S420 Barbecue
Assembly Manual
85-3062-2 (G45123) Propane
85-3063-0 (G45124) Natural Gas
1 YEAR LIMITED WARRANTY
Manual Revision #: 12022013 PD
ANS Z21.58b-2012-CSA 1.6b-2012
ANS Z21.58b-2012-CSA 1.6b-2012 ANS Z21.58b-2012-CSA 1.6b-2012
ANS Z21.58b-2012-CSA 1.6b-2012
READ AND SAVE MANUAL FOR FUTURE REFERENCE.
Assemble your grill immediately.
Missing or damaged parts claims must be submitted within 30 days of purchase date.
For product inquiries, parts, warranty and troubleshooting support,
please call 1-855-453-2150.
DANGER
1. If you smell Gas:
a. Shut o gas to the appliance
b. Extinguish any open ame
c. Open lid
d. If odor continues, keep away from
the appliance and immediately
call your gas supplier or your
re department
2. Requires two people to complete the
assembly process.
3. Beware of sharp edges.
WARNING
Failure to follow all of the Manufacturer’s
instructions could result in hazardous res,
explosions, property damage, or serious
personal injury or even death.
Follow all leak check procedures carefully
prior to operation of barbecue, even if grill
was dealer assembled. Do not try to light
this barbecue without reading the Lighting
Instructions section of this manual.
THIS MANUAL MUST REMAIN WITH THE PRODUCT AT ALL TIMES
CAUTION
Read and follow all safety statements,
assembly instructions, use and care
directions before attempting to assemble
and cook.
WARNING
1. Do not store or use gasoline or other
ammable liquids or vapours in the
vicinity of this or any other appliance.
2. An LP cylinder not connected for use shall
not be stored in the vicinity of this or any
other appliance.
WARNING
IN DIRECT SUN, AND IN OPERATION,
YOUR BBQ’S STAINLESS STEEL AND
PAINTED STEEL PARTS CAN BECOME
VERY HOT.
CAUTION
Sharp edges. Wear gloves when assembling
your grill.
THIS BARBECUE IS FOR OUTDOOR USE ONLY
CONTACT CALL CENTRE IF ANY PARTS ARE MISSING
1-855-453-2150
INSTALLER OR ASSEMBLER/CONSUMER
This manual should be kept with the BBQ at
all times.
HEAVY ARTICLE NEEDS 2 TO LIFT
To ORDER non-warranty replacement parts or accessories, or to register your warranty,
please visit us on the web at
www.masterchefbbqs.com
1
TOOLS NEEDED FOR ASSEMBLY
• #2 Phillips screwdriver (long and short)
• ¼” Slotted screwdriver (long and short)
• Adjustable wrench
• Pliers
Before assembling the barbecue, read these
instructions carefully.
Assemble the barbecue on a at, clean surface.
Grill is heavy. You should have at least two people
assemble the barbecue together.
Notes: Do not fully tighten all the nuts during
this initial stage.
Caution:
Sheet metal can cause injury. Wear gloves when installing the grill.
HARDWARE PACK
¼” x 13mm Screw
X 20
Hitch Pin
X 1
#8X3/8” Self Tapping Screw
X 12
Ø7 Fiber Washer
X 8
¼” - 20UNC Nut
X 8
Wheel Spacer
X 2
1 2 3
4 5 6
7
Washer (Wheel)
X 1
KEY # DESCRIPTION PART NUMBER QUANTITY
1 1/4” x 13mm Screw 20120-13013-036 20
2 1/4”-20UNC Nut 31220-13000-036 8
3 #8X3/8” Self Tapping Screw 24200-42008-136 12
4 φ7 Fiber Washer G431-0018-9000 8
5 Wheel Spacer G305-0024-9088 2
6 Hitch Pin G306-0005-9088 1
7 Washer (Wheel) 40300-08000-036 1
2
PARTS LIST PROPANE FOR 8530622 G45123
KEY # QUANTITY DESCRIPTION PART NO.
AA 1 Top Lid Assembly G451-0E00-01
AB 1 Thermometer and bezel G432-000K-01
AC 1 Top Lid Handle G451-0063-01
AD 2 Lid Bumbers-Back G303-0038-01
AE 2 Lid Bumbers-Front G430-00B8-01
AF 2 Screws For Lid G430-0024-01
BA 1 Burner Box Assembly G451-0H00-01
BB 3 Burner G432-B600-01
BC 1 Electrode Set,Main Burners G501-0010-01
BD 2 Burner Brace Assembly G432-0078-01
BE 3 Flame Tamers G430-0005-01
BF 3 Cooking Grates G451-1200-01
BG 1 Warming Rack G430-0003-01
CA 1 Control Panel G451-0064-01
CB 1 Manifold Assembly G451-P200-01
CC 1 Regulator G511-0031-01
CD 3 Bezel, control knob G430-0027-02
CE 3 Control Knob G432-0090-01
CF1 1 Electronic Ignition Assembly G409-0021-A1
CF2 1 Electronic Ignition Button G409-0030-01
CG 1 Grease Cup Hook G305-0043-01
CH 1 Grease Cup G430-0033-02
CI 1 Heat Shield G451-6201-01
DA 1 Cart Side Panel,Right G451-0D00-01
DB 1 Cart Side Panel,Left G451-0C00-01
DC 2 Back Brace G459-1100-01
DD 1 Front Panel G451-0005-02
DE 2 End Caps G431-0004-01
DF 1 Match Holder G401-0079-01
DG 2 Wheel G210-0018-02
DH 1 Wheel Axle G430-0007-01
DI 1 Tank exclusion G430-5402-01
DJ 1 Gas Tank Support G307-0016-01
EA 1 Side Shelf Table(right) G451-0B00-01
EB 1 Side Shelf Fascia(right) G451-0061-01
EC 1 Side Shelf Table(left) G451-0A00-01
ED 1 Side Shelf Fascia(left) G451-0060-01
F1 1 Hardware Pack G451-B023-01
F2 1 Assembly Instructions G451-M023-01
F3 1 Safe Use and Care Manual G451-M018-02
3
EXPLODED DIAGRAM PROPANE FOR 8530622 G45123
AB
CI
AA
AC
EA
EB
CD
DA
CG
CH
DE
DD
DB
DF
EC
ED
CB
CC
DG
DH
BG
BC
AE
AD
DC
CD
CA
BA
BE
BF
DI
DJ
CE
AF
BD
BB
CF1 CF2
CE
HARDWARE
PACK
F1
F2 F3
ASSEMBLY
MANUAL
SAFETY
AND CARE
MANUAL
4
PARTS LIST NATURAL GAS FOR 8530630 G45124
KEY # QUANTITY DESCRIPTION PART NO.
AA 1 Top Lid Assembly G451-0E00-01
AB 1 Thermometer and bezel G432-000K-01
AC 1 Top Lid Handle G451-0063-01
AD 2 Lid Bumbers-Back G303-0038-01
AE 2 Lid Bumbers-Front G430-00B8-01
AF 2 Screws For Lid G430-0024-01
BA 1 Burner Box Assembly G451-0H00-01
BB 3 Burner G432-B600-01
BC 1 Electrode Set,Main Burners G501-0010-01
BD 2 Burner Brace Assembly G432-0078-01
BE 3 Flame Tamers G430-0005-01
BF 3 Cooking Grates G451-1200-01
BG 1 Warming Rack G430-0003-01
CA 1 Control Panel G451-0064-01
CB 1 Manifold Assembly G451-P700-01
CC 1 Natural Gas Hose G501-0099-01
CD 3 Bezel, control knob G430-0027-02
CE 3 Control Knob G432-0090-01
CF1 1 Electronic Ignition Assembly G409-0021-A1
CF2 1 Electronic Ignition Button G409-0030-01
CG 1 Grease Cup Hook G305-0043-01
CH 1 Grease Cup G430-0033-02
CI 1 Heat Shield G451-6201-01
DA 1 Cart Side Panel,Right G451-0D00-01
DB 1 Cart Side Panel,Left G451-0C00-01
DC 2 Back Brace G459-1100-01
DD 1 Front Panel G451-0005-02
DE 2 End Caps G431-0004-01
DF 1 Match Holder G401-0079-01
DG 2 Wheel G210-0018-02
DH 1 Wheel Axle G430-0007-01
EA 1 Side Shelf Table(right) G451-0B00-01
EB 1 Side Shelf Fascia(right) G451-0061-01
EC 1 Side Shelf Table(left) G451-0A00-01
ED 1 Side Shelf Fascia(left) G451-0060-01
F1 1 Hardware Pack G451-B023-01
F2 1 Assembly Instructions G451-M023-01
F3 1 Safe Use and Care Manual G451-M018-02
5
AB
CI
AA
AC
EA
EB
CD
DA
CG
CH
DE
DD
DB
EC
CC
ED
CB
DG
DH
BG
BC
AE
AD
DC
CD
CA
BA
BE
BF
CE
AF
BD
BB
CF1 CF2
CE
DF
EXPLODED DIAGRAM NATURAL GAS FOR 8530630 G45124
HARDWARE
PACK
F1
F2 F3
ASSEMBLY
MANUAL
SAFETY
AND CARE
MANUAL
6
PROPANE MODELS ONLY: NATURAL
GAS MODELS WILL NOT INCLUDE
THE TANK EXCLUSION (DI)
Note: You will need two people for this step.
Assemble the tank exclusion (DI) to the left and
right cart side panels (DA, DB), as shown.
Note: The left cart side panel (DB) will
have large holes on the end of the legs for
assembling the wheel axle (DH).
Note: the tank exclusion should sit in the lower
hole on the left and right side panel.
Note: Turn Cart assembly over. Front panel
should be facing upward.
Assemble the Front Panel (DD) to the Left and
Right Cart Side Panels (DA and DB), as shown.
1
2
ASSEMBLY INSTRUCTIONS
YOU WILL NEED:
3
X 6
DB DA
DI
DI
DA
DB
DD
DA
DI
Front View
Close up
Front side down
7
Note: Turn Cart assembly upside down.
a. Place wheel (DG) and wheel spacer (#5) onto
wheel axle (DH). “Cone” side of wheel should
be against cart side panel, as shown in gure B.
b. Insert wheel axle assembly (DH) through
wheel axle hole in the front and rear, of the left
cart side panel (DB), as shown.
c. To complete wheel assembly, position the
wheel spacer (#5), wheel (DG), wheel washer
(#7) and hitch pin (#6), onto wheel axle (DH),
as shown.
d. Insert end caps (DE) into right cart side panel
(DA).
Assemble the two Back Braces (DC) to the Left
and Right Cart Side Panels (DA and DB),
as shown.
3
4
ASSEMBLY INSTRUCTIONS
876
YOU WILL NEED:
5
X 2
6
X 1
7
X 1
YOU WILL NEED:
1
X 8
DG
DG
DE
DH
Close upClose up
Back view
5
5
6
7
A
DB
DC
DC
DA
C
B
56
7
8
5
Note: TWO PEOPLE required for this step.
Ensure that the regulator hose (CC) (Propane
models only) is hanging outside of cart.
Position the lid and burner box assembly (A&B),
onto the cart assembly (C), and assemble.
ASSEMBLY INSTRUCTIONS
DB
DB
DJ
Close up
PROPANE MODELS ONLY
Assemble the Gas Tank Support (DJ) to the Left
Cart Side Panel (DB).
A
B
DJ
A B
+
C
A
B
BA
DB
6
YOU WILL NEED:
1
X 4
CC
