Model

HG5000

Retain This

Manual for

Reference

01012014

OWNER'S

MANUAL

MARCY ECLIPSE HG5000

DELUXE

HOME GYM

TABLE OF CONTENTS

BEFORE YOU BEGIN...................................................................................... 1

IMPORTANT SAFETY NOTICES..................................................................... 2

HARDWARE PACK……….....…....................................................................... 4

ASSEMBLY INSTRUCTIONS........................................................................... 7

WEIGHT RESISTANCE CHART....................................................................... 26

PARTS LIST………………………………………………………………………….. 27

WARRANTY.................................................................................................… 28

ORDERING PARTS......................................................................................... 28

BEFORE YOU BEGIN

Thank you for selecting the MARCY Eclipse HG5000 Deluxe Home Gym. For your

safety and benefit, read this manual carefully before using the equipment. As a

distributor, we are committed to provide you complete customer satisfaction. If you

have any questions, or find there are missing or damaged parts, we guarantee you

complete satisfaction through direct assistance. To avoid unnecessary delays,

please contact our customer service department, Monday to Friday 9am – 5pm

GMT + 1 hour.

E mail: service.international@tunturi-fitness.com

Supplied by

Tunturi Fitness B.V.

www.tunturi-fitness.com

E mail: info@tunturi-fitness.com

IMPORTANT SAFETY NOTICE

PRECAUTIONS

This exercise machine is built for optimum safety. However, certain precautions apply whenever

you operate a piece of exercise equipment. Be sure to read the entire manual before you

assemble or operate your machine. In particular, note the following safety precautions:

1. Keep children and pets away from the machine at all times. DO NOT

leave children unattended in the same room with the machine.

2. Only one person at a time should use the machine.

3. If the user experiences dizziness, nausea, chest pain, or any other abnormal

symptoms, STOP the workout at once. CONSULT A PHYSICIAN

IMMEDIATELY.

4. Position the machine on a clear, leveled surface. DO NOT use the machine

near water or outdoors.

5. Keep hands away from all moving parts.

6. Always wear appropriate workout clothing when exercising. DO NOT wear

robes or other clothing that could become caught in the machine. Running

or aerobic shoes are also required when using the machine.

7. Use the machine only for its intended use as described in this manual. DO

NOT use attachments not recommended by the manufacturer.

8. Do not place any sharp object around the machine.

9. Disabled person should not use the machine without a qualified person or

physician in attendance.

10. Before using the machine to exercise, always do stretching exercises to

properly warm up.

11. Never operate the machine if the machine is not functioning properly.

12. A spotter is recommended during exercise.

13. Do not intend to insert weight selector pin while the weight stack or top plate

is in elevated position.

14. Be certain the weight Selector Pin is completely inserted.

15. Never use dumbbells or other means to increase the weight resistance. Use only weight

plates provided by manufacturer.

16. This machine is designed and intended for home and consumer use only, not for

commercial use.

CARE AND MAINTENANCE

1. Lubricate moving parts with WD-40 or light oil periodically.

2. Inspect and tighten all parts before using the machine.

3. The machine can be cleaned using a damp cloth and mild non-abrasive detergent.

DO NOT use solvents.

4. Maximum user’s weight: 136kgs.

WARNING: BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT YOUR

PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF

35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL

INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. TUNTURI FITNESS BV

ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE

SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT.

SAVE THESE INSTRUCTIONS. 2

WARNING LABEL PLACEMENT

The warning labels shown here have been placed on the Rear Stabilizer and Upper Frame. If the labels are missing or

illegible, please contact customer service by email: service.international@tunturi-fitness.com for replacements. Apply

the labels in the location shown.

HARDWARE PACK

NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.

HARDWARE PACK

NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.

HARDWARE PACK

ASSEMBLY INSTRUCTION

Tools Required for Assembling the Machine: Two Adjustable Wrenches and Allen

Wrenches

NOTE: It is strongly recommended that this machine be assembled by two or more

people to avoid possible injury.

STEP 1 (See Diagram 1)

A.) Insert two Guide Rods (#16) into the holes on the Rear Stabilizer (#15). Secure each

Guide Rod with one M10 x ¾” Allen Bolt (#78) and Ø ¾” Washer (#92) from the

bottom. Attach two Rubber Bumpers (#55) onto top of the two Guide Rods and slide

down to the stopper on the Guide Rods.

B.) Attach the Vertical Frame (#4) onto the Rear Base Frame (#14). Secure it with two

M10 x 2 ¾” Carriage Bolts (#90), one 4 ¾” x 2 ¾” Bracket (#25), two ∅¾” Washers

(#92), and two M10 Aircraft Nuts (#91). DO NOT tighten the Nuts and Bolts yet.

C.)Attach the Butterfly Base (#13) to the Rear Base Frame (#14). Attach the Front Base

Frame (#12) to the Butterfly Base (#13). Align the holes and secure them together

with two M10 x 2 ¾” Carriage Bolts (#90) from the bottom, two M10 x 3 ¾” Carriage

Bolts (#89) from the side of Butterfly Base, four Ø ¾” Washers (#92), and four M10

Aircraft Nuts (#91).

D.)Attach the Rear Base Frame (#14) to the Rear Stabilizer (#15). Secure them together

with two M10 x 3 ¾” Allen Bolts (#82), two Ø ¾” Washers (#92), and one 1 5/8” x 1 ½”

Bracket (#26).

E.) Attach the Foot Plate (#17) to the Front Base Frame (#12). Align the holes and insert

the 13” Foot Plate Axle (#18) through the holes.

F.) Slide 13 Weight Plates (#45) onto the Guide Rods. Make sure the deep groves on all

Plates face down and toward the back. Insert the Selector Rod (#28) through the

center hole on the Weight Plates. Slide the Weight Selector Stem (#46) onto the

Guide Rods.

G.)Use the Weight Plate Selector Pin (#42) to select desired number of Weight Plates to

exercise. NOTE: Each Plate weights approximately 6.8kg. Please refer to the Weight

Resistance Chart on page 26.

DIAGRAM 1
