MTI RU-888-0 RFID Module
User Manual Version 4.0
MTI Group Proprietary Information
Any unauthorized use, duplication, reproduction, or disclosure of this
document may be considered as infringement of MTI Group’s intellectual
Content
1. Start Demo SW
2. Advanced Reader Setting
3. Inventory Run
4. Advanced Tag Setting
WARNING：Please keep more than 20 cm away when doing the test.
1. Start Demo DW
1. 1 Double click the icon as in Fig.1
Fig.1
1.2 Plug Antenna and USB cable you could see the Demo SW shown Online as in
Fig.2
Fig.2
2. Advanced Reader Setting
2. 1 Right click the MTI module and will show “Reader Setting ” on screen. You
could start to set the region, frequency, and output power as in Fig.3.
Fig.3
2.2 Please you must set Region, Power Level, and choose Hopping in Frequency
Column when you would like to do the normal test. Press Submit to sent the parameters
and press exit to leave this window as shown in Fig.4. 「RSSI and LBT」and「Gen2
Setting」Column could let you do more
advantage setting. The default value of sensitivity level is -84 dBm. Please shift
the button if you
would like to set another value.
Fig.4
3. Inventory Run
3. 1 After setting the parameter, please press “ Start Scan “to start the inventory run
as shown in Fig.5 and Fig.6.
Fig.5
Fig.6
4. Advanced Tag Setting
4.1 Please right-click on the tag that you would like to change the setting as
shown in Fig.7.
Fig.7
4.2 You could set EPC, Password, Lock, or Kill the selected tag in this window as
shown in Fig. 8.
Fig. 8
4.3 Option function : Memory Bank Read/Write Function. You could read
Reserved, EPC, TID, and User Bank at Memory Column. Choose the one you would like to
know the information and press the Read Button as shown in Fig.9.
Fig. 9
a. You could see this kind of picture as in Fig. 10 if MTI module could get complete
information from the tag.
Fig. 10
b. You could see this kind of picture as in Fig. 11 if MTI module couldn’t get
complete information from the tag.
Fig. 11
4.4 Please read user bank if you would like to write any information into user bank.
Write the information into the byte you would like to modify and press Set button as shown in
Figure 12.
Fig. 12 GUI would shown pass message as shown in
Fig. 13.
Fig. 13
