CYCLES OWNER’S MANUAL

H7xi

H7xe

H5x

H3x

R7xi

R7xe

R5x

R3x

U7xi

U7xe

U5x

U3x

3 IMPORTANT PRECAUTIONS

9 HYBRID ASSEMBLY

19 UPRIGHT ASSEMBLY

29 RECUMBENT ASSEMBLY

39 LOCATION & SETUP

41 TROUBLESHOOTING & MAINTENANCE

45 CYCLE OPERATION

65 CYCLE WORKOUTS

71 PRODUCT SPECIFICATIONS

IMPORTANT PRECAUTIONS

SAVE THESE INSTRUCTIONS

When using Matrix Cycles, basic precautions should always be followed. Read all instructions before using this product.

It is the responsibility of the owner to ensure that all users of this product are adequately informed of all warnings and

precautions. If you have any questions after reading this guide, contact Customer Tech Support.

This product is intended for commercial use. To ensure your safety and protect the equipment, read all instructions

before operating.

TO REDUCE THE RISK OF ELECTRICAL SHOCK:

Always unplug the unit from the electrical outlet immediately after using, before cleaning, performing maintenance and putting on or

taking off parts.

DANGER

TO REDUCE THE RISK OF BURNS, FIRE, ELECTRICAL SHOCK OR INJURY TO PERSONS:

• Use this exercise bike for its intended purpose as described in this manual. Do not use attachments that have not been

recommended by the manufacturer.

• Never operate the exercise bike if it is not working properly, or if it has been damaged. Contact Customer Tech Support or the

authorized dealers for examination and repair.

• Do not use the exercise bike without proper footwear. NEVER operate the exercise bike with bare feet.

• Do not wear any clothing that might catch on any moving parts of this exercise bike.

• Keep hands and feet clear at all times from moving parts to avoid injury. Never turn the pedal cranks by hand.

• Do not dismount the exercise bike until the pedals are at a complete STOP.

• Do not attempt to ride the exercise bike in a standing position at high RPMs until you have practiced at slower speeds.

• Do not insert any object, hands or feet into any openings, or expose hands, arms or feet to the drive mechanism or other

potentially moving part of the exercise bike.

• Do not use any equipment that is damaged or has worn or broken parts. Use only replacement parts supplied by Customer

Tech Support or the authorized dealers.

• Do not operate where aerosol (spray) products are being used or when oxygen is being administered.

• Close supervision is necessary when used near children.

• Close supervision is necessary when used by or near people with disabilities.

• Ensure that adjustment levers (seat and handlebar fore-and-aft) are properly secured and do not interfere with range of

motion during exercise.

• Incorrect or excessive exercise may result in serious injury or death. If you experience any kind of pain, including but not

limited to chest pains, nausea, dizziness, or shortness of breath, stop exercising immediately and consult your physician

before continuing.

WARNING

• Do not jump on the unit.

• At no time should more than one person be on unit while in operation.

• This unit should not be used by persons weighing more than specified in the OWNER’S MANUAL SPECIFICATIONS

SECTION. Failure to comply will void the warranty.

• Keep power cord away from heated surfaces. Do not carry this unit by its supply cord or use the cord as a handle.

• Do not use other attachments that are not recommended by the manufacturer. Attachments may cause injury.

• Use the unit only as described in the unit guide and owner’s manual.

• Disconnect all power before servicing or moving the equipment. To clean, wipe surfaces down with soap and slightly damp

cloth only; never use solvents. (See MAINTENANCE)

• The unit should never be left unattended when plugged in. Unplug from outlet when not in use, and before putting on or

taking off parts.

• Do not operate under blanket or pillow. Excessive heating can occur and cause fire, electric shock, or injury to persons.

• At NO time should pets or children under the age of 14 be closer to the unit than 10 feet.

• At NO time should children under the age of 14 use the unit.

• Children over the age of 14 should not use the unit without adult supervision.

• Never operate the unit if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or

immersed in water. Return the unit to a service center for examination and repair.

• To disconnect, turn all controls to the off position, then remove plug from outlet.

• Do not remove the console covers unless instructed by Customer Tech Support. Service should only be done by an

authorized service technician.

• Heart rate monitoring systems may be inaccurate.

• Over exercising may result in serious injury or death.

• If you feel faint, stop exercising immediately.

WARNING

It is essential that your unit is used only indoors, in a climate controlled room. If your unit has been exposed to colder

temperatures or high moisture climates, it is strongly recommended that the unit is warmed up to room temperature before

first time use. Failure to do so may cause premature electronic failure.

CONSULT A PHYSICIAN BEFORE USING THIS EQUIPMENT.

READ OWNER’S MANUAL BEFORE USE.

CAUTION

DEDICATED CIRCUIT AND ELECTRICAL INFO

A “Dedicated Circuit” means that each outlet you plug into should not have anything else running on that same circuit. The

easiest way to verify this is to locate the main circuit breaker box, and turn off the breaker(s) one at a time. Once a breaker has

been turned off, the only thing that should not have power to it are the units in question. No lamps, vending machines, fans,

sound systems, or any other item should lose power when you perform this test.

Non-looped (isolated) neutral/grounding means that each circuit must have an individual neutral/ground connection coming

from it, and terminating at an approved earth ground. You cannot “jumper” a single neutral/ground from one circuit to the next.

ELECTRICAL REQUIREMENTS

For your safety and to ensure good unit performance, the ground on this circuit must be non-looped (isolated). Please refer to

NEC article 210-21 and 210-23. Any alterations to the standard power cord provided could void all warranties of this product.

The 3x, 5x and 7xe bikes are designed to be self-powered and do not require an external power supply source to operate.

Without an external power supply, the console’s start-up time may be delayed. Add-on TV’s and other console accessories will

increase the time needed for start-up. An external power supply will ensure power is provided to the console at all times and is

recommended when add-on accessories are used.

For units with an integrated TV (like the 7xe and 7xi), the TV power requirements are included in the unit. An RG6 quad shield

coaxial cable with ‘F Type’ compression fittings on each end will need to be connected to the cardio unit and the video source.

Additional power requirements are not needed for the add-on digital TV (3x and 5x). For units with an add-on PCTV (3x and

5x), the TV power requirements are separate.

NOTE: ALL UNITS WITH VIRTUAL ACTIVE™ MUST BE POWERED!

110 V UNITS

All Matrix 3x, 5x, 7xe and 7xi 110 V bikes require the use of

a 100-125 V, 60 Hz and a 15 A “Dedicated Circuit”, with a

non-looped (isolated) neutral/ground for power. This outlet

should be a NEMA 5-15R and have the same configuration

as the plug. No adapter should be used with this product.

These bikes can be daisy-chained together with up to 4 units

per 15 A dedicated circuit. Matrix daisy-chain cord adapters

are sold separately.

220 V UNITS

All Matrix 3x, 5x, 7xe and 7xi 220 V bikes require the use of

a 216-250 V, 50 Hz and a 15 A “Dedicated Circuit”, with a

non-looped (isolated) neutral/ground for power. This outlet

should be a NEMA 6-15R and have the same configuration

as the plug. No adapter should be used with this product.

These bikes can be daisy-chained together with up to 4 units

per 15 A dedicated circuit. Matrix daisy-chain cord adapters

are sold separately.

220 NEMA 6-15P

PLUG

110 NEMA 5-15P

PLUG

North American power cord

plugs shown. Depending on

your country, the plug type

may vary.

GROUNDING INSTRUCTIONS

The unit must be grounded. If it should malfunction or

breakdown, grounding provides a path of least resistance

for electric current to reduce the risk of electric shock.

The unit is equipped with a cord having an equipment-

grounding conductor and a grounding plug. The plug

must be plugged into an appropriate outlet that is

properly installed and grounded in accordance with all

local codes and ordinances. If the user does not follow

these grounding instructions, the user could void the

Matrix limited warranty.

ADDITIONAL ELECTRICAL INFO

In addition to the dedicated circuit requirement, the

proper gauge wire must be used from the circuit breaker

box, to each outlet that will have the maximum number

of units running off of it. If the distance from the circuit

breaker box to each outlet, is 100 ft (30.5 m) or less, then

12 gauge wire should be used. For distances greater

than 100 ft (30.5 m) from the circuit breaker box to the

outlet, a 10 gauge wire should be used.

ENERGY SAVING / LOW-POWER MODE

All units are configured with the ability to enter into an

energy saving / low-power mode when the unit has not

been in use for a specified period of time. Additional time

may be required to fully reactivate this unit once it has

entered the low-power mode. This energy saving feature

may be enabled or disabled from within the ‘Manager

Mode’ or ‘Engineering Mode.’

• All video and power outlets must be functional the day of delivery / assembly of the product. The client is responsible

for any additional installation charges associated with return visits.

• Electrical supply may fluctuate in your area. To ensure stable performance of the product, use the proper gauge wire.

WARNING: Failure to follow these specifications can cause damage to your product and

can void the warranty.

Connect this exercise product to a properly grounded outlet only.

Never operate product with a damaged cord or plug even if it is working properly. Never operate any product if it

appears damaged, or has been immersed in water. Contact Customer Tech Support for replacement or repair.

WARNING

DANGER

Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check with a

qualified electrician or serviceman if you are in doubt as to whether the product is properly grounded. Do not modify

the plug provided with the product. If it will not fit the outlet, have a proper outlet installed by a qualified electrician.

ADD-ON PCTV (3X AND 5X)

A 15 A or 20 A “Dedicated Circuit” with a non-looped (isolated) neutral/ground is required. Each PCTV requires at least

1.2 A of current. No more than 12 PCTVs should be used for each 15 A circuit and no more than 16 PCTVs should be

used for each 20 A circuit. The power outlet should have the same configuration as the plug. No adapter should be used

with this product. An RG6 quad shield coaxial cable with ‘F Type’ compression fittings will need to be connected between

the video source and each add-on PCTV unit.

ADD-ON DIGITAL TV (3X AND 5X)

Additional power requirements are not needed for the add-on digital TV. An RG6 quad shield coaxial cable with ‘F Type’

compression fittings will need to be connected between the video source and each add-on digital TV unit.

HYBRID CYCLE ASSEMBLY

There are several areas during the assembly process to which special attention

must be paid. It is very important to follow the assembly instructions correctly and to

make sure all parts are firmly tightened. If the assembly instructions are not followed

correctly, the unit could have parts that are not tightened, possibly leading to a loose fit

or and will seem loose and may cause irritating noises. To prevent damage to the unit,

the assembly instructions must be reviewed and corrective actions should be taken.

Before proceeding, find your unit’s frame serial number located on the front stabilizer

tube as shown. The console serial number is located on a barcode sticker on the

console, near the connection between the console and the mast. The model name of

your product is determined by the combination of the console series (example: 3X)

and the frame type (example: Hybrid Cycle).

ENTER YOUR SERIAL NUMBERS AND MODEL NAME IN THE BOXES BELOW:

» Use the information above for initial setup and when calling for service.

WARNING

FRAME SERIAL NUMBER:

CONSOLE SERIAL NUMBER:

MODEL NAME:

MATRIX

CONSOLE SERIAL NUMBER LOCATION

FRAME SERIAL NUMBER LOCATION

SEAT BACK

ARM REST HANDLEBARS

SEAT FRAME

SEAT BASE

SEAT RAMP

MAIN FRAME

REAR FRAME HANDLE

REAR FRAME COVER

REAR STABILIZER TUBE

SEAT ADJUSTMENT LEVER

PULSE GRIPS / RESISTANCE TOGGLES

CONSOLE

PULSE GRIP HANDLEBARS

CONSOLE MAST

CRANK

PEDALS

FRONT SHROUD COVER

FRONT STABILIZER TUBE

TRANSPORT WHEELS

POWER CORD SOCKET

Autres manuels pour U7xi

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Matrix vélo d'appartement

Matrix

Matrix U3x-01 Manuel utilisateur

Matrix

Matrix R30 Manuel utilisateur

Matrix

Matrix U7X-01 Manuel utilisateur

Matrix

Matrix U7xe-04 Manuel utilisateur

Matrix

Matrix V Series Manuel utilisateur

Matrix

Matrix R3x-01 Manuel utilisateur

Matrix

Matrix H7XE-05 Manuel utilisateur

Matrix

Matrix R1x Manuel utilisateur

Matrix

Matrix Performance Upright Cycle Manuel utilisateur

Matrix

Matrix CXP Manuel utilisateur

Matrix

Matrix CXP Manuel utilisateur

Matrix

Matrix U1x Manuel utilisateur

Matrix

Matrix u7xe-01 Manuel utilisateur

Matrix

Matrix IC-MXIC3B-01 Manuel utilisateur

Matrix

Matrix U3X-05 Manuel utilisateur

Matrix

Matrix MX-U5 Manuel utilisateur

Matrix

Matrix IC5 Manuel utilisateur

Matrix

Matrix IC-MXIC7B-02 Manuel utilisateur

Matrix

Matrix R3XE-01 Manuel utilisateur

Matrix

Matrix ES MATRIX INDOOR CYCLE Manuel utilisateur

Matrix

Matrix H7X-03 Manuel utilisateur

Matrix

Matrix R7XE-02 Bike Manuel utilisateur

Matrix

Matrix R1x Manuel utilisateur

Matrix

Matrix R1x Manuel utilisateur

Manuels vélo d'appartement populaires d'autres marques

Weslo

Weslo Vector 302 Guide de démarrage rapide

TOORX

TOORX BRX85 Manuel utilisateur

Sunny Health & Fitness

Sunny Health & Fitness SF-B121021 Manuel utilisateur

Monark

Monark 827E Manuel utilisateur

Stamina

Stamina 1310 Manuel utilisateur

American Fitness

American Fitness SPR-BK1072A Manuel utilisateur

Cateye

Cateye CS-1000 (CYCLO SIMULATOR) Manuel utilisateur

BH FITNESS

BH FITNESS H9158H Manuel de l'opérateur

Body Sculpture

Body Sculpture BC-7220G Manuel utilisateur

Cateye

Cateye EC-2300 Manuel utilisateur

FYTTER

FYTTER RACER RC MSR Manuel utilisateur

Kikos

Kikos HM-9090M Manuel utilisateur

Pro-Form

Pro-Form 345 Zlx Bike Guide de l'utilisateur

Fuel Fitness

Fuel Fitness SU135-40 Manuel utilisateur

NordicTrack

NordicTrack Gxr 4.2 Bike Manuel utilisateur

Vision Fitness

Vision Fitness U70 Manuel utilisateur

Stamina

Stamina 15-0340A Manuel utilisateur

KIDSFIT

KIDSFIT Cardio Kids 661 Manuel utilisateur
