Marathon Power SNMP Series Manuel utilisateur

SNMP Card

User’s Manual

for the SNMP-CY54-03 and SNMP-CY54-04 SNMP Cards

Table of Contents

Introduction.................................................................................................................... 8

Features.............................................................................................................. 8

Web-Enabled ...................................................................................................... 8

Notifications ........................................................................................................ 8

Scheduling .......................................................................................................... 8

Security............................................................................................................... 8

Upgrading ........................................................................................................... 8

Supported Protocols ........................................................................................... 9

NMS,................................................................................................................... 9

Supported Protocols ........................................................................................... 9

Supported MIB Objects....................................................................................... 9

Free Downloadable Software from our website............................................................. 9

Netility ................................................................................................................. 9

SNMPView.......................................................................................................... 9

iMConfig.............................................................................................................. 9

ClientMate........................................................................................................... 9

SMS Server Software ....................................................................................... 10

SNMP card UPS Installation........................................................................................ 11

LED Indications on the card.............................................................................. 12

Connecting to the SNMP cards ................................................................................... 13

Connecting to the SNMP-CY54-03 Card .......................................................... 13

Connecting to the SNMP-CY54-04 Card .......................................................... 13

Configuration of the SNMP Cards ............................................................................... 14

1. Configuration/Network .................................................................................. 14

2. Configuration/SNMP (Uniquely Identifying Your UPS).................................. 15

3. Configuration/Email ...................................................................................... 15

4. Configuration/System Time........................................................................... 18

5. Creating a Master configuration File ............................................................. 20

Using the Netility Configuration Software .................................................................... 21

SNMP Card Firmware Upgrading using Netility ................................................ 25

Web UI Structure ......................................................................................................... 26

Information Tab ........................................................................................................... 27

System Status................................................................................................... 27

System Information.................................................................................... 27

Network Status .......................................................................................... 27

Basic Information .............................................................................................. 27

Current Status................................................................................................... 27

Input Status ............................................................................................... 27

Output Status............................................................................................. 27

Battery Status ............................................................................................ 27

Event Log and Event Timer (Only Available on the CY54-04 Model) ........ 27

Summary (Only Available on the CY54-04 Model) .................................... 27

Contact Status (Only Available on the CY54-04 Model) ............................ 27

Remote Control................................................................................................. 28

UPS Testing .............................................................................................. 28

Miscellaneous (Control Commands) (Only Available on the CY54-03

Model)........................................................................................................ 28

Dry Contact Status and Configuration (Only Available on the CY54-04

Model)........................................................................................................ 28

Meter/Chart (Only Available on the CY54-03 Model)........................................ 28

Configuration Tab ........................................................................................................ 29

UPS Configuration (CY54-03 Model) ................................................................ 29

UPS Properties.......................................................................................... 29

Date of Last Battery replacement(mm/dd/yyyy)......................................... 29

Test Log - UPS Testing (CY54-03 Model Only)......................................... 30

Critical Battery Capacity (%) (Only Available on the CY54-03 Model)....... 30

UPS On/Off Schedule (Only Available on the CY54-03 Model) ........................ 30

Wake On Lan (Only Available on the CY54-03 Model).............................. 30

Warning Threshold Levels (Only Available on the CY54-03 Model) .......... 31

UPS Configuration (CY54-04 Model) ................................................................ 32

UPS Properties.......................................................................................... 32

Test Log (CY54-04 Model) ........................................................................ 34

Maintenance (Only Available on the CY54-04 Model) ...................................... 34

Battery Charging Temperature Compensation .......................................... 34

Battery Voltage Low Warning .................................................................... 34

External Fan On/Off by Temperature ........................................................ 34

Battery Test Options .................................................................................. 34

Inverter On/Off (Load/Output ONLY) ......................................................... 34

Reset the Event/Timer Counters ............................................................... 34

Change Password ..................................................................................... 34

Transfer Points (Only Available on the CY54-04 Model) .................................. 35

Transfer Point Descriptions (CY54-04 Model) ........................................... 36

Default Transfer Point Settings (CY54-04 Model)...................................... 37

Rebooting the UPS (TRTC Series UPSs) ......................................................... 37

The same procedure above can be rebooted using the front panel controls

on the UPS. ............................................................................................... 37

Network............................................................................................................. 38

Ipv4............................................................................................................ 38

Ipv6............................................................................................................ 38

IP Address ................................................................................................. 38

DNS Server IP ........................................................................................... 38

Modbus on TCP Device ID ........................................................................ 38

Rebooting the SNMP Card ONLY..................................................................... 39

SNMP (Uniquely Identifying the UPS and its Notifications)............................... 40

MIB System ............................................................................................... 40

System Name ............................................................................................ 40

SNMPv1 & SNMPv2 or SNMPv3............................................................... 41

TRAP Notifications..................................................................................... 41

MIB Type ................................................................................................... 41

Email................................................................................................................. 42

Email Settings............................................................................................ 42

Emailing of Power and UPS Events .......................................................... 43

Event Notifications (CY54-03 Model)......................................................... 44

Event Notifications (CY54-04 Model)......................................................... 44

Emailing of Daily Report ............................................................................ 45

Notifications Sent as SMS Notifications..................................................... 46

SMS Server ...................................................................................................... 47

Web/Telnet/FTP – Security Settings................................................................. 48

RADIUS Server Settings................................................................................... 49

System Time..................................................................................................... 50

Rebooting the Card........................................................................................... 50

Language.......................................................................................................... 51

Log Information Tab .................................................................................................... 52

Event Log.......................................................................................................... 52

Data Log ........................................................................................................... 52

Battery Test Log (Only Available on the CY54-03 Model) ................................ 52

UPS Event Log (Only Available on the CY54-04 Model) .................................. 52

Help Tab...................................................................................................................... 53

Search NetAgent .............................................................................................. 53

Serial Port Debug ............................................................................................. 53

Help .................................................................................................................. 53

Save/Restore Settings ............................................................................... 53

Firmware Update Settings ................................................................................ 54

Updating the CY54-03 Card’s Firmware - Important Note ................................ 54

Updating the CY54-04 Card’s Firmware - Important Note ................................ 54

About ......................................................................................................... 55

Password Recovery.......................................................................................... 56

Introduction

The NetAgent 9 SNMP card adds network monitoring and management functions to

your UPS. After plugging the card into your UPS and connecting it to your network, you

can view the UPS’s status and control the UPS by merely entering the card's IP address

into a web browser. The card also offers network management functions via SNMP

NMS (Network Management System).

Features

Save and Restore card configurations

Centralized UPS Monitoring & Management

Real-time UPS monitoring

Scheduling of UPS and Battering Testing

Automatic Event and Data logging.

Easy setup and Firmware updating via the Netility software

Management and configuration via Web Browser or NMS

SNMPv1, SNMPv2C, and SNMPv3 Supported

TRAP, email, and SMS messages for events notifications

Automatically emailing of Daily Reports

Supports SNMP MIB for monitoring & control

Autosensing of Fast Ethernet 10M /100M

Can gracefully shut down computers and servers after installing the ClientMate software

Web-Enabled

The card creates a portal for the UPS that can be accessed using any standard web

browser.

Notifications

When an event such as a power failure or a low battery condition occurs, the card can

notify authorized personnel.

Scheduling

The SNMP-CY54-03 card allows you to automatically set up a schedule to initiate a self-

test.

Security

Supports SSL/TLS, SSH Encryption

The card can be restricted to authorized personnel only.

Upgrading

The firmware is easily updated.

Supported Protocols

The SNMP (Simple Network Management Protocol) is a way to monitor and manage a

network. The card supports SNMPv1, SNMPv2C, SNMPv3, and many SNMP NMS

(Network Management System, i.e., SNMP manager) can retrieve information from the

UPS and control the UPS.

NMS,

The card has its own NMS, called SNMPView. But you can also use other third-party

NMS, such as HP OpenView, by importing its MIB file.

Supported Protocols

TCP/IP, HTTP, HTTPS, SSL, SSH, SMTP, SNTP, DHCP, Telnet, BOOTP, DNS, DDNS,

RADIUS, IPv4, IPv6

Supported MIB Objects

PPC MIB, RFC1628, SNMPv1, SNMPv2, SNMPv3

Free Downloadable Software from our website

Netility is software that helps the user search for all the available NetAgent 9 cards

within your LAN, configure IP addresses and upgrade firmware. Download it at

https://marathon-power.com/s/Netility.rar

SNMPView is an NMS software program used to monitor and control multiple cards.

With SNMPView, you can view a UPS’s location, output status mode, battery capacity,

AC status, battery status, and other parameters of all your UPSs, all in one window.

Plus, you can perform self-tests, send history files, and more. Download it at

https://marathon-power.com/s/SNMPView-v58.rar

iMConfig is software that allows a user to change the same parameter on multiple

cards simultaneously. Please contact Marathon Power at support@marathon-

power.com for the latest version of this software.

ClientMate is shutdown software for PCs and Servers that works with NetAgent 9

cards. When ClientMate, installed on a computer or servers, receives an AC Failure,

battery low, or scheduled shutdown signal from a NetAgent 9 card, it saves the client’s

files and shuts down the system gracefully to avoid a system crash. Download it at

https://marathon-power.com/s/ClientMate-for-Windows-v60.rar

SMS Server Software allows the card to communicate with an SMS Server, enabling

event notifications to be sent via SMS messaging. Please contact Marathon Power at

support@marathon-power.com for the latest version of this software.

To open rar files for free, please install 7-zip on your computer, available at

https://www.7-zip.org/download.html

After installing 7-zip, you maybe give options for using the program, choose File

Manager.

After clicking on the rar file, 7-zip opens. At this point, click on Extract on the upper

lefthand side of the Toolbar. Then save the extracted exe file to your preferred location.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Marathon Power UPS

Marathon Power

Marathon Power Track Series Manuel utilisateur

Marathon Power

Marathon Power vault series Manuel utilisateur

Marathon Power

Marathon Power Sprint Series Manuel utilisateur

Marathon Power

Marathon Power vault series Manuel utilisateur

Marathon Power

Marathon Power TRTC-2004-N1 Manuel utilisateur

Marathon Power

Marathon Power Tri-Athlon ATWS-10003-02 Manuel utilisateur

Marathon Power

Marathon Power TRTC-2002-N1 Manuel utilisateur

Marathon Power

Marathon Power SDRS-0300-H1 Manuel utilisateur

Marathon Power

Marathon Power vault series Manuel utilisateur

Marathon Power

Marathon Power vault series Mode d'emploi

Marathon Power

Marathon Power Athlon SEries Manuel utilisateur

Manuels UPS populaires d'autres marques

Pylontech

Pylontech Victron & Pylontech US5000 Manuel utilisateur

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manuel utilisateur

Mecer

Mecer ME-1000-WTU Manuel utilisateur

Mustek

Mustek PowerMust 530(B) Plus Manuel d'installation et d'exploitation

Emerson

Emerson Liebert NXL series Manuel utilisateur

MAKELSAN

MAKELSAN BOXER SERIES Manuel utilisateur

Block

Block PC-0524-400-0 Manuel utilisateur

CyberPower

CyberPower CP585LCD Manuel utilisateur

Eaton

Eaton 3S Instructions de montage

CyberPower

CyberPower Office Tower Series UPS 1000 Manuel utilisateur

CyberPower

CyberPower BM100 Manuel utilisateur

Best Power

Best Power 610 Manuel utilisateur

Best Power

Best Power Unity/I UT3K Manuel utilisateur

Mustek

Mustek PowerMust 400 Offline Manuel utilisateur

Xantrex

Xantrex Trace 512 UR-UPS Manuel utilisateur

Forza

Forza SL-1501UL Manuel utilisateur

LEGRAND

LEGRAND keor 310081 Manuel utilisateur

ABB

ABB Conceptpower DPA 500 Manuel utilisateur
