Firmware upgrade instructions for IAuCS

Only Indigo ice machines with firmware versions 2.032, 2.036 & 2.044 require a firmware

upgrade - All other firmware versions do not require a firmware upgrade. Use the flash drive

enclosed with this kit, along with these instructions to upgrade the firmware.

Verify firmware version needs to be upgraded:

a) Press menu button - Machine info will be bracketed.

b) Press right arrow and select Main SW Ver from submenu (Main Software Version).

c) Continue with this instruction when the software version is 2.032, 2.036 & 2.044. The firmware

upgrade is not required for any other firmware versions.

1. Remove front door and control box cover

2. Set the ice machine to off by pushing the power button after the ice falls from the evaporator at

the end of a harvest cycle.

3. Navigate the Display Interface to download the current version of Firmware and follow

instructions

Warning

Personal Injury Potential

Failure to upgrade the indicated firmware

versions can result in continuous dispensing

of solution into the water circuit.

Warning

Personal Injury Potential

Line voltage is present in the control box

during this procedure. Use caution when

inserting USB flash drive in control board.

Manitowoc Ice

2110 South 26th Street, P.O. Box 1720, Manitowoc, WI 54221-1720 USA 000009168

Telephone 920-682-0161, Fax - Sales: 920-683-7589, Service/Parts: 920-683-7585, Other: 920-683-7879 Page 2 of 4

Web Site - www.manitowocice.com Rev01

a. Menu

b. Service

c. USB Setup

d. USB Stick

e. Download Frm

f. Insert Drive

g. Press Checkmark after inserting drive

h. Wait for Completion (this may take 5-10 minutes)

Manitowoc Ice

2110 South 26th Street, P.O. Box 1720, Manitowoc, WI 54221-1720 USA 000009168

Telephone 920-682-0161, Fax - Sales: 920-683-7589, Service/Parts: 920-683-7585, Other: 920-683-7879 Page 3 of 4

Web Site - www.manitowocice.com Rev01

i. Once complete the display goes back to the home

screen and the CPU and display green LED lights begin to flash again.

Verify the correct Model and Serial number are programmed into the control board.

Verify the model and serial number on the display matches the model and serial number on the

data plate. If they match remove the flash drive - If they do not match continue with the steps

below.

j. Under Service > Repl Cntrl Bd > Manual Setup - Scroll down to the line below the model number

k. Begin to enter the model number IY, ID or IR, then press the Checkmark; The display should auto fill with the rest

of the model number - If the model number does not auto fill, repeat the firmware flash by repeating steps a

through i.

Manitowoc Ice

2110 South 26th Street, P.O. Box 1720, Manitowoc, WI 54221-1720 USA 000009168

Telephone 920-682-0161, Fax - Sales: 920-683-7589, Service/Parts: 920-683-7585, Other: 920-683-7879 Page 4 of 4

Web Site - www.manitowocice.com Rev01

l. Press the Down Arrow and scroll down until the

correct model number is shown, then press the

checkmark.

m. Scroll down to serial number and press the Right

Arrow Key.

n. Enter the serial number from the ice machine data

plate with the up and down arrows. If the cursor is

not present press the Checkmark to activate the

cursor.

o. Scroll down to Exit and press the Right Arrow or

Check Mark. Exiting will take a few seconds as it

is writing the info to memory.

p. Remove the flash drive and verify the Model

Number, Serial Number and Firmware Version are

correct.
