PRIME 5-BURNER STAINLESS

STEEL PROPANE BARBECUE

ASSEMBLY MANUAL

085-3178-8 / G42602

1YEAR LIMITED WARRANTY

Manual Revision #: 03302021MK

ANS Z21.58-2018 / CSA 1.6-2018

ANS Z21.58-2018 / CSA 1.6-2018 ANS Z21.58-2018 / CSA 1.6-2018

ANS Z21.58-2018 / CSA 1.6-2018

READ AND SAVE MANUAL FOR FUTURE REFERENCE.

Assemble your grill immediately.

Missing or damaged parts claims must be submitted within 30 days of the purchase date.

For product inquiries, parts, warranty and troubleshooting support,

please call 1-855-453-2150.

DANGER

1. If you smell gas:

a. Shut oﬀ gas to the appliance.

b. Extinguish any open ﬂame.

c. Open the lid.

d. If the odour continues, keep away

from the appliance and immediately

call your gas supplier or your ﬁre

department.

2. Requires two people to complete the

assembly process.

3. Beware of sharp edges.

WARNING

Failure to follow all of the Manufacturer’s

instructions could result in hazardous ﬁres,

explosions, property damage, serious

personal injury or even death.

Follow all leak check procedures carefully

before using the barbecue, even if the grill has

been assembled by the dealer. Do not attempt

to light this barbecue without reading the

Lighting Instructions section of this manual.

THIS MANUAL MUST BE KEPT WITH THE PRODUCT AT ALL TIMES

CAUTION

Read and follow all safety statements,

assembly instructions, use and care

directions before attempting to assemble

and cook.

WARNING

1. Do not store or use gasoline or other

ﬂammable liquids or vapours in the

vicinity of this or any other appliance.

2. An LP cylinder not connected for use must

not be stored in the vicinity of this or any

other appliance.

WARNING

WHEN PLACED IN DIRECT SUNLIGHT

OR WHEN IN USE, YOUR BARBECUE’S

STAINLESS STEEL AND PAINTED STEEL

PARTS CAN BECOME VERY HOT.

CAUTION

Sharp edges. Wear gloves when assembling

your grill.

THIS BARBECUE IS FOR OUTDOOR USE ONLY.

CONTACT THE CALL CENTRE IF ANY PARTS ARE MISSING.

INSTALLER OR ASSEMBLER/CONSUMER

This manual must be kept with the barbecue

at all times.

HEAVY ARTICLE: NEEDS 2 TO LIFT

To order non-warranty replacement parts or accessories, or to register your warranty,

please visit us at

www.masterchefbbqs.com

1/4”×18 Screw Assembly

X 2

1/4”-20UNC×13 Screw

X 36

NO.10-24UNC x18 Screw

X 2

Axle Spacer

X 2

NO.8-32UNC×10 Screw

X 2

φ6.5 Washer

X 6

NO.10-24UNC×13 Screw

X 6

NO.10-24UNC Nut

X 2

Hitch Pin

X 2

Wing Nut

X 1

ST4.2×8 Tapping Screw

X 8

Axle Washer

X 2

1 3

KEY # DESCRIPTION PART NUMBER QUANTITY

1 1/4”×18 Screw Assembly G560-3900-9091 2

2 φ6.5 Washer G466-0042-9000 6

3 1/4”-20UNC×13 Screw 20120-13013-036 36

4 NO.10-24UNC×13 Screw 20124-10013-036 6

5 ST4.2×8 Tapping Screw 24200-42008-136 8

6 NO.10-24UNC x18 Screw 20124-10018-036 2

7 NO.10-24UNC Nut 31224-10000-036 2

8 Axle Spacer G305-0024-9088 2

9 Hitch Pin G306-0005-9088 2

10 Axle Washer 40300-08000-036 2

11 NO.8-32UNC×10 Screw 20132-08010-250 2

12 Wing Nut 33300-08000-032 1

HARDWARE PACK

TOOLS NEEDED FOR ASSEMBLY

• #2 Star-head screwdriver (long and short)

• ¼” Slotted screwdriver (long and short)

• Adjustable wrench

• Pliers

Caution:

Sheet metal can cause injury. Wear gloves when installing the grill.

BEFORE ASSEMBLING THIS BARBECUE, READ THE INSTRUCTIONS CAREFULLY.

Assemble the barbecue on a flat, clean surface. Due to the weight of the grill, two people are

recommended to complete the assembly.

PARTS LIST (PROPANE) FOR 085-3178-8 / G42602

KEY # QUANTITY DESCRIPTION PART NO.

AA 1 Top lid assembly G426-5600-01

AB 1 Thermometer G425-5004-01

AC 1 Thermometer bezel G425-5005-01

AD 1 Top lid handle G425-5001-01

AE 2 Top lid handle bezel C404-2002-01

AF 4 Lid bumpers G527-0002-01

AG 2 Top lid screws G425-0006-01

BA 1 Burner box assembly G426-0200-01

BB 5 Main burner G425-5400-01

BC 1 Electrode set, main burner G425-5501-01

BD 4 Carryover assembly G426-0003-01

BE 5 Flame tamer G425-0004-01

BF 1 Left cooking grate G426-0004-01

BG 1 Warming rack G426-0002-01

BH 1 Heat Shield G426-5502-01

BI 1 Grease Cup G430-0033-02

BJ 1 Grease cup hook G305-0043-01

BK 2 Right cooking grate G426-0005-01

CA 1 Control panel G426-0300-01

CB 6 Control knob G425-0003-01

CC 1 Ignitor G432-003D-01

CD 1 Manifold assembly G426-5800-02

CE 1 Side burner valve with regulator G426-5900-01

CF 1 Side burner metal hose G432-1102-01

DA 1 Side shelf table, right G425-0600-01

DB 1 Side shelf fascia, right G425-0700-01

DC 1 Side shelf support brace, right G425-5201-01

DD 1 Side shelf table, left G426-0900-01

DE 1 Side shelf fascia, left G426-1000-01

DF 1 Side shelf support brace, left G425-5301-01

DG 1 Side burner drip pan G421-9102-01

DH 1 Side burner G426-6200-01

DI 1 Side burner electrode set G426-6002-01

DJ 1 Side burner cooking grate G426-6001-01

DK 1 Side burner lid G430-0018-A2

EA 1 Front cart leg with end cap, right ---------- 3 G425-5603-01

EB 1 Rear cart leg with end cap, right -----------4 G425-5604-01

EC 1 Lower brace, right G451-1Y00-01

ED 1 Tank exclusion wire, right G425-5609-01

EE 1 Front cart leg with end cap, left ------------1 G425-5601-01

EF 1 Rear cart leg with end cap, left -------------2 G425-5602-01

EG 1 Lower brace, left G451-1X00-01

EH 2 Upper brace G451-1W00-01

EI 1 Match holder G401-0079-01

EJ 1 Gas tank support G307-0016-01

EK 2 Back brace G432-L600-01

EL 2 Front panel G426-5501-01

EM 2 Tank exclusion wire, rear G425-5608-01

FA 2 Wheel G437-0037-01

FB 2 Wheel axle G425-5606-01

FC 2 Feet G470-4K01-01

G1 1 Hardware pack G426-B002-01

G2 1 Assembly instructions G426-M002-01

G3 1 Safe use and care manual G425-M001-02

EXPLODED DIAGRAM (PROPANE) FOR 085-3178-8 / G42602

EI EJ

HARDWARE

PACK

G2 G3

ASSEMBLY

MANUAL

SAFETY

AND CARE

MANUAL

1YOU WILL NEED:

YOU WILL NEED:

X 4

(1)

(2)

ATTENTION:

Part EG is used for installing

the propane tank in step 22.

ASSEMBLY INSTRUCTIONS

2YOU WILL NEED:

YOU WILL NEED:

X 4

(4)

(3)

ASSEMBLY INSTRUCTIONS

3YOU WILL NEED:

X 4

(3)

(1)

ASSEMBLY INSTRUCTIONS

4YOU WILL NEED:

X 2

YOU WILL NEED:

X 2

(3)

(1)

ASSEMBLY INSTRUCTIONS

YOU WILL NEED:

X 4

(4)

(2)

ASSEMBLY INSTRUCTIONS
