Magnetic MHTM FlowMotion Manuel utilisateur
Description
Swing door mSwing
MHTM™ FlowMotion®
Control unit MGC
Doc.ID: 5817,0031EN
Version 00
2
Control unit MGC
MAGNETIC AUTOCONTROL GMBH
Grienmatt 20
D-79650 Schopfheim
Germany
Phone +49 7622 695 5
Fax +49 7622 695 802
www.magnetic-access.com
3
Control unit MGC
Contents
Contents
1 Notices on the document 7
1.1 Purpose and contents of this description 7
1.2 Symbols and illustrations used in this document 8
1.2.1 Warning notes and notes 8
1.3 Target group 9
1.3.1 Personnel – activities and qualifications 9
2 Digital inputs, digital outputs and relay outputs 10
2.1 Digital inputs 10
2.2 Digital outputs and relay outputs 12
2.3 Illumination 14
3 Parameterising mSwing 15
3.1 Parameterisation directly at the control unit 15
3.2 Parameterisation via the "mSwing Connect" programme 16
3.2.1 Establishing connection 16
3.2.2 Checking and updating software version "mSwing
Connect 18
3.2.3 Updating control unit MGC 19
4 Description "mSwing Connect" programme 20
4.1 Overview 20
4.2 Swing door mSwing status view 21
4.3 "Passage control" tab 23
4.4 "Settings" tab 24
4.5 "Service" tab 26
4.5.1 Selecting target stop and setting target positions 26
4.5.2 Description of the buttons and parameters 28
4.6 "Safety settings" tab 30
4.6.1 Activating "Safety" tab and
entering safety parameters 30
4.6.2 Safety parameters for shortened blocking elements
"bracket" 33
4
Control unit MGC
Contents
5 Parameterisation directly at the control unit MGC 34
5.1 Changing menu language 34
5.2 Entering password 38
5.3 Control unit elements 39
5.4 Displays of the control unit 40
5.5 Symbols in the display 42
5.5.1 Control button functions 42
5.5.2 Further symbols 43
5.6 Setting display contrast 44
5.7 Protecting parameterisation from access 44
5.8 Parameterising value 44
5.9 Switching the "Service" mode on and off 46
6 Description of menus and parameters 47
6.1 "Information" menu 47
6.2 "Settings" menu 48
6.2.1 Hold-open time 48
6.2.2 Permanent open 48
6.2.3 Speed 49
6.2.4 Safety/Security 50
6.2.5 Signalling 51
6.3 "Inputs/Outputs" menu 51
6.3.1 Inputs 51
6.3.2 Outputs 51
6.4 "Service" menu 52
6.4.1 Gate HW 52
6.4.2 Further parameters 54
6.5 Menu "System" 54
6.6 "Information" menu 55
6.7 "Motor MHP2" menu 55
6.8 "Safety Controller" menu 55
6.9 "Factory settings" menu 56
5
Control unit MGC
Contents
7 Function description 58
7.1 Definition of "left" and "right" 58
7.2 Start-up and regular movement sequence 59
7.2.1 Power-off state 59
7.2.2 Homing 59
7.2.3 Regular movement process 59
7.2.4 Permanent open 59
7.3 Pulse operation in both directions with vend count 60
7.4 Special cases within the motion sequence 60
7.4.1 Turning back during the closing movement 60
7.4.2 Vandalism attempt 60
7.4.3 Obstacle detection 60
7.4.4 Emergency 61
8 Corrective action 62
8.1 Safety in troubleshooting 62
8.2 Malfunctions pedestrian gate 63
8.3 Event, warning and error messages in the display 63
8.3.1 Event, warning and error messages – Logic control
(control unit) 64
8.3.2 Event, warning and error messages – Motor MHP2 66
8.3.3 Event, warning and error messages –
Safety Controller 69
8.3.4 Event, warning and error messages – All modules 70
8.4 Performing reset 71
9 Menu structure 72
9.1 Menu structure directly on the control unit MGC 72
Index 75
6
Control unit MGC
7
Control unit MGC
Notices on the document
1 Notices on the document
1.1 Purpose and contents of this description
This document describes the control unit MGC from the programme versions
listed below.
Software number (software #) and software version (SW version) are displayed
in the menu "Module info".
Designation Software # SW version
Gate Controller 4915,1006 2.0
MHP2 motor 4915,4003 1.0
Safety Controller 4915,3014 1.0
mSwing Connect 4910,5052 V1.0.0
Table 1: Programme versions control unit MGC
IMPORTANT!
For information on design and function, for technical data,
installation and assembly, electrical connection, commissioning
and cleaning and maintenance, see the separate operating
instructions "Swing door mSwing MHTM™ FlowMotion® (Doc.ID:
5817,0032)".
8
Control unit MGC
Notices on the document
1.2 Symbols and illustrations used in this document
1.2.1 Warning notes and notes
Warning notes are characterised by pictograms in these operating instructions.
A warning note starts with a signal word that expresses the extent of the
hazard.
It is absolutely essential to observe the warning notes and to proceed with
caution in order to prevent accidents as well as bodily injuries and property
damage.
Warning Notes
DANGER
The signal word DANGER points to an immediately dangerous
situation, which leads to death or severe injuries if it is not
avoided.
WARNING
The signal word WARNING points to a potentially dangerous
situation, which can lead to death or severe injuries if it is not
avoided.
CAUTION
The signal word CAUTION points to a potentially dangerous
situation, which can lead to minor injuries if it is not avoided.
NOTICE
The signal word NOTICE points to a potentially harmful situation,
which leads to property damage if it is not avoided.
9
Control unit MGC
Notices on the document
Notes and recommendations
IMPORTANT!
The signal word IMPORTANT highlights useful notes and
recommendations as well as information for an efficient and
trouble-free operation.
1.3 Target group
1.3.1 Personnel – activities and qualifications
All work on the control unit may only be carried out by technicians and
Magnetic MHTM™ FlowMotion® service experts with the following
qualifications.
Designation Qualification
Technician › Has completed training as a plant mechanic, plant fitter,
assembly mechanic, assembly fitter or has a comparable
technical education.
› Has completed training as an electrical safety expert.
› Has additional knowledge and experience.
› Knows the associated technical terms and regulations.
› Can assess the work assigned to her/him, recognises
possible dangers and take suitable safety measures.
Magnetic MHTM™ FlowMotion®
service expert
› Meets all requirements of the technician.
› Trained and authorised by Magnetic.
Table 2: Qualification of the personnel – control unit MGC
10
Control unit MGC
Digital inputs, digital outputs and relay outputs
2 Digital inputs, digital outputs and relay outputs
WARNING
Improper wiring and parameterisation of the control unit!
Improper wiring and parameterisation of the control unit can
lead to undesired functions and thus to injuries.
› Only MHTM™ FlowMotion® service experts or skilled
technicians or electrical safety experts may wire up and
parameterise the control unit.
› The electrical connection of the signal transmitters to the IN1
to IN8 inputs must fit the parameterisation.
Parameterisation: äPage 15, chapter 3.
2.1 Digital inputs
Definition of "Left" and "Right": äPage 58, chapter 7.1.
By parameterising the inputs, you assign certain functions to the inputs. For
example, if you parameterise the "Illumination off" function for input IN7, you
must connect a illumination to this input.
If the function is marked with "|", the input is inverted (Fail Safe).
The following functions are assigned to the inputs as default settings:
Clamp Description Function
IN1 Digital input 1 | Emergency open
IN2 Digital input 2 Open from left
IN3 Digital input 3 Open from right
IN4 Digital input 4 –
IN5 Digital input 5 Confirm warnings
IN6 Digital input 6 Close (Inhibit opening)
IN7 Digital input 7 Illumination off
IN8 Digital input 8 –
Table 3: Factory settings "Digital inputs"
