Maiwe MIEN2016 Manuel utilisateur

MIEN2016/2018/2024/2026

Rack Mount Industrial Ethernet Switch

User Manual

(Edition: V2.0)

Wuhan Maiwe Communication Co., Ltd.

MIEN2016/2018/2024/2026 Rack Mount Industrial Ethernet Switch

Trademark

This trademark is owned by Wuhan Maiwe

Communication Co., Ltd.

Mwring is the trademark used for link redundancy and self-recovery

technology, owned by Wuhan Maiwe Communication Co., Ltd.

Microsoft and Windows is registered trademark owned by Microsoft.

Clarification

The user manual is applicable to MIEN2016/MIEN2018/MIEN2024/MIEN2026

rack-mounted industrial ethernet switch.

Please read the following license agreement carefully before using this manual.

The products described in this manual can be used only if you agree on the

following license agreement.

Important Statement

Any information provided by our company in this manual does not represent for

corresponding authorization on these information.

Our company attempts to ensure the accuracy and applicability for the

information provided in this manual, however our company does not assume

any responsibility for the use of these information, and does not assume any

joint responsibility for the use of these information. There may be a few

technical or typographical errors in the product and manual. The company

reserves the right to change all or part of this manual without prior notice.

Statement

Due to continuous update and improvement of products and

technology, the contents of this document may not be completely

consistent with the actual products, appreciate for your understanding.

If necessary to inquiry the updates of the product, please check our

official website or contact our representative directly.

Revision history:

Version

Date

Reason

V1.0

2012.08

Document creation

V2.0

2014.06

Product upgrade

MIEN2016/2018/2024/2026 Rack Mount Industrial Ethernet Switch

Safe Use Instruction

This product performance is excellent and reliable in the designed range of use,

but it’s necessary to avoid man-made damage or destroy for the

equipment.

Read the manual carefully and keep this manual for reference if need

afterwards.

Do not put the device close to the water sources or damp places.

Do not put anything on the power cable, it should be placed out of reach.

To avoid causing fire, do not knot or wrap the cable.

Power connector and other device connectors should be firmly

connected with each other, frequently inspection is needed.

Please keep the fiber socket and plug clean. Do not look directly at the

fiber section when the equipment is working.

Please keep the equipment clean and wipe it with a soft cotton cloth if

necessary.

Please do not repair the equipment by yourself, unless there is clear

instructions in the manual.

Under the following circumstances, please cut off power immediately and

Equipment water damage.

The equipment is broken or the casing is broken.

The equipment works abnormally or the performance has completely

changed.

The equipment produces odor, smoke or noise.

Statement: Information requiring explanation in use of the managed software.

Attention: Matters requiring specific attention in the use of the managed

software.

MIEN2016/2018/2024/2026 Rack Mount Industrial Ethernet Switch

III

Catalogue

1. System Overview....................................................... - 1 -

1.1. Product Introduction.................................................................... - 1 -

1.2. Characteristic................................................................................ - 1 -

1.2.1. Industrial network performance........................................................- 1 -

1.2.2. Industrial application design............................................................. - 1 -

1.2.3. Packing list..........................................................................................- 1 -

1.3. Performance specifications....................................................... - 2 -

2. Application Description............................................- 3 -

2.1. Hardware structure...................................................................... - 3 -

2.1.1. System structure................................................................................ - 3 -

2.1.2. Whole machine structure.................................................................. - 3 -

2.2. Hardware installation...................................................................- 5 -

2.2.1. Installation requirements...................................................................- 5 -

2.2.2. Host installation.................................................................................. - 6 -

2.2.3. Cable connection............................................................................... - 7 -

2.2.4. Fiber optic connection....................................................................... - 8 -

2.2.5. Laying cables......................................................................................- 8 -

2.3. Simple test.....................................................................................- 9 -

2.3.1. System self-check..............................................................................- 9 -

2.3.2. Copper port test............................................................................... - 10 -

2.3.3. Fiber port test................................................................................... - 10 -

3. Maintenance and Service...................................... - 12 -

3.1. INTERNET service.................................................................... - 12 -

3.2. Technical support telephone service.....................................- 12 -

3.3. Product repair or replacement................................................ - 12 -

MIEN2016/2018/2024/2026 Rack Mount Industrial Ethernet Switch

- 1 -

1. System Overview

1.1. Product Introduction

The unmanaged simple series products produced by Maiwe including

MIEN2016, MIEN2024, MIEN2018-2S/M and MIEN2026-2S/M, are industrial

Ethernet switches that are professionally designed and developed for industrial

high-speed communication network applications. The switch is mainly used for

simple plug-and-play applications. All electrical ports support auto-negotiation,

10/100Mbps full duplex and half duplex, Auto-MDI/MDI-X and other functions.

Make industrial communication smoother, more reliable, and faster, and meet

the continuous innovation needs of customers to increase value-added

applications.

These unmanaged switches provide AC and DC 220V power supply

support, while providing a wide range of DC and AC power input. In terms of

structural installation, the switch uses rack installation.

This series of industrial Ethernet switches has a total of 26 100M ports at

most, and its switching bandwidth is 8.8G. They all support 8K entries in the

MAC address table.

1.2. Characteristic

1.2.1. Industrial network performance

Broadcast storm suppression

Optional 100Base-FX with different transmission distances and different

types of optical fiber interfaces

Store and forward mechanism

100M electrical port 10/100M adaptive, full/half duplex, MDI/MDIX

adaptive mode

Full-duplex flow control and half-duplex back pressure flow control

AC and DC power input to meet the requirements of high availability

Meet the requirements of trouble-free work under strong electromagnetic

interference environment

1.2.2. Industrial application design

Rack installation

Quick recovery of port connection

1.2.3. Packing list

The packaging list of unmanaged products of Wuhan Maiwe

Communication Co., Ltd. is shown in Table 1-1. If any of the listed items is lost

or destroyed, please contact the agent or the customer service center for

replace or make up.

MIEN2016/2018/2024/2026 Rack Mount Industrial Ethernet Switch

- 2 -

Table 1-1 Product packing list

Item

Quantity

Switch

User manual

Product Certificate and Warranty Card

1.3. Performance specifications

Maiwe switches can complete Ethernet information exchange. Users must

refer to the following data for reasonable selection and use in order to show

good industrial characteristics and excellent network information exchange

capabilities.

Technical index:

IEEE standard: 802.3, 802.3u, 802.3x

Exchange method: store and forward

Exchange bandwidth: 8.8G

Flow control: full-duplex flow control, half-duplex back pressure control

MAC address: 8K

Transmission distance: twisted pair cable 100m, fiber 100Mbps maximum

20, 40, 60, 80km

Broadcast storm: real-time broadcast storm suppression

EMC standard:

EN61000-4-2 anti-static (ESD): ±6kV contact discharge, ±8kV air

discharge

EN61000-4-3 electromagnetic field: 10V/m (80-1000MHz)

EN61000-4-6 anti-conduction: 3V (10kHz~150 kHz), 10V (150kHz~80

MHz)

EN55022: EN55022 Class A

MIEN2016/2018/2024/2026 Rack Mount Industrial Ethernet Switch

- 3 -

2. Application Description

2.1. Hardware structure

2.1.1. System structure

The system hardware is mainly composed of the following parts:

The switching network controller uses high-performance ASIC chip

technology to provide Layer 2 wire-speed forwarding of data packets.

The fiber interface adopts an integrated optical transceiver module with

stable performance.

The power supply adopts industrial-grade power supply, with

over-current, over-voltage and EMC protection.

All copper ports and serial ports have EMC protection.

2.1.2. Whole machine structure

The chassis is a 19-inch 1U rack structure, as shown in Figure 2-1, the

whole machine adopts a six-sided fully enclosed structure. Abandon the

traditional flow fan heat dissipation form, reduce the power consumption of the

whole machine, but also improve the stability of the system.

The dimensions are: 482.6*44*210mm.

Figure 2-1 Product appearance

The front panel indicators are shown in Figure 2-2

Figure 2-2 Schematic diagram of front panel indicators

The indicator description is shown in Table 2-1.

Function

LED

LED color

Condition

Status

Power

state

PWR1

Red

Power

connection

Off

Power is not

connected

System

status

RUN

Green

Flashing

System is

working fine

MIEN2016/2018/2024/2026 Rack Mount Industrial Ethernet Switch

- 4 -

Panel

status

100Mbps

Green

The port has

established a

100M

network

connection

Off

No port

connection or

10M access

LINK/AC

Green

Port has

established a

valid network

connection

Flashing

Port has

network

activity

Off

The port has

not

established a

valid network

connection

100M fiber interface

MIEN2018-2S/M and MIEN2026-2S/M have 2 100Base-FX full-duplex

single-mode or multi-mode fiber interfaces, and the connectors can be SC, ST

or FC. Optical fiber interfaces need to be used in pairs (TX and RX are a pair),

TX port is the optical transmitting end, connected to the optical receiving end

RX of the optical interface of another remote switch; RX port is the optical

receiving end, connected to the same optical interface of the same remote

switch The optical transmitter TX.

The 100M fiber interfaces mainly include: SC, ST, FC. As shown in Figure

2-3.

Figure 2-3 Appearance of SC /ST /FC interface optical module

Ethernet RJ45 port

This series of products has 16 or 24 10Base-T/100Base-TX Ethernet

RJ45 ports. Each RJ45 port has an adaptive function and supports automatic

MDI/MDI-X connection. The switch can be connected to terminal devices,

MIEN2016/2018/2024/2026 Rack Mount Industrial Ethernet Switch

- 5 -

servers, hubs or other switches using straight-through network

cables/crossover network cables. Each port supports IEEE802.3x adaptive, so

the most suitable transmission mode (half-duplex or full-duplex) and data rate

(10Mbps or 100Mbps) can be automatically selected (the connected device

must also support this feature). If the devices connected to these ports do not

support auto-negotiation, the ports will send at the correct speed, but the

transmission mode will default to half-duplex.

The power input terminals are shown in Figure 2-4.

Figure 2-4 Schematic diagram of power input terminal

The power requirements of this series of switches are shown in Table 2-2.

Table 2-2 Switch power requirements

Voltage

voltage

range

Operating

temperature

Storage

temperature

Humidity

220VAC/DC

85~265

VAC

47-63Hz

110~370

VDC

-40°C~85°C

5~95%

2.2. Hardware installation

2.2.1. Installation requirements

The industrial Ethernet switch is a single structure, which can be directly

installed on a 19-inch rack. Before installation, first confirm that there is a

suitable working environment, including power requirements, sufficient space,

whether it is close to other network equipment to be connected, and whether

other equipment is in place. Please confirm the following installation

requirements:

Power requirements: standard products use AC220V power supply. For

MIEN2016/2018/2024/2026 Rack Mount Industrial Ethernet Switch

- 6 -

other power supply methods, please refer to the product label, the power

supply label on the housing and the relevant manual

Environmental requirements: temperature -40°C~85°C, relative humidity

5~95% (no condensation)

Grounding resistance requirements: <5

According to the contract configuration requirements, check whether the

optical cable is laid in place and whether the optical fiber connector is suitable

Avoid direct sunlight, keep away from heat sources or areas with strong

electromagnetic interference

The standard product is installed on a 19-inch rack. Check if there are

cables and connectors required for installation

Note:

Be sure to disconnect the power cord before installing or connecting the

Ethernet switch. Calculate the maximum possible current in each power line

and common line, and observe all electrical information to know the

maximum current allowed by lines of different widths. If the current exceeds

the maximum rated current, the wire will overheat and cause serious

damage to the equipment.

At the same time, you must also pay attention to the following:

Separate the paths of power lines and equipment lines. If the two paths

must cross, make sure that these lines are perpendicular at the intersection.

It is not allowed to lay signal wires or communication wires and power wires

in the same pipe. To avoid interference, wires with different signal

characteristics should be separated. We can use the type of signal

transmitted in a line to determine which lines should be separated. It is

strongly recommended to label all equipment lines in the system when

necessary.

The switch must be connected to the protective ground:

Grounding and wiring can effectively suppress the noise impact caused

by electromagnetic interference. The ground connection should be made

before connecting the equipment, from the ground screw to the ground

surface.

2.2.2. Host installation

The installation dimensions of MIEN2016 and MIEN2024 are shown in

Figure 2-5.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Maiwe Changer

Maiwe

Maiwe MIEN2208-F Manuel utilisateur

Maiwe

Maiwe MISCOM7028GX Series Manuel utilisateur

Maiwe

Maiwe MIEN2205 Manuel utilisateur

Maiwe

Maiwe MIEN2208 Series Manuel utilisateur

Maiwe

Maiwe MIEN6208 Series Manuel utilisateur

Maiwe

Maiwe MISCOM8028GX-4XGF-16GF-8GC Manuel utilisateur

Maiwe

Maiwe MIEN2205 Manuel utilisateur

Maiwe

Maiwe MISCOM8028-4GF Manuel utilisateur

Maiwe

Maiwe MIEN2216 Manuel utilisateur

Maiwe

Maiwe MISCOM7212GP Series Manuel utilisateur

Maiwe

Maiwe MIEN2204 Series Manuel utilisateur

Maiwe

Maiwe MIGE2206G-2GF-4GT Manuel utilisateur

Maiwe

Maiwe MIEN3020G-4GC-16GT Manuel utilisateur

Maiwe

Maiwe MIEN3024 Manuel utilisateur

Maiwe

Maiwe MIEN5208 Series Manuel utilisateur

Maiwe

Maiwe MIGE3028-4GF Manuel utilisateur

Maiwe

Maiwe MIGE2210 Series Manuel utilisateur

Maiwe

Maiwe MISCOM7220G-4GF-16GT Manuel utilisateur

Maiwe

Maiwe MIEN2205 Manuel utilisateur

Maiwe

Maiwe Admas2208P-M12-8TPOE Manuel utilisateur

Maiwe

Maiwe MIEN2206 Manuel utilisateur

Maiwe

Maiwe MIEN2208 Series Manuel utilisateur

Maiwe

Maiwe MIEN1203 Manuel utilisateur

Maiwe

Maiwe MISCOM8220G Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
