MasterChef 043-2746-2 Manuel utilisateur
4.7 QT (4.5 L) STAND MIXER
Product no. 043-2746-2
USER MANUAL
Toll free: 1-855-803-9313
IMPORTANT NOTE: Please read the manual carefully before operating your
product. Retain it for future reference.
2
Table of Contents
Product no. 043-2746-2 | Contact us: 1-855-803-9313
Important Safeguards 2
Part Names & Technical Data 4
Using Your Stand Mixer 4
Recipes 7
Caution 8
Cleaning and Maintenance 9
Environmental Protection 10
Warranty 10
When using electrical appliances, basic safety precautions should always be followed including
the following:
1. Read all instructions.
2. To protect against risk of electrical shock, do not put in water or other liquid.
3. This appliance is not intended for use by persons (including children) with reduced physical,
sensory, or mental capabilities, or lack of experience and knowledge, unless they are closely
supervised and instructed concerning use of the appliance by a person responsible for their
safety. Close supervision is necessary when any appliance is used by or near children.
Children should be supervised to ensure that they do not play with the appliance.
4. Turn the appliance OFF, then unplug from the outlet when not in use, before assembling or
disassembling parts and before cleaning. To unplug, grasp the plug and pull from the outlet.
Never pull from the power cord.
5. Avoid contacting moving parts. Keep hands, hair, clothing, as well as spatulas and other
utensils away from beaters during operation to reduce the risk of injury to persons, or damage
to the mixer.
6. Do not operate any appliance with a damaged cord or plug or after the appliance
Important Safeguards
3
Important Safeguards
malfunctions, or is dropped or damaged in any manner. Contact the manufacturer at their
customer service telephone number for information on examination, repair, or adjustment.
7. The use of attachments not recommended or sold by the manufacturer may cause fire,
electric shock or injury.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter.
10. Do not let cord contact hot surface, including the stove.
11. Remove beaters from mixer before washing.
12. This appliance has a polarized plug (one blade is wider than the other). To reduce the risk
of electric shock, this plug will fit in a polarized outlet only one way. If the plug does not fit
fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician.
Do not modify the plug in any way.
13. Do not let stirring accessories touch acidic food or soak in acidic solutions.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
The failure to follow any of the important safeguards and the important instructions for safe
use is a misuse of your kitchen machine that can void your warranty and create the risk of
serious injury.
Note
Product name Model No. Rated voltage Rated frequency Rated power
STAND MIXER
MJ-KM3502WD 120 V 60 Hz 350 W
4.5 L (4.7 QT)
4
Product no. 043-2746-2 | Contact us: 1-855-803-9313
Part Names & Technical DataUsing Your Stand Mixer
Stand mixer
13
2
45
Always make sure mixer is
unplugged andsetting control
is set to OFF(0).
Press mixer release button up. Tilt mixer head up.
Place bowl in bowl base andturn
clockwise until bowl locks into
place.
Insertattachment onto output
shaft and press upwardas far
as possible. Turn the attachment
counter-clockwise, hooking
attachment over pin onshaft.
5
Using Your Stand Mixer
37
10
Remove attachment by turnning
the attachment counter-clockwise
and pull to remove.
9
Remove attachment by pressing
attachment upward as far as
possible. Turn the attachment
clockwise and pull to remove.
Plug mixer into wall outlet.
Select desired speed. When finished, rotate speed
control to O (0). Unplug from
outlet.
Press up on mixer release button.
Tilt mixer head up.
7
7
68
Note
Mixing bowl tools
Your stand mixer will automatically turn o after 15 minutes of continuous operation. This
will avoid any potential safety problems due to prolonged usage.
Before you use the stand mixer and accessories for the first time, thoroughly clean the parts
that come into contact with food. You can only plug in and switch on the appliance after you
correctly assemble the accessories.
Before first use
Auto stop
1. Before switching on your stand mixer, make sure the knob is the O (0) position and then attach
the whisk, beater or dough hook.
2. Up to 500 g (4 cups) of flour plus other ingredients can be processed in the bowl.
3. Follow the recommended quantities, processing time and speed as indicated in user manual. Do
not exceed the suggested processing speed to avoid damage to the machine.
6
Product no. 043-2746-2 | Contact us: 1-855-803-9313
Using Your Stand Mixer
Before you start, make sure that you pick the correct attachment using the information below:
N a m e Purpose
Dough
Hook
Beate r
Whisk
• For making green onion Chinese pancake
• Suggested processing speed: 2
• 1134g water, 1575g flour, some green onion and little salt, 10 min.
• For making cakes, cookies, pies, pastry, mashed potato,
pasta dough, gluten-free bread, and cold butter
• Suggested processing speed: 1–4
• For mixing egg whites, cream, meringues, mousses, and soufflés
• Suggested processing speed: 7
Tips
•To avoid splashing, always increase speed gradually.
•Whisk: before whisking egg whites or cream, make sure that the bowl and the whisk are dry
and free from grease.
•Kneading: use the dough hook to knead yeast dough for bread and pizzas.
•You need to adjust the amount of liquid to form the dough according to the humidity and
temperature condition.
•If you want to re-knead the dough with your stand mixer, press the dough down to the
bottom of the bowl to avoid the dough wrapping around the dough hook. Make sure that you
re-knead the dough within the recommended speed.
Recipes
7
Ingredients:
•500 gflour • 50 g olive oil• 1 teaspoon salt
•1 teaspoon sugar • 7 g yeast •260 mL (approx.1 cup) warm water
1. Add all the dry ingredients to the bowl andturn the rotary knobtospeed 1.
2. Pour in the water and thenthe oil.
3. Switch to speed 2 and continue kneading until one smoothdough ballis formed.
4. Grease a bowl with olive oil.
5. Place the dough ball into the greased bowl and cover with plastic wrap.
6. Let dough rise for 1 hour untilit is doubled in size.
7. Remove the air from the raiseddough.
8. Fold dough into a log shape and fit dough into a loaf pan.
9. Cover loaf pan and let dough rise for 1 hour.
10. Bake inpreheated oven350°F (180°C) for 40 minutes.
Recipes: Breaddough (Hook)
Ingredients:
•3 eggs •150 g butter • 150 gcastor sugar • 150 gflour • 3 gbaking powder
1. Cut the butter into 2 cm (3/4") cubes.
2. Put the butter cubes and sugar in a bowl and mix together at speed 1.
3. Gradually increase the speed from 1 to4.
4. Add the eggs one at a time andkeepmixing at speed 4 until your eggs are mixed in.
5. Fold in baking powder and flour to the mixture and mix at speed 4 until allthe ingredients are
mixed together.
6. Put the batter into a 30 cm long baking pan.
7. Place pan in the middle of the oven.
8. Bake in preheated oven 350°F (180°C) for 30–40 minutes.
Recipe: Cake batter (Beater)
Ingredients:
•340 gcups all-purpose flour, plus extra for rolling
•227 gcold unsalted butter,cutinto2 cm (3/4") cubes.
•1 teaspoon salt • 1 teaspoonsugar • 6to 8tablespoons ice water
1. Put all the dry ingredients to the bowl andturn the rotary knobtospeed to speed 1.
2. Add the cold butter into the dry ingredients and gradually increase the speed from 1 to 3.
Pie pastry (Beater)
8
Product no. 043-2746-2 | Contact us: 1-855-803-9313
RecipesCaution
3. Add 1 tablespoon iced water at a time to the mixture until it forms a crumbly dough. If the dough
doesn't hold together, add a little more water and mix it for a longer time. Do not add too much water,
otherwise, it will make the crust tough.
4. Form the dough into the shape you want and wrap it with plastic wrap.
5. Keep dough in the refrigerator for at least 1 hour and up to 2 days.
6. Rest the dough at room room temperature for a few minutes before rolling and baking.
7. Bake in preheated oven 350°F (180°C) for 25–30 minutes.
Ingredients:
• 4 egg whites • 1 cup (200 grams) superfine or caster sugar
1. Whisk the egg whites at speed 7 until soft peaks are formed.
2. Gradually add the sugar while processing at speed 4 until firm peaks are formed.
3. Spoon the meringue onto a baking tray which is covered with baking paper.
4. Preheat your oven to 220°F (105°C) and place the tray with the meringue in the centre of the oven.
5. Bake the meringues for approximately 1 to 1 1/2 hours until they are dry and crisp.
6. Turn o the oven and dry the meringues in the oven for 1 1/2 hours.
Recipes: Meringue (Whisk)
1. If stand mixer produces unusual smells, smoke, etc., you should immediately turn o power and
stop use.
2. If the stand mixer does not work, please check if the power supply is connected, if the switch is at
the ON position and if fittings are installed in place.
3. If the stand mixer still does not work after checks mentioned above, please consult the designated
repair centre for maintenance.
Caution
If your appliance does not work, check;
That it is plugged in correctly.
That the accessories are correctly locked.
That the multi-function head is locked in a horizontal position.
Your appliance comes with a microprocessor that controls and analyses the operating power. If the
load becomes too high, your appliance will stop automatically. To restart your appliance, turn the rotary
button to the "0" position and remove some of your ingredients. Allow your appliance to cool down for
a few minutes. You can the select the desired speed to complete your preparation.
Cleaning and MaintenanceCircuit Principle Diagram
9
CAUTION: Before you clean the appliance, unplug it.
Refer to the chart below for information on cleaning the parts with water, dishwasher or damp
cloth.
Clean the main unitwith a damp cloth.
Clean the other parts in hot water (<60°C/140°F) with some wash liquid or in a dishwasher
(refer to the table).
Store the appliance andaccessories ina dry place after cleaning.
1.
2.
3.
ACL
ACN
ACL
ACN
M1
M2
CONTROL PCBA
MLift up Switch
1-YEAR LIMITED WARRANTY
This product carries a one (1) year warranty against defects in workmanship and materials. Trileaf
Distribution agrees to replace a defective product free of charge within the stated warranty period,
when returned by the original purchaser with proof of purchase. This product is not guaranteed against
wear or breakage due to misuse and/or abuse.
10
Product no. 043-2746-2 | Contact us: 1-855-803-9313
Environmental ProtectionWarranty
The appliance must not be disposed of with regular household waste.
At the end of its service life, the appliance must be properly delivered to a collection point for
the recycling of electrical and electronic equipment. By collecting and recycling of old
appliances, you are making an important contribution to the conservation of our natural
resources and provide for environmentally sound and healthy disposal.
Made in China
Imported by Trileaf Distribution Trifeuil Toronto, Canada
M4S 2B8
