Manhattan 177184 Manuel utilisateur

MXP

WIRELESS

PRESENTATION

MOUSE

USER

MANUAL

Model 177184

MAN-177184-UM-0708-01

Thank you for purchasing the MANHATTAN

MXP Wireless Presentation

Mouse, Model 177184.

Putting multi-media, mouse and presentation controls with a built-in laser

pointer in the palm of your hand, this handy device features a secure

2.4 GHz Bluetooth connection for easy installation and reliable connectivity,

with plenty of freedom and control from almost anywhere in the room.

Integrated media and slide buttons give you all-in-one control during

meetings and demonstrations, and the sensitive 200 dpi touchpad

quickly places the cursor where and when it’s needed for precise four-

button mouse operation. Plus, it quickly recharges through any USB

port or PCMCIA slot without the need for cables, cords or batteries!

The instructions in this user manual make installation and operation

quick and simple, so you’ll soon be enjoying the benets of these

additional features:

• Sleek, low-prole design

• Windows compatibility

• Lifetime Warranty

NOTE: Some screen images have been modied to t this manual format.

INSTALLATION

1. With the Bluetooth protocol available on your computer — on

the hard drive or through a Bluetooth dongle inserted in a USB

port — double-click the Bluetooth icon (right), which usually

appears in the lower-right corner of your desktop in the system tray.

2. When the Devices

tab of the Bluetooth

Devices screen

displays, click “Add.”

NOTE: Be sure the

mouse is within the

7 m / 23 ft. operating

range.

3. With the Welcome screen of Add Bluetooth Device Wizard displayed,

select “My device is set up and ready to be found” and click “Next.”

4. When the search screen displays, press the ID key (a recessed button

on the back of the MXP Wireless Presentation Mouse, approximately

” from the bottom of the device on the left side). The Activity LED

on the front panel should start blinking to indicate readiness.

5. When the wizard displays the prompt “Select the Bluetooth device that

you want to add,” highlight the device (as shown above) and click “Next.”

6. When the wizard displays the prompt “Do you need a passkey to add

your device?” select “Don’t use a passkey” and click “Next.”

7. A Status screen displays the message “Windows is installing your

device,” followed by a Finish screen. Click “Finish.” The Activity LED

will stop blinking, indicating the device is ready for use.

666

OPERATION

1. Set the On/Off switch to On.

2. Press either the “L” or “R” key to wake up the mouse.

As you move your nger on the touch pad, the cursor will follow. You

can “double-click” on the touch pad for the same results as when you

double-click a regular mouse.

Charging

To renew the full charge (4 hours) of the MXP Wireless Presentation

Mouse, either insert the device into the computer’s PCMCIA slot or use

the included cable to connect the USB cable jack to a USB port on the

computer (as shown below). The Charge LED will light during charging

and go off to indicate the charge is complete.

Charge LED

Activity LED

Laser

USB

cable jack

Volume down

(Media Player)

Previous (Media Player)

Next (Media Player)

Laser on/off

Right click

Scroll up/down

Left click

Open Media Player

Volume up (Media Player)

Play/pause (Media Player)

Touch pad

SPECIFICATIONS

Standards and Certications

• CE; FCC; Class II Laser product; deep red laser diode (650 nm;

1 mW output)

General

• 2.4 - 2.48 GHz Bluetooth Class II

• Operating distance up to 7 m (23 ft.)

• Presenter buttons (Next Slide, Prev Slide, Laser On)

• Media player buttons (Player Open, Volume Down, Volume Up, Prev

Track, Next Track and Play/Pause)

• Mouse buttons (Left, Right, Scroll Up, Scroll Down)

• Tracking method: Touchpad

• Touchpad: 200 dpi resolution; 10 sq. cm (1.5 sq. in.)

• Charging time: 4 hours (full charge)

• Power switch with charge, activity and laser LED indicators

• Windows 2000/XP/Vista compatible

• USB cable, 92 cm (36 in.)

• 104 x 55 x 7 mm (4.1 x 2.1 x 0.27 in.); 31.2 g (1.1 oz.)

Package Contents

• MXP Wireless Presentation Mouse

• User manual and carrying pouch

NOTE: Laser pointers and laser-equipped devices are not toys and should not be used by

minors without direct adult supervision. Do not stare into the beam or view directly with

optical instruments.

All products mentioned are trademarks or registered trademarks of their respective owners.

www.manhattan-products.com

MANHATTAN®offers a complete line

of PC Components, Peripherals, Cables and Accessories.

Ask your local computer dealer for more information

or visit us online at
