Installation, Use & Care Manual
This manual is updated as new information and models are released. Visit our website for the latest manual www.
manitowocice.com
F Model
Ice Storage Bins
Table of Contents
Part Number: 000006528 12/15 3
Section 1
General Information
Model Numbers..................................................................................................................4
Before You Begin ................................................................................................................4
Section 2
Installation Instructions
Installation Procedure .......................................................................................................6
Drain Requirements...........................................................................................................6
Door Removal.....................................................................................................................7
Removing Lower Door Assembly.....................................................................................................7
Reinstalling Lower Door Assembly...................................................................................7
Section 3
Operation
Baffle Operation.................................................................................................................9
For More Ice..............................................................................................................................................9
For More Access......................................................................................................................................9
Using Ice Probe Tool Accessory .........................................................................................9
Section 4
Maintenance
Cleaning and Sanitizing Interior Bin ..............................................................................11
Cleaning Exterior Bin .......................................................................................................11
Section 5
Customer Support
Before Calling For Service Checklist ...............................................................................13
Limited Warranty For Ice Storage Bin & Dispensers......................................................14
LIMITED WARRANTY........................................................................................................................... 14
WHAT IS COVERED .............................................................................................................................. 14
EXCLUSIONS FROM COVERAGE...................................................................................................... 14
LIMITATIONS OF LIABILITY................................................................................................................14
REMEDIES............................................................................................................................................... 15
WARRANTY CLAIM PROCEDURE.................................................................................................... 15
GOVERNING LAW.................................................................................................................................15
COMPLETE AND RETAIN FOR YOUR RECORD: ........................................................................... 15
4 Part Number: 000006528 12/15
Table of Contents (continued)
Part Number: 000006528 12/15 5
Model Numbers
This manual covers the following models
Single Door Upright
Ice Storage Bins
F700
F1300
F1325
F1650
Before You Begin
After uncrating and removing all packing material, inspect
the equipment for concealed shipping damage. If damage
is found, notify the shipper immediately
nWarning
Top is NOT fastened to bin. Be aware of this to avoid
personal injury.
nWarning
PERSONAL INJURY POTENTIAL
Do not operate equipment that has been misused,
abused, neglected, damaged, or altered/modified
from that of original manufactured specifications. This
appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge,
unless they have been given supervision concerning
use of theappliance by a person responsible for their
safety.
,Caution
Avoid excessive tightening force when connecting to
the bin drain fitting. Overtightening may cause damage.
,Caution
Do not apply excessive heat if any sweating of fittings
is necessary. Heat conduction through metal may melt
threads in plastic drain fitting.
,Caution
30” large capacity ice storage bins must be attached to
the wall.
Section 1
General Information
6 Part Number: 000006528 12/15
General Information Section 1
THIS PAGE INTENTIONALLY LEFT BLANK
Part Number: 000006528 12/15 7
Installation Procedure
1. Remove all packing material from bin.
2. Remove all tape and temporary fastenings from door
assemblies and outside of bin.
3. Remove top from bin.
4. Remove set of four legs and any other accessories
packed inside bin.
5. Lay bin on back, being careful to protect finish, and
remove bolts holding skid to bin.
6. Screw legs into tapped holes in bin bottom and tighten
to seat legs well against bottom.
7. Set bin upright.
8. Reinstall top onto bin.
9. Remove protective paper from stainless steel exterior.
10. Move bin to permanent location.
11. Adjust“foot” at bottom of each leg to level bin in both
directions.
12. Mount ice machine(s) on bin in accordance with ice
machine instructions.
13. Connect drain line to 1”FPT female fitting located in
bottom of bin.
14. Make final connections to ice machine.
Drain Requirements
• Bin drain termination must have an air gap.
• Drain lines must have a 1.5 inch drop per 5 feet of run
(2.5 cm per meter), and must not create traps.
• The floor drain must be large enough to accommodate
drainage from all drains.
• Run separate bin and ice machine drain lines and
insulate to prevent condensation.
Section 2
Installation Instructions
8 Part Number: 000006528 12/15
Installation Instructions Section 2
Door Removal
REMOVING LOWER DOOR ASSEMBLY
(Only if required for access through narrow doors)
1. With door in closed position, remove Phillips head
screw and washer from hinge area on each side of
lower access door.
2. Insert screwdriver between door and hinge bracket on
one side of door and gently push against bracket to
provide room for door stud to clear bracket.
3. Remove access door.
4. Pull up on baffle to remove.
5. Remove screws along top of door assembly.
6. Pull forward on top of assembly and lift to remove.
ACCESS
DOOR
BAFFLE
LOWER
DOOR
ASSEMBLY
Reinstalling Lower Door Assembly
1. Reinstall lower door assembly in bin opening.
2. Reinstall screws in hood at top of door assembly.
3. Reinstall baffle in side panel tracks and push down to
seat.
4. With door in closed position, insert one door stud
through hinge bracket, install washer, screw and
tighten.
NOTE: For proper operation the access door must be
reinstalled in the closed position.
5. On other side, insert screwdriver between door and
hinge bracket and gently push against bracket to
provide room for door stud to clear bracket.
6. Reinstall washer and screw in lift door and tighten.
7. Check door to ensure proper operation.
Part Number: 000006528 12/15 9
Baffle Operation
The baffle controls the flow of ice into lower door assembly
area for removal with either a scoop or shovel. The baffle
can also be adjusted and locked at one of several levels to
accommodate flow characteristics of different types of ice.
Bin is shipped with the baffle in full down position. The
baffle can be raised and locked in higher position for better
flow or when more access is needed
FOR MORE ICE
If more ice is needed in lower door area:
1. Use full-length handle at top of the baffle to gently
lift and jiggle the baffle to encourage ice to flow into
access area of the bin. (Loose ice will cascade into lower
door area.)
2. When adequate ice has flowed, push the baffle back
down.
FOR MORE ACCESS
When more access is needed or to encourage flow of less
“slippery” ice:
1. Lock gate at higher level by pulling up and holding
the baffle at correct level, and pushing tapered end of
catch into nearest hole in gate (catch will automatically
release when you pull up).
2. To release catch, pull up on the baffle.
Using Ice Probe Tool Accessory
Ice probe tool is an optional accessory. If your bin has been
ordered with ice probe tool accessory, mount probe for
easy access on either side of bin in bracket provided.
If there is adequate ice in bin but lower door area is not
filled with ice, it may be that ice has congealed in bin and
cannot flow. This can often be remedied by quickly jiggling
the baffle several times (see preceding, Baffle Operation).
If problem continues, probe tool can be inserted through
rectangular openings in the baffle and agitated back and
forth to break up congealed ice mass
nWarning
Use probe tool only as described above. To avoid
possible injury, keep head and face clear of lower door
area and tool at all times. Do not use probe tool for
other purposes.
Section 3
Operation
10 Part Number: 000006528 12/15
Operation Section 3
