Marshall M-CT6 Camera-Top Monitor Owner’s Manual

M-CT6

Camera-Top Monitor

Owner’s Manual

Marshall M-CT6 Camera-Top Monitor Owner’s Manual

Thank you for purchasing a Marshall M-CT6 camera-top monitor. The

M-CT6 is a great tool for focusing, composing, and viewing images/video

clips directly from your digital camera/video camera. It is conveniently sized

for easy transportation, and it is perfect for difﬁcult shooting situations.

To obtain the best results with your new M-CT6, please take the time to

read this manual.

CAUTION

• Please use the supplied power sources.

• Do not expose this product to excessive heat or humidity.

• Avoid subjecting the unit to physical shock wherever possible.

• Do not use chemical solutions to clean this unit. Simply wipe with a

clean soft cloth to remove ﬁngerprints or smudges.

Marshall M-CT6 Camera-Top Monitor Owner’s Manual

CONTENTS

PRODUCT OVERVIEW .....................3-4

MONITOR.............................3

REMOTE CONTROL ......................4

CABLES..............................4

MENU OPERATION ...................... 5-8

SPECIFICATIONS..........................9

INCLUDED ACCESSORIES .................. 10

TROUBLESHOOTING ...................... 10

BATTERY COMPATIBILITY .................. 11

MONITOR

1. Volume down or adjust the value setting.

2. Volume up or adjust the value setting.

3. MENU: To activate OSD menu.

4. Selection key to adjust phase directly or

navigate through the ODS menu.

5. Selection key to adjust brightness directly

or navigate through the ODS menu.

6. PC/AV PC. AV switch.

7. Power on/off.

8. Red indicator light.

9. Infrared receiving Window.

10. DC12V input jack

11. HDMI input jack.

12. VGA input jack.

13. 3.5mm earphone jack, AV input jack.

14. 3.5mm headphone jack.

15. Battery on/off switch.

16. Speaker.

17. Battery mount.

14 9 6 1 2 38 7 4 5

17 16

Marshall M-CT6 Camera-Top Monitor Owner’s Manual

REMOTE CONTROL

CABLES

HDMI cable

mini HDMI-to-HDMI

AV Cable

MUTE

Power ON / OFF

Activate OSD menu

Volume UP / adjust value of setting function

Volume DOWN / adjust value of setting function

Selection key / adjust brightness directly

Selection key / adjust phase directly

Aspect ratio switch (4:3/16:9)

Menu Navigation (Flip UP/DOWN)

Menu Navigation (Flip LEFT/RIGHT)

Input Selection

1. Yellow RCA jack for VIDEO 1 input

2. White RCA jack for AUDIO input

3. Yellow RCA jack for VIDEO 2 input

Marshall M-CT6 Camera-Top Monitor Owner’s Manual

MENU OPERATION

After connecting power, the unit will be in standby mode, which is indicated

by a red light. Press the button (power) on the unit or on the remote

control, and the screen on the unit will illuminate in blue when the unit is

operational. Pressing the same button again will return the unit to STANDBY

mode. Push the "PC/AV"button on the unit or the remote control to select

the signal input.

You can press or on the unit or on the remote control to select the

items: COLOR ADJUST MENU FUNCTION SOUND

and conﬁrm by pressing on the remote control or + or - on the unit,

then push on the remote control or + or - on the unit a second time

to adjust the items. Push to exit the OSD after your adjustments are

complete.

Marshall M-CT6 Camera-Top Monitor Owner’s Manual

Color temperature within the OSD is adjustable also. Press on the

remote control or + or - on the unit to select "Color Temp,"then choose to

set color temperature to: 9300 K, 6500 K, or USER or by pressing .

RED, GREEN and BLUE may then be adjusted with + or - to obtain any

custom settings you may require.

Note: when you select “USER,” a mini pop-up box will appear in the right bottom

corner of the OSD (

as pictured above

After selecting "Color"mode on the OSD, use to select and then

push + or - to adjust.

1. Brightness: adjusts the brightness of the image

2. Contrast: adjusts the contrast of image

3. Color Temp: adjusts the color temperature of the image

4. Custom Color Adjustment mode

COLOR

Marshall M-CT6 Camera-Top Monitor Owner’s Manual

ADJUST

Operating Screen Display

1. Auto Conﬁg: adjusts settings automatically

2. H Position: adjusts the picture horizontally

3. V Position: adjusts the picture vertically

4. Phase: adjusts the phase

5. Clock: adjusts the clock, make ﬁeld, and line synchronization

1. Language: sets the displayed language

2. H Position: adjusts the OSD window horizontally

3. V Position: adjusts the OSD window vertically

4. OSD Timeout: adjusts the timeout for the OSD shut-off

5. Transparent: Adjust the transparency level of the OSD screen

Language window

Marshall M-CT6 Camera-Top Monitor Owner’s Manual

FUNCTION

SOUND

1. Reset: resets the monitor to the original factory settings

2. Display Ratio: changes the aspect ratio from 4:3 to 16:9 (4:3 is default)

3. Zoom: increases the image by 10%

4. LR: ﬂip image horizontally (Mirror image)

5. UD: ﬂip image vertically (up / down)

1. Volume: adjusts the monitor or headphone volume

Marshall M-CT6 Camera-Top Monitor Owner’s Manual

SPECIFICATIONS

Display Panel 6.2-inch TFT LCD (1,152,000 pixels)

Resolution 800x480 (VGA)

Upscaled Resolution 1920x1440 (VGA)

Brightness 400 cd/m2

Contrast 500:1

Viewing Angles 75°/75° (Left/Right) 70°/70° (Up/Down)

Video Signal Input 0.7 ~ 1.4Vp-p / 75Ω

VGA Signal Input Horizontal: 30~60KHz Vertical: 60~75Hz

Speaker ≥2.5W/8Ω

3.5mm headphone jack

Color System NTSC: 3.58 / PAL: 4.43

Voltage DC: 12V ± 10%

Signal Inputs PC (VGA), AV1, AV2, HDMI

Power Consumption ≤8w

Working Temperature -10°~75°C / -4°~130°F

Size 170mm (L) x 129mm (W) x 34.5mm (H)

Weight 14 oz. (without battery)

Marshall M-CT6 Camera-Top Monitor Owner’s Manual

10|

INCLUDED ACCESSORIES

TROUBLESHOOTING

• Power AC adapter

• AV cable

• HDMI-to-HDMI cable

• Mini HDMI-to-HDMI cable

• Remote control

• Camera mount

• Battery

• Battery charger

• Operation manual

• Soft pouch

Image is only showing black and white:

Make sure the level of color saturation and brightness are correct.

The power is on but there is no picture:

Check your cable to make sure both ends are secure. Make sure the

AV or VGA cable is tightly connected from the video out connector or

VGA signal output connector. Make sure you are using the standard

power adapter supplied with the monitor.

The colors are incorrect or abnormal:

If any color is missing, check the cables to make sure they are securely

connected. Broken or loose pins in the cable connector can cause a

bad connection.

The remote control does not work:

Check the battery to make sure the battery is installed properly and that

it is not depleted.

If you are still experiencing problems, contact Marshall Electronics

technical support at:

(800) 800-6608 or +1 (310) 333-0606
