PRIME 3-BURNER

PROPANE BARBECUE

Assembly Manual

85-3135-0 / G32012

1 YEAR LIMITED WARRANTY

ANSI Z21.58-2015 / CSA 1.6-2015

ANSI Z21.58-2015 / CSA 1.6-2015 ANSI Z21.58-2015 / CSA 1.6-2015

ANSI Z21.58-2015 / CSA 1.6-2015

READ AND SAVE MANUAL FOR FUTURE REFERENCE.

Assemble your grill immediately.

Missing or damaged parts claims must be submitted within 30 days of purchase date.

For product inquiries, parts, warranty and troubleshooting support,

please call 1-855-453-2150.

Manual Revision #: 02212019 JC

DANGER

1. If you smell Gas:

a. Shut o gas to the appliance.

b. Extinguish any open ame.

c. Open lid.

d. If odor continues, keep away from

the appliance and immediately

call your gas supplier or your

re department.

2. Requires two people to complete the

assembly process.

3. Beware of sharp edges.

WARNING

Failure to follow all of the Manufacturer’s

instructions could result in hazardous res,

explosions, property damage, serious

personal injury or even death.

Follow all leak check procedures carefully

prior to operation of barbecue, even if grill

was dealer assembled. Do not try to light

this barbecue without reading the Lighting

Instructions section of this manual.

THIS MANUAL MUST REMAIN WITH THE PRODUCT AT ALL TIMES

CAUTION

Read and follow all safety statements,

assembly instructions, use and care

directions before attempting to assemble

and cook.

WARNING

1. Do not store or use gasoline or other

ammable liquids or vapours in the

vicinity of this or any other appliance.

2. An LP cylinder not connected for use shall

not be stored in the vicinity of this or any

other appliance.

WARNING

IN DIRECT SUNLIGHT, AND IN

OPERATION, YOUR BBQ’S STAINLESS

STEEL AND PAINTED STEEL PARTS CAN

BECOME VERY HOT.

CAUTION

Sharp edges. Wear gloves when assembling

your grill.

THIS BARBECUE IS FOR OUTDOOR USE ONLY.

CONTACT CALL CENTRE IF ANY PARTS ARE MISSING.

1-855-453-2150

INSTALLER OR ASSEMBLER/CONSUMER

This manual should be kept with the BBQ at

all times.

HEAVY ARTICLE NEEDS 2 TO LIFT

To ORDER non-warranty replacement parts or accessories, or to register your warranty,

please visit us on the web at

www.masterchefbbqs.com

HARDWARE PACK

1/4’’ - 20 UNC x 50 Screw

X 2

1/4’’ - 20 UNC x 20 Screw

X 16

ST4.2 x 8 Tapping Screw

X 5

No. 10 - 24 UNC Nut

X 1

Wheel Spacer

X 2

Stopper, Lid Hinge

X 2

1/4’’ - 20 UNC x 30 Screw

X 2

No. 10 - 24 UNC x 13 Screw

X 30

1/4’’ - 20 UNC Nut

X 10

Aluminum Washer

X 17

Hitch Pin, Wheel

X 1

Top Lid Spacer

X 2

No. 8 - 32 UNC x 10 Screw

X 6

Hitch Pin, Burner

X 3

Wheel Washer

X 1

Clip, Regulator

X 1

1 3

KEY # DESCRIPTION PART NUMBER QUANTITY

1 1/4’’ - 20 UNC x 50 Screw 20120-13050-036 2

2 1/4’’ - 20 UNC x 30 Screw 20120-13030-036 2

3 1/4’’ - 20 UNC x 20 Screw 20120-13020-036 16

4 No.10 - 24 UNC x 13 Screw 20124-10013-036 30

5 No. 8 - 32 UNC x 10 Screw 20132-08010-250 6

6 ST4.2 x 8 Tapping Screw 24200-42008-136 5

7 1/4’’ - 20 UNC Nut 31220-13000-036 10

8 No.10 - 24 UNC Nut 31224-10000-036 1

9 Aluminum Washer G466-0042-9000 17

10 Hitch Pin, Burner G515-0013-9000 3

11 Wheel Spacer G312-0014-9088 2

12 Hitch Pin, Wheel G306-0005-9088 1

13 Wheel Washer 40300-08000-036 1

14 Stopper, Lid Hinge G320-3004-9191 2

15 Top Lid Spacer G305-0024-9088 2

16 Clip, Regulator G351-0043-9000 1

TOOLS NEEDED FOR ASSEMBLY

• #2 Star-head screwdriver (long and short)

• ¼” Slotted screwdriver (long and short)

• Adjustable wrench

• Pliers

For correct hardware assembly, always position

the lock washer between the screw and the at

washer.

Caution:

Sheet metal can cause injury. Wear gloves when installing the grill.

Lock Washer

Flat Washer

Screw

BEFORE ASSEMBLING THIS BARBECUE, READ THE INSTRUCTIONS CAREFULLY.

Assemble the barbecue on a flat, clean surface. The grill is heavy, two people are

recommended to complete assembly.

PARTS LIST (PROPANE) FOR 85-3135-0 / G32012

KEY # QUANTITY DESCRIPTION PART NO.

AA 1 Top Lid Assembly G320-6501-01

AB 1 Top Lid Handle G320-6301-01

AC 1 Lid Handle Heat Shield G320-5104-01

AD 2 Lid Hinge G320-5101-01

AE 2 Lid Handle Washer G560-0002-01

AF 2 Lid Handle Screw and Washer G432-U300-01

BA 1 Burner Box Assembly G320-5400-01

BB 3 Main Burner G320-0200-01

BC 1 Electrode Set, Main Burner G312-B103-01

BD 2 Carryover Assembly G413-0004-02

BE 3 Flame Tamer G215-0203-01

BF 1 Cooking Grate G305-0006-01

BG 1 Warming Rack G320-6401-01

CA 1 Control Panel G320-6000-01

CB 1 Manifold Assembly G320-6100-01

CC 1 Regulator G311-0503-01

CD 3 Control Knob G320-5302-01

CE 1 Ignitor G206-0701-01

CF 1 Grease Cup Hook G305-0043-01

CG 1 Grease Cup G430-0033-02

CH 1 Gas Tank Heat Shield G320-3003-01

DA 1 Top Cart Leg, Left G320-5601-01

DB 1 Front Cart Leg, Left ------------2 G320-5602-01

DC 1 Rear Cart Leg, Left -------------1 G320-5603-01

DD 1 Top Cart Leg, Right G320-5701-01

DE 1 Front Cart Leg, Right ---------- 4 G320-5702-02

DF 1 Rear Cart Leg, Right -----------3 G320-5703-02

DG 2 Lower Cart Brace G312-B503-01

DH 1 Upper Back Brace G320-5800-01

DI 1 Lower Back Brace G320-5900-02

DJ 1 Front Panel G320-5501-01

DK 2 End Caps G320-5504-01

DL 2 Wheel G206-0025-01

DM 1 Wheel Axle G320-5507-01

DN 1 Match Holder G401-0079-01

DO 1 Tank Exclusion Wire G320-6601-01

DP 1 Gas Tank Support G320-5503-01

DQ 1 Tank Exclusion Wire, Right G215-3803-01

EA 2 Side Shelf G215-1800-01

F1 1 Hardware Pack G320-B008-01

F2 1 Assembly Instructions G320-M012-01

F3 1 Safe Use and Care Manual G320-M012-02

EXPLODED DIAGRAM (PROPANE) FOR 85-3135-0 / G32012

(2)

(1)

(4)

(3)

HARDWARE

PACK

F2 F3

ASSEMBLY

MANUAL

SAFETY

AND CARE

MANUAL

ASSEMBLY INSTRUCTIONS

YOU WILL NEED:

X 2

YOU WILL NEED:

766

X 1

YOU WILL NEED:

X 1

(1)

(2)

(1)

(2)

YOU WILL NEED:

766

X 1

YOU WILL NEED:

X 1

ASSEMBLY INSTRUCTIONS

(4)

(3)

YOU WILL NEED:

X 2

ASSEMBLY INSTRUCTIONS

YOU WILL NEED:

X 6

ASSEMBLY INSTRUCTIONS

YOU WILL NEED:

X 8

ASSEMBLY INSTRUCTIONS

DL 11

YOU WILL NEED:

X 1

12 13

X 1 X 1
