MIEN3024/3026

Rack Mount Industrial Ethernet Switch

User Manual

(Edition: V3.0)

Wuhan Maiwe Communication Co., Ltd.

MIEN3024/3026 Rack Mount Industrial Ethernet Switch

Trademark

This trademark is owned by Wuhan Maiwe

Communication Co., Ltd.

Mwring is the trademark used for link redundancy and self-recovery

technology, owned by Wuhan Maiwe Communication Co., Ltd.

Microsoft and Windows is registered trademark owned by Microsoft.

Clarification

The user manual is applicable to MIEN3024/3026 series rack-mounted

industrial Ethernet switches.

Please read the following license agreement carefully before using this manual.

The products described in this manual can be used only if you agree on the

following license agreement.

Important Statement

Any information provided by our company in this manual does not represent for

corresponding authorization on these information.

Our company attempts to ensure the accuracy and applicability for the

information provided in this manual, however our company does not assume

any responsibility for the use of these information, and does not assume any

joint responsibility for the use of these information. There may be a few

technical or typographical errors in the product and manual. The company

reserves the right to change all or part of this manual without prior notice.

Statement

Due to continuous update and improvement of products and

technology, the contents of this document may not be completely

consistent with the actual products, appreciate for your understanding.

If necessary to inquiry the updates of the product, please check our

official website or contact our representative directly.

MIEN3024/3026 Rack Mount Industrial Ethernet Switch

Revision history:

Version

Date

Reason

V1.0

2013.08

Document creation

V1.1

2013.11

Modified housing size

V2.0

2014.07

Product upgrade

V3.0

2015.14

Product upgrade

MIEN3024/3026 Rack Mount Industrial Ethernet Switch

III

Safe Use Instruction

This product performance is excellent and reliable in the designed range of use,

but it’s necessary to avoid man-made damage or destroy for the

equipment.

Read the manual carefully and keep this manual for reference if need

afterwards.

Do not put the device close to the water sources or damp places.

Do not put anything on the power cable, it should be placed out of reach.

To avoid causing fire, do not knot or wrap the cable.

Power connector and other device connectors should be firmly

connected with each other, frequently inspection is needed.

Please keep the fiber socket and plug clean. Do not look directly at the

fiber section when the equipment is working.

Please keep the equipment clean and wipe it with a soft cotton cloth if

necessary.

Please do not repair the equipment by yourself, unless there is clear

instructions in the manual.

Under the following circumstances, please cut off power immediately and

Equipment water damage.

The equipment is broken or the casing is broken.

The equipment works abnormally or the performance has completely

changed.

The equipment produces odor, smoke or noise.

Statement: Information requiring explanation in use of the managed software.

Attention: Matters requiring specific attention in the use of the managed

software.

MIEN3024/3026 Rack Mount Industrial Ethernet Switch

Catalogue

1. Introduction................................................................. - 1 -

1.1. Product instruction.......................................................................- 1 -

1.2. Product characteristic................................................................. - 1 -

1.2.1. Industry Network features................................................................. - 1 -

1.2.2. Industrial application design............................................................. - 1 -

1.3. Packing list.................................................................................... - 1 -

1.4. Product parameters.....................................................................- 2 -

2. Product application...................................................- 3 -

2.1. Hardware structure...................................................................... - 3 -

2.1.1. System structure................................................................................ - 3 -

2.1.2. Product configuration.........................................................................- 3 -

2.2. Hardware Installation.................................................................. - 6 -

2.2.1. Installation requirements...................................................................- 6 -

2.2.2. The equipment installation................................................................- 7 -

2.2.3. Cable connection............................................................................... - 9 -

2.2.4. Fiber optic connection....................................................................... - 9 -

2.2.5. Cable Layout.................................................................................... - 10 -

2.3. Testing guide...............................................................................- 11 -

2.3.1. System self-examination................................................................. - 11 -

2.3.2. Copper port testing.......................................................................... - 11 -

2.3.3. Fiber port testing.............................................................................. - 13 -

3. Maintain and Service.............................................. - 14 -

3.1. On-line service........................................................................... - 14 -

3.2. Call for technical support service...........................................- 14 -

3.3. Warranty Policy.......................................................................... - 14 -

4. Appendix.................................................................... - 15 -

MIEN3024/3026 Rack Mount Industrial Ethernet Switch

- 1 -

1. Introduction

1.1. Product instruction

The Maiwe industrial rack-mount Ethernet switch is specially designed and

developed for industrial high speed communication network applications. This

series of switches features is simple plug and play, all copper port support

auto-negotiation, 10/100Mbps full duplex and half duplex, Auto-MDI/MDI-X and

other functions.

This series switch offer RPS support and can provide wide range of AC

and DC power input at the same time. In terms of structural installation, they

use the rack mount to meet the industrial site.

The MIEN3024 series of industrial Ethernet switches have a total of 24

100M ports, and the MIEN3026-2S/M industrial Ethernet switches have a total

of 26 100M ports. Both the switching bandwidth is 8.8G and support 8K entries

in the MAC address table.

1.2. Product characteristic

1.2.1. Industry Network features

Broadcast storm protection

Optional 100Base-FX different transmission distances, different types of

optical fiber interfaces

Store and forward mode, switched bandwidth is 8.8Gbps.

10/100M TX auto negotiation ,full/half duplex, auto MDI/MDI-X

connection

Full-duplex flow control, half-duplex back pressure flow control

Redundancy dual power supply input, suitable for high performance

requirement.

No interference operation in hard EMI Environment.

1.2.2. Industrial application design

Redundancy dual power supply input design.

Rack-mount

Relay power failure alarm

Fast recovery of port wire changing connection

1.3. Packing list

The packing list of MIEN3024/3026 series rack-mounted industrial

Ethernet switch is as below. If any of the following items is lost or damaged,

please contact the agent or the company's customer service center, and they

will assist you to replace or supplement.

MIEN3024/3026 Rack Mount Industrial Ethernet Switch

- 2 -

Item

QTY

MIEN3024/3026 industrial Ethernet switch

1pcs

User manual

1pcs

Certificate and warranty card

1pcs

1.4. Product parameters

The rack-mount Ethernet switch can finish Ethernet information exchange.

Users must refer to the following data for reasonable selection and use in order

to show good industrial characteristics and excellent network information

exchange capabilities

IEEE standard

802.3,802.3u,802.3x

Exchange method

Store and forward

Flow control

Full-duplex flow control,

half-duplex back pressure flow

control

Mac address

Transmission distance

Twisted pair 100m,Optical fiber

100Mbps Maximum

20km\40km\60km\80km

Broadcast storm

Real-time broadcast suppression

Diagnostic function

Relay power failure alarm

EMC Standard

IEC61000-4-2 electrostatic

prevention ESD

±8kv contact discharge, ±15kv air

discharge

IEC61000-4-3 electromagnetic

field

10V/m(80~1000MHz)

IEC61000-4-6 radio frequency

presentation

3V(10kHz~150kHz),10V(150kHz~

80kHz)

EN55022

EN55022 Class A

MIEN3024/3026 Rack Mount Industrial Ethernet Switch

- 3 -

2. Product application

2.1. Hardware structure

2.1.1. System structure

System hardware mainly composed following parts:

The switch network controller uses high performance ASIC chip

technology to provide layer 2 wire-speed forwarding of data packets.

The fiber port use integrated optical transceiver module, stable

performance.

Industrial power supply with EMC and over-current/over-voltage

protection.

All data ports and copper port have the EMC protection.

2.1.2. Product configuration

The MIEN3024 rack-mount industrial Ethernet’s chassis is the 19-inch 1U

structure. The whole machine use six-side fully enclosed structure. The left and

right side panels of the chassis are made of single-ribbed aluminum material

which it is one part of whole cooling system. It abandon the traditional flow fan

heat dissipation and reduce the power consumption of the whole machine but

also improve the stability of the system at the same time.

MIEN3024, MIEN3024-4/8S/M and MIEN3026-2S/M the picture is as

below.

Dimension size is as below:482.6x210x44mm

MIEN3024-12/16/24S/M picture as below, Dimension size is below series

switch are:

482.6mm×315mm×44mm

The front Interface panel indication lights is as below:

MIEN3024/3026 Rack Mount Industrial Ethernet Switch

- 4 -

The Interface indication lights function:

PWR1

PWR2

ALARM

RUN

LINK/ACT

10/100M

Red on

Green

off

Green

flash

Green

periodic flash

Green on

Green flash

Green

off

Power

normal

Both

power

supply

Single

power

supply

System

working

normal

Link

connected

Data

transmission

100M

10M

100M fiber connector

This switch has multi full duplex 100Base-FX single-mode or multi-mode

fiber connectors, the connector has 3 types SC, ST, or FC to be chosen. The

fiber connector is used in pairs, the TX is the transmitting port and the RX is the

receiving port. TX port is the optical transmitting end which is connected to the

optical receiving end RX of another remote switch optical interface; RX port is

the optical receiving end which is connected to the optical transmitting TX of

the same remote switch optical interface.

Below is the 100M fiber connector:

Ethernet RJ45 connector

This switch series has multi 10Base-T/100Base-TX Ethernet RJ45 ports.

Each port has adaptive function and support auto MDI/MDI-X connection. The

switch use straight-through network cables/crossover network cables to

connect to terminal devices, servers, hubs or other switches. Each port

supports IEEE802.3x adaptive, so the most suitable transmission mode (half

duplex or full duplex) and data rate (10Mbps or 100Mbps) can be automatically

selected (the connected device must also support this feature). If the devices

connected to these ports do not support auto-negotiation, the ports will send at

the correct speed, but the transmission mode will default to half-duplex.

The Power supply input terminal block

This series of switches standard configuration uses 2 channels of AC220V

redundant power supply, MIEN3024 and MIEN3024-4/8S/M, MIEN3026-2S/M

wiring terminals use 7.62mm pitch terminals to connect 2 power inputs.

MIEN3024/3026 Rack Mount Industrial Ethernet Switch

- 5 -

MIEN3024-12/16/24S/M terminal block uses 5.08mm pitch terminal to connect

2 power inputs. The power consumption of the whole series is less than 25W

The Power supply input terminal block picture as below:

This series rack mount industrial Ethernet switch power requirement is as

below:

Voltage

range

Working

temperature

Storage

temperature

Humidity

24vdc

18-36vdc

-40°C~+85°C

5~95%

48vdc

36-72vdc

-40°C~+85°C

5~95%

220vac/dc

85-264vac

47-63hz or

110-370vdc

-40°C~+85°C

5~95%

Notice:

The power supply specifications supported by this device are 24VDC,

48VDC, 220VAC/DC. Before connecting to the power supply, please confirm

whether the power supply is consistent as required to avoid damage to the

device

Alarm relay

The switch power-on and power-down alarm relay, the wiring terminal

adopts 3 5.08mm pitch terminals, this relay is one normally open and one

normally closed relay, as shown in the figure below. The one in the middle is

the common terminal, the two terminals on the left are normally open relays,

and the two on the right are normally closed relays. When the switch is

powered on and working normally, the normally open relay is energized and

closed, and the normally closed relay is disconnected. When the system is

powered off or one of the redundant power supplies is power off, the normally

open relay is powered off and the normally closed relay is closed. The

recommended switching load capacity of the relay is 1A (24VDC), Check below

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Maiwe Changer

Maiwe

Maiwe MISCOM7212GP Series Manuel utilisateur

Maiwe

Maiwe MIGE2210 Series Manuel utilisateur

Maiwe

Maiwe MISCOM7220G-4GF-16GT Manuel utilisateur

Maiwe

Maiwe MISCOM8028-4GF Manuel utilisateur

Maiwe

Maiwe MIEN2208 Series Manuel utilisateur

Maiwe

Maiwe MISCOM8028GX-4XGF-16GF-8GC Manuel utilisateur

Maiwe

Maiwe MIEN2216 Manuel utilisateur

Maiwe

Maiwe MIEN2204 Series Manuel utilisateur

Maiwe

Maiwe MISCOM7028GX Series Manuel utilisateur

Maiwe

Maiwe MIEN5208 Series Manuel utilisateur

Maiwe

Maiwe MIEN2208-F Manuel utilisateur

Maiwe

Maiwe MIEN2208 Series Manuel utilisateur

Maiwe

Maiwe Admas2208P-M12-8TPOE Manuel utilisateur

Maiwe

Maiwe MIEN2016 Manuel utilisateur

Maiwe

Maiwe MIGE3028-4GF Manuel utilisateur

Maiwe

Maiwe MIEN2205 Manuel utilisateur

Maiwe

Maiwe MISCOM8220G Manuel utilisateur

Maiwe

Maiwe MIEN2205 Manuel utilisateur

Maiwe

Maiwe MIEN2206 Manuel utilisateur

Maiwe

Maiwe MIEN3020G-4GC-16GT Manuel utilisateur

Maiwe

Maiwe MIEN1203 Manuel utilisateur

Maiwe

Maiwe MIEN6208 Series Manuel utilisateur

Maiwe

Maiwe MIGE2206G-2GF-4GT Manuel utilisateur

Maiwe

Maiwe MIEN2205 Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
