Manhattan 702898 Manuel utilisateur

MAN-702898-UM-0706-02

hi-speed UsB 2.0

2.5" external

enclosUre

User ManUal

MODEL 702898

Congratulations on purchasing the MANHATTAN®Hi-Speed USB 2.0 2.5" External Enclosure, Model

702898. This device will let you quickly and easily transfer, share and archive data, and expand storage

capacities for desktop and notebook PCs. Among the external enclosure’s main features:

• Supports Hi-Speed USB 2.0 data transfer rates of up to 480 Mbps

• Lightweight, compact design requires no external power adapters for increased portability

• Sturdy aluminum case protects drive and facilitates cooling

• Fits standard 2.5” PATA (IDE) drives with easy, quick installation

• Windows and Macintosh compatible, Plug and Play, hot swappable

• Lifetime Warranty

setting Up the external enclosUre

NOTE: It’s recommended that you ﬁrst create a copy of your original data prior to connecting to the

external enclosure to prevent the possibility of data loss should a mistake be made during the setup

procedure. MANHATTAN accepts no responsibility for lost data.

1. Remove the back cover 2. Carefully connect your 3. Re-insert your drive into 4. Replace and tighten the

from the enclosure. drive to the interface. the enclosure. two screws to complete

the procedure.

USB 2.0 Windows 98SE Installation

1. Place the installation CD in the CD-ROM drive and connect the external enclosure to your computer.

Auto Detect will run the Add New Hardware wizard, which searches for the USB 2.0 external enclosure.

Click "Next."

2.Select "Search for the best driver for your device (recommended)" and then click "Next."

3.Click "Specify location"; browse to "CD-ROM E:\USB 2.0-98 Drive"; then click "Next."

4.With the prompt "Windows driver ﬁle search for the device Hi-Speed USB-to-IDE Bridge Controller,"

click "Next."

5.With the prompt "Windows has ﬁnished installing the software that your new hardware device requires,"

click "Finish."

NOTE: For Windows Me/2000/XP/Vista, no need to install the additional driver: It’s already installed.

Windows XP needs to be updated with SP2.

specifications

• 44-pin IDE internal connection

• Hi-Speed USB 2.0 mini B

external connection

• Proliﬁc PL-2506 chipset

• DC power input jack (adapter

not included)

• Meets current Hi-Speed USB

2.0 & IDE/ATA133 standards

• External DC power adapter

cannot exceed 5 V / 1 A (not

included)

• 14 x 8 x 1 cm (5.1 x 3.0 x 0.5 in.)

• 78 g (2.5 oz)

System Requirements

• Pentium 266 MHz or higher

• 64 MB RAM

• Windows 98SE/Me/2000/

XP/Vista or MAC OS 9.0 and

above

Package Contents

• External Enclosure

• USB cable, A-type male x 2 to

mini B male, 1.2 m (4 ft.)

• User manual and travel bag

www.manhattan-products.com

Are you completely satisﬁed with this product?

Please contact your MANHATTAN®dealer with comments or questions.

All products mentioned are trademarks or registered trademarks of their respective owners.
