways

are shown below.

Tip of the Line

Does The Cutting

Right Wrong

Line Crowded Into

Work Area

SThe line will easily remove grass and

weeds from around walls, fences, trees and

flower beds, but it also can cut the tender

bark of trees or shrubs and scar fences.

SFor trimming or scalping, use less than full

throttle to increase line life and decrease

head wear, especially:

SDuring light duty cutting.

SNear objects around which the line can-

wrap such as small posts, trees or fence

wire.

SFor mowing or sweeping, use full throttle for

a good clean job.

TRIMMING -- Hold the bottom of the trimmer

head about 8 cm above the ground and at an

angle. Allow only the tip of the line to make con-

tact. Do not force trimmer line into work area.

Trimming

8 cm above

ground

SCALPING -- The scalping technique removes

unwanted vegetation. Hold the bottom of the

trimmer head about 8 cm above the ground and

at an angle. Allow the tip of the line to strike the

ground around trees, posts, monuments, etc.

This technique increases line wear.

Scalping

MOWING -- Your trimmer is ideal for mowing

in places conventional lawn mowers cannot

reach. In the mowing position, keep the line

parallel to the ground. Avoid pressing the

head into the ground as this can scalp the

ground and damage the tool.

Mowing

SWEEPING -- The fanning action of the rotat-

ing line can be used for a quick and easy

clean up. Keep the line parallel to and above

the surfaces being swept and move the tool

from side to side.

Sweeping

MAINTENANCE

WARNING: Disconnect the spark

plug before performing maintenance except

for carburetor adjustments.

CHECK FOR LOOSE

FASTENERS AND PARTS

SSpark Plug Boot

SAir Filter

SHousing Screws

SAssist Handle Screw

SDebris Shield

CHECK FOR DAMAGED OR

WORN PARTS

Contact an authorized service dealer for re-

placement of damaged or worn parts.

SON/OFF Switch -- Ensure ON/OFF switch

functions properly by moving the switch to

the OFF position. Make sure engine stops;

then restart engine and continue.

SFuel Tank -- Discontinue use of unit if fuel

tank shows signs of damage or leaks.

SDebris Shield -- Discontinue use of unit if

debris shield is damaged.

INSPECT AND CLEAN UNIT AND

LABELS

SAfter each use, inspect complete unit for

loose or damaged parts. Clean the unit and

labels using a damp cloth with a mild deter-

gent.

SWipe off unit with a clean dry cloth.

CLEAN AIR FILTER

A dirty air filter decreases engine perform-

ance and increases fuel consumption and

harmful emissions. Always clean after every

5 hours of operation.

1. Clean the cover and the area around it to

keep dirt from falling into the carburetor

chamber when the cover is removed.

2. Remove parts as illustrated.

NOTE: Do not clean filter in gasoline or other

flammable solvent to avoid creating a fire haz-

ard or producing harmful evaporative emis-

sions.

3. Wash the filter in soap and water.

4. Allow filter to dry.

5. Replace parts.

Air Filter Cover

Air Filter

Button

REPLACE SPARK PLUG

Replace the spark plug each year to ensure

the engine starts easier and runs better. Set

spark plug gap at 0,6 mm. Ignition timing is

fixed and nonadjustable.

1. Twist, then pull off spark plug boot.

2. Remove spark plug from cylinder and dis-

card.

3. Replace with Champion spark

plug and tighten securely with a 19 mm

socket wrench.

4. Reinstall the spark plug boot.

SERVICE AND ADJUSTMENTS

REPLACING THE LINE

1. Press the tabs on the side of the trimmer

head and remove cover and spool.

Tab

4&-<

Cover

Spool

2. Remove any remaining line.

3. Clean dirt and debris from all parts. Re-

place spool if it is worn or damaged.

4. Replace with a pre-wound spool, or re-

place line using a 8 meters length of 2 mm

diameter line.

WARNING: Never use wire, rope,

string, etc., which can break off and become a

dangerous missile.

5. When installing new line on an existing

spool, hold the spool as shown.

6. Bend the line at the midpoint and insert

the bend into the slot in the center rim of

the spool. Ensure line snaps into position

in the slot.

Slot

7. With your finger between the lines, wrap

the lines evenly and firmly around the

spool in a clockwise direction.

8. Position the lines in the guide slots.

Guide slot

9. Place the spool in the cover as shown

below.

10. Insert the ends of the lines through exit

holes in the sides of the cover.

Line exit hole

Cover

11. Reinstall the spool and cover onto the

trimmer head. Push until cover snaps into

place.

CARBURETOR ADJUSTMENT

WARNING: Keep others away when

making idle speed adjustments. The trimmer

head will be spinning during this procedure.

Wear your protective equipment and observe

all safety precautions.

The carburetor has been carefully set at the

factory. Adjustments may be necessary if you

notice any of the following conditions:

SEngine will not idle when the throttle is re-

leased.

Make adjustments with the unit supported so

the cutting attachment is off the ground and

will not make contact with any object. Hold

the unit by hand while running and making ad-

justments. Keep all parts of your body away

from the cutting attachment and muffler.

Idle Speed Adjustment

Allow engine to idle. Adjust speed until engine

runs without stalling (idle speed too slow).

STurn idle speed screw clockwise to in-

crease engine speed if engine stalls or dies.

STurn idle speed screw counterclockwise to

decrease engine speed.

NOTE: When using Aspen 2T fuel, the engine

acceleration may be slower.

Air Filter Cover

Idle Speed Screw

If you require further assistance or are unsure

about performing this procedure, contact an

authorized service dealer.

STORAGE

WARNING: Perform the following

steps after each use:

SAllow engine to cool before storing or trans-

porting.

SStore unit and fuel in a well ventilated area

where fuel vapors cannot reach sparks or

open flames from water heaters, electric

motors or switches, furnaces, etc.

SEmpty fuel tank before storing or transport-

ing the unit.

SStore unit and fuel well out of the reach of

children.

SStore unit with all guards in place. Position

unit so that any sharp object cannot acci-

dentally cause injury.

SEASONAL STORAGE

Prepare unit for storage at end of season or if

it will not be used for 30 days or more.

If your unit is to be stored for a period of time:

SClean the entire unit before lengthy storage.

SStore in a clean dry area.

SLightly oil external metal surfaces.

ENGINE

SRemove spark plug and pour 1 teaspoon of

40:1, 2-cycle engine oil (air cooled) through

the spark plug opening. Slowly pull the

starter rope 8 to 10 times to distribute oil.

SReplace spark plug with new one of recom-

mended type and heat range.

SClean air filter.

SCheck entire unit for loose screws, nuts,

and bolts. Replace any damaged, broken,

or worn parts.

SAt the beginning of the next season, use

only fresh fuel having the proper gasoline to

oil ratio.

OTHER

SDo not store gasoline from one season to

another.

SReplace your gasoline can if it starts to rust.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels McCulloch Tondeuse à gazon

McCulloch

McCulloch ROB R600 Manuel utilisateur

McCulloch

McCulloch M22-46T Manuel utilisateur

McCulloch

McCulloch M40-120 CLASSIC Manuel utilisateur

McCulloch

McCulloch M13597HRB Manuel utilisateur

McCulloch

McCulloch 96041016500 Manuel utilisateur

McCulloch

McCulloch M53-190AREPX Manuel utilisateur

McCulloch

McCulloch M48 Manuel utilisateur

McCulloch

McCulloch PM655HW Guide de configuration

McCulloch

McCulloch M55H53HW Manuel utilisateur

McCulloch

McCulloch 96041018000 Manuel utilisateur

McCulloch

McCulloch ZM4619 BF Manuel utilisateur

McCulloch

McCulloch MC1236ST Manuel utilisateur

McCulloch

McCulloch 96141020600 Manuel utilisateur

McCulloch

McCulloch MC1292RB Manuel du propriétaire

McCulloch

McCulloch BM145B107HRBK Manuel utilisateur

McCulloch

McCulloch ROB S600 Manuel utilisateur

McCulloch

McCulloch Edition 1 Manuel du propriétaire

McCulloch

McCulloch 14592RB Manuel du propriétaire

McCulloch

McCulloch LT2213C Manuel utilisateur

McCulloch

McCulloch ROB S400 Manuel utilisateur

McCulloch

McCulloch ROB R600 Manuel utilisateur

McCulloch

McCulloch 532 43 27-66 Manuel utilisateur

McCulloch

McCulloch M185107H Manuel utilisateur

McCulloch

McCulloch ZM3016 BF Manuel utilisateur

Manuels Tondeuse à gazon populaires d'autres marques

RHINO

RHINO 1958 Manuel utilisateur

Wolf Garten

Wolf Garten Compact plus 40 B Manuel utilisateur

Cub Cadet

Cub Cadet LTX 1045 Manuel utilisateur

Craftsman

Craftsman 917.378461 Manuel utilisateur

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Manuel utilisateur

Challenge

Challenge CH18V2 Instructions de fonctionnement

TALEN TOOLS

TALEN TOOLS AVR HGM30 Manuel utilisateur

DEWEZE

DEWEZE ATM-725 Manuel d'utilisation

Weed Eater

Weed Eater 180083 Manuel utilisateur

Husqvarna

Husqvarna Poulan Pro PP185A42 Manuel utilisateur

Better Outdoor Products

Better Outdoor Products Quick Series Manuel utilisateur

Cub Cadet

Cub Cadet 23HP Z-Force 60 Manuel d'utilisation

MTD

MTD 795, 792, 791, 790 Manuel utilisateur

Toro

Toro Groundsmaster 3505-D Manuel utilisateur

Dennis

Dennis FT 610 Manuel utilisateur

AIRFORCE

AIRFORCE F-15 Gen 3 Manuel utilisateur

MTD

MTD 126-220-000 Manuel utilisateur

Toro

Toro 74806 Manuel utilisateur
