Marshall Electronics

Model No.

V-MD503

Model No.

V-MD434

Triple 5” Rack Mount Monitor

Quad 4.3” Rack Mount Monitor

Operating Instructions

Table of Contents

Product Overview .........................................................................................................................5

Features....................................................................................................................................5

Installation and Accessories .........................................................................................................6

Monitor Front ................................................................................................................................7

Monitor Rear.................................................................................................................................8

Compatible Input Formats ............................................................................................................9

Menu and Navigation..................................................................................................................10

Video Configuration Submenu....................................................................................................10

Marker Configuration Submenu..................................................................................................13

Filter Configuration Submenu.....................................................................................................16

System Configuration Submenu.................................................................................................17

Function Presets Submenu ........................................................................................................18

IMD & Tally Configuration...........................................................................................................19

System Information Submenu ....................................................................................................20

Network Configuration Submenu................................................................................................20

Network Control Page.................................................................................................................22

Status Tab...............................................................................................................................22

Menu Tab................................................................................................................................23

Display Tab.............................................................................................................................29

Keypad Tab.............................................................................................................................30

Network Tab............................................................................................................................31

Global Tab ..............................................................................................................................34

Specifications .............................................................................................................................35

Dimensions.................................................................................................................................36

Maintenance...............................................................................................................................37

Warranty.....................................................................................................................................37

This page intentionally left blank

Product Overview

Marshall Electronics proudly presents the MD series of rack mount monitors that offer a flexible modular solution to

system integration. These new rack-mountable monitors can be configured with a variety of video inputs that can

be "swapped" or interchanged in the field based on your evolving needs and requirements. This eliminates the

need to upgrade or replace equipment when a different input or application is required. This "future proof" solution

provides flexibility and reassurance when necessary, especially in multi-monitor rack mount units.

Features

■High-Resolution 5” and 4.3” Panel

The V-MD503 and V-MD434 feature an all-digital

TFT-MegaPixel active matrix LCD system with

1.15 million pixels. The LCD panels feature a

brightness of 300 cd/m

and 200 cd/m

and

contrast ratios of 6000:1 and 400:1, respectively

making the display ideal in a variety of

environments and lighting conditions.

■Modular Input Design

Each monitor has rear slots to support various

Digital, Optical and Analog video input modules.

■Multi-Format Compatibility

Accepted formats include 480i, 576i, 720p, 1035i,

1080i. 3G/HD/SDI, HDMI, DVI-I, Optical inputs

available as optional Input Modules. Please

contact Marshall Electronics for availability.

■ColorMatch Conversion with Color

Temperature Adjustment

Emulation of SMPTE-C/EBU color space allows

these monitors to replace any broadcast CRT

monitor. Presets include D65, D55 and D93. Bias

and Gain adjustment for each color enables

precise color matching and white balance.

■False Color Filter, and other Advanced

Features

False Color filter, Aspect ratio settings, blue-only

mode, and monochrome mode are a few of the

advanced features which make the V-MD503 and

V-MD434 at home in any broadcast environment.

Pixel-to-Pixel mode also allows native display of

any incoming image format.

■Flexible Screen Markers

A variety of screen markers in 4:3, 16:9, and full

screen modes allow accurate monitoring of the

different aspect ratios used in broadcast

environments.

■User-Definable Function Buttons

Two user-definable function buttons on the front-

panel allow quick access to numerous settings

and features including false color filter, aspect

ratio, screen markers, monochrome mode, color

temperature and more.

Installation and Accessories

Carefully unpack the V-MD503 / V-MD434 monitor and verify that the following items are included:

• V-MD503 / V-MD434 Monitor

• V-PS12-5V-1 Twist Lock Connector

• Operating Instructions

Inspect the unit for any physical damage that may have occurred during shipping. Should there be any damage,

immediately call Marshall Electronics Customer Service at (800) 800-6608. If you are not located within the

continental United States, call +1 (310) 333-0606.

Monitor Front

[Power]

Turn the monitor off or on by pressing the power

button. The LED on the power button is at full

illumination when the monitor is OFF.

[F1 - F2]

Two user-definable function buttons can be used

for direct access to various settings. Functions

are assigned using the on-screen menu

Menu Access

Use the Menu, ▲, ▼, and Select buttons to

display and navigate the on-screen menu.

[BRIGHT, COLOR , CONTRAST]

The BRIGHT, COLOR and CONTRAST buttons

function as Image Adjustment buttons. The

status of each image adjustment parameter is

shown on the top left of the screen, with values

ranging from 0 to 100. Pressing a button once

displays the current value. Pressing a button

twice resets the corresponding adjustment to the

default setting.

Monitor Number

This silkscreened number will indicate the panel

number on the V-MD503 system.

LED Tally

Three LED tally lights (yellow, red, green) are

available above the screen. Each tally light is

controlled by the Tally Connector on the back of

the monitor.

POWER

LED Tally

Access

F1-F2

BRIGHT - COLOR - CONTRAST

Monitor

Number

Note: This image is specific

to the V-MD434 monitor.

The V-MD503 keypad is

turned 90°clockwise.

Monitor Rear



Tally Connector

The LED tally can be activated via the HD-15

connector by connecting the corresponding pin to

ground. A variety of external devices can be

used to perform the contact closure. No

additional power should be supplied to the HD-15

port.



Network Port

The Network Port is used to access the Network

Control Page for the V-MD434 or V-MD503

monitor. Use a regular RJ45 Ethernet cable to

connect the V-MD monitor to your network.

Please see the Network Configuration

Submenu section of this manual for further

connection details.



Service Connector

This is for factory and Upgrade use ONLY.

Please contact Marshall Electronics for further

information on upgrading the V-MD monitor.



Monitor Service Selector

This, in conjunction with the Service Connector,

serves to control which monitor to Service.

Please contact Marshall Electronics before any

attempted service to this monitor.



Power Input

Connect the 12 VDC input to the Twist-Lock

power input connector. Power can be supplied

from the included power supply or from a variety

of DC sources supplying at least 5.0 Amps at 12

Volts.

IMPORTANT: If using a power source other than

the included power supply, be sure that the

polarity of the DC input is correct:

Pin 1: +12 VDC

Pin 2: GND



Module Slot

The V-MD monitor comes with Module Slots for

Marshall Electronics’ line of future proof Input

Modules. Please contact Marshall Electronics for

a list of compatible Input Modules.

Power Input

Tally Connector

Module

Slot

Monitor Service

Selector

Network Port

Service Connector

Note: This image is

specific to the V-

MD434 monitor.

Please refer to the

Specifications

portion of the

manual for Tally

and Power details.

Compatible Input Formats

The following standards are supported by the V-MD434 or V-MD503 monitors and available input modules:

MD-3GSDI-B – 3G/HD/SDI Input Module

SD-SDI –

480i 59.94, 576i 50

HD-SDI –

720p (60 / 59.94 / 50 / 30 / 29.97 / 25)

1080i (60 / 59.94 / 50)

1080p (30 / 29.97/ 25 / 24 / 24sF/ 23.98 / 23.98sF)

3G-SDI – YCbCr (4:2:2) 10 Bit – Level A and B

1080p (60 / 59.94 / 50)

YCbCr/RGB (4:4:4) 10 Bit – Level A and B

1080i (60 / 59.94 / 50)

1080p (30 / 29.97 / 29.97sF / 25 / 25sF / 24 / 24sF / 23.98 / 23.98sF)

MD-HDSDIx2-B – Two-channel HDSDI Input Module with Switched Output

SD-SDI –

480i 59.94, 576i 50

HD-SDI –

720p (60 / 59.94 / 50 / 30 / 29.97 / 25)

1080i (60 / 59.94 / 50)

1080p (30 / 29.97/ 25 / 24 / 24sF/ 23.98 / 23.98sF)

Menu and Navigation

Access the main menu by pushing and holding the MENU button on the front panel of the monitor.

•Step through menu items using the ▲and ▼buttons.

•Choose a submenu or select a menu item by pressing SELECT.

•Return to the previous menu by pressing MENU.

•Exit the main menu by pressing MENU. The menu will automatically time out after 15 seconds.

Only unit screen 1 will have the Network Configuration option available. All network settings can be configured

from unit screen 1.

Video Configuration Submenu
