MangOH Red Manuel utilisateur

mangOH™ Red

User Guide

41110400

Rev 3

Contents subject to change

mangOH Red User Guide

Rev 3 Sep.18 2 41110400

Important

Notice

Due to the nature of wireless communications, transmission and reception of data can

never be guaranteed. Data may be delayed, corrupted (i.e., have errors) or be totally

lost. Although significant delays or losses of data are rare when wireless devices such

as the Sierra Wireless modem are used in a normal manner with a well-constructed

network, the Sierra Wireless modem should not be used in situations where failure to

transmit or receive data could result in damage of any kind to the user or any other

party, including but not limited to personal injury, death, or loss of property. Sierra

Wireless accepts no responsibility for damages of any kind resulting from delays or

errors in data transmitted or received using the Sierra Wireless modem, or for failure

of the Sierra Wireless modem to transmit or receive such data.

Safety and

Hazards

Do not operate the Sierra Wireless modem in areas where blasting is in progress,

where explosive atmospheres may be present, near medical equipment, near life

support equipment, or any equipment which may be susceptible to any form of radio

interference. In such areas, the Sierra Wireless modem MUST BE POWERED OFF.

The Sierra Wireless modem can transmit signals that could interfere with this

equipment.

Do not operate the Sierra Wireless modem in any aircraft, whether the aircraft is on

the ground or in flight. In aircraft, the Sierra Wireless modem MUST BE POWERED

OFF. When operating, the Sierra Wireless modem can transmit signals that could

interfere with various onboard systems.

Note: Some airlines may permit the use of cellular phones while the aircraft is on the ground

and the door is open. Sierra Wireless modems may be used at this time.

The driver or operator of any vehicle should not operate the Sierra Wireless modem

while in control of a vehicle. Doing so will detract from the driver or operator's control

and operation of that vehicle. In some states and provinces, operating such

communications devices while in control of a vehicle is an offence.

Limitation of

Liability

The information in this manual is subject to change without notice and does not

represent a commitment on the part of Sierra Wireless. SIERRA WIRELESS AND ITS

AFFILIATES SPECIFICALLY DISCLAIM LIABILITY FOR ANY AND ALL DIRECT,

INDIRECT, SPECIAL, GENERAL, INCIDENTAL, CONSEQUENTIAL, PUNITIVE OR

EXEMPLARY DAMAGES INCLUDING, BUT NOT LIMITED TO, LOSS OF PROFITS

OR REVENUE OR ANTICIPATED PROFITS OR REVENUE ARISING OUT OF THE

USE OR INABILITY TO USE ANY SIERRA WIRELESS PRODUCT, EVEN IF

SIERRA WIRELESS AND/OR ITS AFFILIATES HAS BEEN ADVISED OF THE

POSSIBILITY OF SUCH DAMAGES OR THEY ARE FORESEEABLE OR FOR

CLAIMS BY ANY THIRD PARTY.

Notwithstanding the foregoing, in no event shall Sierra Wireless and/or its affiliates

aggregate liability arising under or in connection with the Sierra Wireless product,

regardless of the number of events, occurrences, or claims giving rise to liability, be in

excess of the price paid by the purchaser for the Sierra Wireless product.

Rev 3 Sep.18 3 41110400

Patents This document contains information which is proprietary to Sierra Wireless Inc. and is

licensed pursuant to Creative Commons Attribution 4.0 International License.

Document

details

Title: mangOH Red User Guide

Author: Sierra Wireless

Source: http://mangoh.io/

license, http://creativecommons.org/licenses/by/4.0/

Disclaimer Indicate any modifications made to the original document.

Trademarks mangOH™ and the mangOH logo are trademarks of Sierra Wireless.

Other trademarks are the property of their respective owners.

Revision

History

Revision

number

Release date Changes

1February 2017 Document created

2May 2017 Removed DV2 references, updated to DV3 where needed

3September 2018 Updated DV5

Updated Table 1-2

Added Console Access appendix

Rev 3 Sep.18 4 41110400

Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

mangOH Red Components and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Setup and Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Safe Handling Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Initial Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Hardware Setup and Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Insert/Remove Embedded Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Power Supply Sources. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Select USB Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Connect Battery Backup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Connect Antenna(s). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

SIM, SD, and IoT Expansion Cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Inserting a micro-SIM Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Inserting a microSD Card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Inserting/Removing an IoT Expansion Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Peripheral Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Raspberry Pi Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Audio Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

USB Host Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Control Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Console USB Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

CF3 USB Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Physical Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Reset Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Rev 3 Sep.18 5 41110400

mangOH Red Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Default Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Switch and Jumper Configuration Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

Real-time I/O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Low-power I/O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Module Signals Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Software Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Install / Update Windows Driver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Install a Terminal Emulator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Download Firmware Updates. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Write Your First Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Console Access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Rev 3 Sep.18 6 41110400

1: Introduction

This user guide explains how to set up and begin using the mangOH™ Red with CF3 (Common Flexible Form

Factor) modules.

Once you have the mangOH Red set up, visit mangoh.io/mangoh-red-resources for developer documentation,

code samples, and other materials.

1.1 mangOH Red Components and Accessories

Table 1-1 details the required and optional components needed to begin using the mangOH Red in your

development environment. Some of these components are available in mangOH Red development kits (kit

contents are supplier-dependent).

Table 1-1: mangOH Red Required and Optional Components

Item Details Example

(1) mangOH Red with

CF3 module

(Pre-installed in kit)

Pre-configured development board for CF3 modules

The module in the kit includes a cellular modem and an

application processor running Legato, an open source

embedded platform built on Linux for hosting IoT applications

(see legato.io for details).

For a list of Sierra Wireless CF3 modules and their

compatibility with mangOH Red, see Table 1-2 on page 7.

Note: Not all supported Sierra Wireless modules include appli-

cation processors.

(2) CF3 module covers

and cover removal tool

(One pre-installed in kit)

Industrial-quality snap-in module covers (for 2.5 mm and

4.0 mm height modules) plus cover removal tool to disconnect

the cover from the mangOH Red

Note: The cover and tool shown are for WP-series modules. A

similar cover and tool (not displayed) are used for HL-series

modules.)

(2) Micro-USB cables

(Included in kit)

Connects computer to the mangOH Red for communication

and to provide power for non-transmitting tests.

(1 or 2) Antenna, Ultra

Wide Band

(Included in kit)

Main RF antenna included. Second antenna included if CF3

module supports diversity.

Rev 3 Sep.18 7 41110400

The mangOH Red schematic (available at mangoh.io/mangoh-red-resources-hardware), describes all interfaces

supported by the mangOH Red.

The following table identifies differences between mangOH Red interfaces, the CF3 standard, and WP Series

modules. Refer to source.sierrawireless.com for module-specific Product Technical Specification Documents.

(1) GNSS Antenna

(Included in kit) Antenna may be connected for GNSS reception.

(1) micro-SIM card

(Included in kit)

•Sierra Wireless or AT&T micro-SIM card (included) with

initial data allocation, or

•User-provided micro-SIM with an active account, or

•User-provided test card for use with a call box.

M2 screws

(Included in kit) Two M2 screws included for IoT card installation

Audio cable (3.5 mm)

(Not included in kit) Optional audio cable or headset

Table 1-2: Interface Variations (mangOH vs CF3 Specification vs WP Series Modules)a

Signal Names

Pin mangOH CF3 WP85/75bWP76xxcWP77xxd

2NC UART1_RI UART1_RI UART1_RI UART1_RI

7NC UART1_DTR UART1_DTR UART1_DTR UART1_DTR

8NC UART1_DCD UART1_DCD UART1_DCD UART1_DCD

9NC UART1_DSR UART1_DSR UART1_DSR UART1_DSR

10 GPIO_IOT0_RESET GPIO2 GPIO2 GPIO2 GPIO2

11 RESET_IN_CF3 RESET_IN_N RESET_IN_N RESET_IN_N RESET_IN_N

21 BAT_RTC BAT_RTC BAT_RTC Reserved Reserved

31 RF_DIV RF_DIV (WP75) RF_DIV

(WP85) Reserved RF_DIV Reserved

40 IOT0_GPIO3 GPIO7 GPIO7 GPIO7 GPIO7

41 IOT0_GPIO4 GPIO8 GPIO8 GPIO8 GPIO8

42 PPS DR_SYNC DR_SYNC DR_SYNC DR_SYNC

43 PWM_OUT EXT_GPS_LNA_EN Reserved EXT_GPS_LNA_EN EXT_GPS_LNA_EN

44 IOT0_GPIO2 GPIO13 GPIO13 GPIO13 GPIO13

Table 1-1: mangOH Red Required and Optional Components (Continued)

Item Details Example

mangOH Red User Guide

Rev 3 Sep.18 8 41110400

46 LowPower_RESET RESET_OUT_N RESET_OUT_N RESET_OUT_N RESET_OUT_N

55 UIM2_VCC UIM2_VCC UIM2_VCC Reserved Reserved

56 UIM2_DAT UIM2_DAT UIM2_DATA Reserved Reserved

57 UIM2_RST UIM2_RST UIM2_RESET_N Reserved Reserved

58 UIM2_CLK UIM2_CLK UIM2_CLK Reserved Reserved

65 UIM2_DET UIM2_DET UIM2_DET GPIO4 GPIO4

92 WP_GPIO_4_wakeable SPI2CLK GPIO38 GPIO38 GPIO38

93 NC SPI2_MOSI GPIO39 Reserved Reserved

94 NC SPI2_MISO GPIO40 GPIO40 GPIO40

95 NC SPI2_CS0 GPIO41 GPIO41 GPIO41

98 UART2_RTS UART2_RTS Reserved UART2_RTS UART2_RTS

99 UART2_CTS UART2_CTS Reserved UART2_CTS UART2_CTS

100 WP_GPIO_7 GPIO34 GPIO34 Reserved Reserved

101 WP_GPIO_8 GPIO35 GPIO35 GPIO35 GPIO35

102 WP_GPIO_5_wakeable GPIO36 GPIO36 GPIO36 GPIO36

103 NC GPIO37 GPIO37 GPIO37 GPIO37

104 GPIOEXP_INT1 GPIO32 GPIO32 GPIO32 GPIO32

105 CARD_DETECT_IOT0 GPIO33 GPIO33 GPIO33 GPIO33

109 IOT0_GPIO1 GPIO42 GPIO42 GPIO42 GPIO42

147 SPI2_SRDY_WIFI_1V8 GPIO21 GPIO21 GPIO21 GPIO21

148 WP_GPIO_1 GPIO22 GPIO22 GPIO22 GPIO22

149 WP_GPIO_2 GPIO23 GPIO23 GPIO23 GPIO23

150 WP_GPIO_3 GPIO24 GPIO24 GPIO24 GPIO24

152 NC SAFE_PWR_REMOVE SAFE_PWR_REMOVE SAFE_PWR_REMOVE SAFE_PWR_REMOVE

153 NC ANT_CTL_0 ANT_CNTL0/GPIO28 ANT_CNTL0 ANT_CNTL0

154 NC ANT_CTL_1 ANT_CNTL1/GPIO29 ANT_CNTL1 ANT_CNTL1

155 NC ANT_CTL_2 ANT_CNTL2/GPIO30 ANT_CNTL2 ANT_CNTL2

156 NC ANT_CTL_3 ANG_CNTRL3/GPIO31 ANT_CNTL3 ANT_CNTL3

a. Refer to Product Technical Specification documents for detailed module information.

b. WP85/75=WP8548, WP7502, WP7504

c. WP76xx=WP7601, WP7601, WP7601-1, WP7603, WP7603-1, WP7607, WP7607-1, WP7608/WP7608-1, WP7609

d. WP77xx=WP7700, WP7702

Table 1-2: Interface Variations (mangOH vs CF3 Specification vs WP Series Modules)a

Signal Names

Pin mangOH CF3 WP85/75bWP76xxcWP77xxd

Rev 3 Sep.18 9 41110400

2: Setup and Installation

2.2 Safe Handling Recommendations

To help prevent accidental damage to the mangOH Red:

•Use safe ESD-handling practices (such as wearing proper ESD straps) to avoid possible ESD damage.

•The mangOH Red kit comes with the CF3 module and cover pre-installed. If you remove the module, avoid

touching the CF3 module socket (J200). These pins can be damaged if caught on clothing or other materials.

Figure 2-1: Safe Handling Recommendations—CF3 Socket (Do Not Touch)

•Optionally, attach standoffs (not included) to the mounting holes at each corner of the board to avoid damage

to components on the bottom side of the board.

Figure 2-2: Module Standoff Placement

J200 — CF3 module

Standoff holes (4 corners)

Standoff example

mangOH Red User Guide

Rev 3 Sep.18 10 41110400

2.3 Initial Setup

To begin using the mangOH Red, set up your hardware and software:

1. Install / Update Windows Driver. See page 36.

2. Install a Terminal Emulator. See page 37.

3. Verify the SW401 dipswitch pins are set correctly:

a. If the dipswitches are covered with a protective film, remove it:

Figure 2-3: SW401 Dipswitch Location

b. Make sure the dipswitches are set as follows:

·ON—1,3,5,8

·OFF—2,4,6,7

Note: Pin 1 must be ON to allow the module to power up as soon as power is supplied. If pin 1 is OFF, you must press

SW402 after power is supplied to power up the module.

Figure 2-4: SW401 Dipswitch Recommended Settings

4. If you will be establishing a mobile network connection, insert a micro-SIM. See Inserting a micro-SIM Card on

page 18.

5. Connect Antenna(s). See page 17.

6. Select USB Power Supply. See page 15.

Remove this film

SW402 (on edge)

Autres manuels pour Red

Table des matières

Autres manuels mangOH Unité de contrôle

mangOH

mangOH Yellow Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur

mangOH Red Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques
