USER MANUAL

V-110

Please take time to read these

instructions before starting

to use the scale

Version 1.0 07/19

Contents

Product Specification 3

Safety Instructions 4

Before Using the Scale 5

Operation 6

Error Messages 7

RoHS Compliance 8

Page 2

Product Specification

Thank you for purchasing a Marsden professional veterinary scale. This is a precision

weighing instrument and considerate use will result in many years of accurate weighing.

The scale has a maximum load capacity of 150kg which must not be exceeded.

Model

Marsden V-110

Capacity/Division

150kg x 100g

Units of Measure

Kg/lb

Function Keys

ON/OFF/TARE, HOLD, UNIT

Display

Easy to read LCD display with four active

digits

Operating Temperature

5 to 30°C

Power Supply

2 x AAA batteries

Dimensions

900mm x 500mm

Warranty

One year

Please note: Marsden’s policy is one of continuous development and therefore

we reserve the right to change product specification without notice.

Page 3

Safety Instructions

Before putting this scale into use, please read with care the information given in this user

manual, which contains important instructions for proper installation, use and maintenance

of the device.

Marsden/the manufacturer shall not be liable for damages arising from failure to heed the

following instructions:

•When using electrical components under increased safety requirements, always

comply with appropriate regulations.

•Inappropriate installation/use will render the warranty null and void.

•Ensure the voltage marked on the power supply unit matches your mains supply.

•This product is not waterproof. We do not recommend using the scale in humid,

damp or wet environments.

•Observe the permissible ambient temperatures for use.

•The device meets the requirements for electromagnetic capability. Do not exceed

the maximum values specified in the applicable standards.

If you have any problems, contact Marsden/your local dealer/your service partner.

Cleaning

•Please do not use corrosive liquids or large amounts of water to clean the scale. We

recommend using alcohol-based wipes or similar.

•Always disconnect the scale from the mains power supply before cleaning.

Never disassemble the scale as this may cause malfunction.

Maintenance

•The scale does not require any routine maintenance. However, we recommend

checking the scale’s accuracy at regular intervals. If any inaccuracies occur, please

contact your local dealer or service partner.

•You can book an accuracy check with the Marsden Service team on 01709 364296.

Disposing of the Scale

•This product should not be treated as regular household waste, but should be

handed in to an electrical/electronic equipment recycling center.

Page 4

Before using the Scale

•Marsden V-110 scales consist of a plastic platform. There are three easy to use

function keys: ON/OFF/TARE, HOLD, UNIT.

•The scale can be used in a fixed location or as a portable scale, powered by 2 x AAA

batteries.

•If you require any assistance with using the V-110, call the Marsden team on 01709

364296, quoting model number V-110 and the serial number, which can typically be

found on the underside of the scale.

•Before use, ensure the scale is on a flat surface. An un-level surface for weighing could

result in inaccurate readings.

Page 5

Operation

Switching the Scale on/off

•To switch the V-110 on, press ON/OFF/TARE.

•When the scale shows a line of zeros, it is ready to use.

•To switch the V-110 off, press and hold ON/OFF/TARE.

Using the Hold function

•The Hold function allows you obtain an accurate weight reading, even if the animal

is moving on the scale.

•With the animal on the scale, press HOLD once.

•The weight reading will flash several times, and then display the correct weight for

around six seconds.

•Please note: The scale will automatically power-off after around 6 seconds to save

battery power.

Using the Tare function

•The Tare function allows you to remove unwanted weight from the display, such as

a towel or blanket.

•With the scale switched on, place the item you wish to tare off onto the platform.

•Press ON/OFF once. The display will show zero.

•You can now place your pet on the scale with the towel or blanket, and only the

weight of pet will display.

•Switching the scale off will cancel the tare weight.

Using the Unit function

•To change the unit of measure, press the UNIT button with the animal on the scale.

•The weight on the display will now change between kg and lb.

Page 6

Error Messages

Display

Problem

Solution

Err

Overload

If the total load exceeds

150kg, the display will show

this message. The weight

must be removed

immediately from the scale

to prevent damage.

Page 7

RoHS Compliance

EU Directive 2002/95/EC restrict the use of the 6 substances below in the manufacture of

specified types of electrical equipment.

•The product does not contain any of the restricted substances in concentrations and

applications banned by the directive;

•And for components, the product is capable of being worked on at higher

temperatures required by lead-free soldering.

The restricted substances and maximum allowed concentrations on the homogenous

material are by weight:

Substances Concentration

Lead <0.1%

Mercury <0.1%

PBB (Polybrominated Biphenyls) <0.1%

PBDE (Polybrominated Diphenyl Ethers) <0.1%

Hexavalant Chromium <0.1%

Cadmium <0.1%

Product Conformity

Harmonised Standards to Which Conformity is Declared –

EN 55014-1/EN 55014-2

2011/65/EU –RoHs2.0 Directive

2002/96/EC –WEEE Directive

Page 8

Tel: +44 (0) 1709 364296 / +44 (0) 800 169 2775

Fax: +44 (0) 1709 364293

E-mail: [email protected]

Manufacturing and Distribution:

Unit 7, Centurion Business Park,

Coggin Mill Way,

Rotherham,

S60 1FB

Head Office:

Unit 1, Genesis Business Park,

Sheffield Road,

Rotherham

S60 1DX

www.marsden-weighing.co.uk
