8528T Voice Terminal

Feature Package 3

User’s Manual

555-021-776

Comcode 107964488

Issue 2

December 1996

WARRANTY

All terms and conditions specified in the owner’s agreement with Lucent

Technologies apply.

NOTICE

While reasonable efforts were made to ensure that the information in this

document was complete and accurate at the time of printing, Lucent

Technologies can assume no responsibility for any errors. Changes or

corrections to the information contained in this document may be incorporated

into future issues.

TO ORDER COPIES OF THIS DOCUMENT

DISCLAIMER

Intellectual property related to this product (including trademarks) and registered

to AT&T Corporation has been transferred to Lucent Technologies Incorporated.

Any references within this text to American Telephone and Telegraph Corporation

or AT&T should be interpreted as references to Lucent Technologies

Incorporated. The exception is cross-references to books published prior to

December 31, 1996, which retain their original AT&T titles.

HERITAGE

Lucent Technologies — formed as a result of AT&T’s planned restructuring —

designs, builds, and delivers a wide range of public and private networks,

communication systems and software, consumer and business telephone

systems, and microelectronics components. The world-renowned Bell

Laboratories is the research and development arm for the company.

THE “CE” MARK

The “CE” mark affixed to this equipment means that it conforms to the European

Union Electromagnetic Compatibility Directive (89/336/EEC) and the Low Voltage

Directive (73/23/EEC).

HEARING AID COMPATIBILITY

These voice terminals are Hearing Aid Compatible (“HAC”). In addition, some

units have an “HAC” label on them.

TRADEMARKS

DEFINITY and 5ESS are registered trademarks of Lucent Technologies.

Middletown, NJ 07748-9972 Printed in USA

Write: Lucent Technologies BCS Publications Center

P.O. Box 4100

Crawfordsville, IN 47933

Call: Voice 1 800 457-1235

International Voice 317 361-5353

Fax: Fax 1 800 457-1764

International Fax 317 361-5355

Order: Document No. 555-021-776

Issue 2, December 1996

INTERFERENCE WARNING INFORMATION - Part 15 of FCC Rules

Federal Communications Commission (FCC) Rules require that you be

notified of the following:

This equipment has been tested and found to comply with the limits for a

Class A digital device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference in

a residential installation. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause interference to radio or television

reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the

following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

You may find the following booklet prepared by the Federal Communications

Commission helpful:

How to Identify and Resolve Radio-TV Interference

Problems.

This booklet is available from the U.S. Government Printing

Office, Washington, D.C. 20042, Stock No. 004-000-00345-4.

IMPORTANT SAFETY INSTRUCTIONS

Only the most careful attention has been devoted to quality standards in

the manufacture of your new telephone. Safety is a major factor in the

design of every set. But, safety is YOUR responsibility too.

Please read carefully the helpful tips listed below and on the next page.

These suggestions will enable you to take fullest advantage of your new

voice terminal. Then, retain these tips for later use.

When using your telephone equipment, the following safety precautions

should always be followed to reduce the risk of fire, electric shock, and

injury to persons.

Read and understand all instructions.

Follow all warnings and instructions marked on the telephone.

This telephone can be hazardous if immersed in water. To avoid the

possibility of electrical shock, do not use the telephone while you are

in the bathtub or shower, or when you are wet. If you accidentally

drop the telephone into water, do not retrieve the equipment until you

have first unplugged the line cord from the modular wall jack. Do not

reconnect the telephone until it has dried thoroughly.

Avoid using the telephone (other than the cordless type) during

electrical storms in your immediate area. There is a remote risk of

electric shock from lightning. Urgent calls should be brief. Even

though protective measures may have been installed to limit

electrical surges from entering your home or business, absolute

protection from lightning is impossible.

If you suspect a natural gas leak in the vicinity of the telephone,

report it immediately, but use a telephone away from the area in

question. The telephone’s electrical contacts could generate a tiny

spark. While unlikely, it is possible that this spark could ignite heavy

concentrations of gas.

Never push objects of any kind into the telephone through housing

slots since they may touch hazardous voltage points or short out

parts that could result in a risk of electric shock. Never spill liquid of

any kind on the telephone. If liquid is spilled, however, dry

immediately, and refer any service problems to qualified service

personnel.

To reduce the risk of electric shock, do not disassemble the

telephone. There are no user serviceable parts inside. Opening or

removing covers may expose you to hazardous voltages. Incorrect

reassembly can cause electric shock when the telephone is

subsequently used.

Slots and openings in the housing must not be blocked or covered.

The openings should never be blocked by placing the telephone on a

sofa, rug or other similar surface. This product should never be

placed near or over a radiator or heat register. This product should

not be placed in a built-in installation unless proper ventilation is

provided.

The telephone should be operated only from the type of power

source indicated on the marking label. If you are not sure of the type

of power supply being used, contact a qualified service person.

Do not allow anything to rest on the power cord. Do not locate this

product where the cord will be abused by persons walking on it.

Do not overload the AC wall outlets and extension cords as this can

result in risk of fire or electric shock.

Before cleaning, disconnect all cords from the telephone. Do not

use liquid cleaners or aerosol cleaners. Use a damp cloth for

cleaning.

Disconnect the cords on the telephone and refer servicing to qualified

service personnel when these conditions exist:

When the power supply cord or plug is damaged or frayed.

If liquid has been spilled into the product.

If the product has been exposed to rain or water.

If the telephone does not operate normally by following the

operating instructions. Do not attempt to adjust any other

controls since doing so may result in damage and will require

extensive work by a qualified technician to restore the product to

normal operation.

If the product has been dropped or the housing has been

damaged.

If the product exhibits a distinct change in performance.

SAVE THESE INSTRUCTIONS

When you see this warning symbol on the product, refer to the

instructions booklet packed with the product for information before

proceeding.

Contents

Introduction……………………………………………………………1

Organization of this Manual ………………………………………1

Conventions Used in this Manual…………………………………2

A Note on the Term, System Manager …………………………3

Your ISDN 8528T Voice Terminal …………………………………4

Feature Descriptions ………………………………………………8

Voice Features………………………………………………………8

Features Accessed with the Display and Softkeys………………9

Voice Features………………………………………………………11

Answering and Placing a Call ……………………………………11

Conference…………………………………………………………12

Drop…………………………………………………………………12

Hold…………………………………………………………………13

Message Retrieval ………………………………………………13

Mute ………………………………………………………………14

Redial (Last Number Dialed) ……………………………………14

Speakerphone and One-Way Speaker …………………………15

Transfer ……………………………………………………………17

Features Accessed with the Display and Softkeys……………18

Entering and Exiting Softkey Mode

(Using the Menu and the Exit Buttons) …………………………19

Using the Next, the Prev, and the Dir Buttons …………………20

Responding to Quit and Done……………………………………20

A Softkey Display Screen Flowchart ……………………………20

Setting the Clock …………………………………………………22

Setting the Speakerphone ………………………………………24

Adding, Editing, and Deleting a Number and Name

in the Directory ……………………………………………………26

Viewing a Directory Entry (and Placing a Call)…………………33

Using the Dir Button to Place a Call ……………………………35

Using the Call Log…………………………………………………36

Locking and Unlocking the Directory, Call Log,

and All Softkeys …………………………………………………54

Changing or Removing Your Password…………………………58

Choosing the Contrast Level for the Display……………………60

Selecting a Personalized Ring……………………………………62

Setting the Rate at Which You View

the Display Messages ……………………………………………64

Turning on or off Softkey Information Tones……………………66

Setting the Number of Names on the Directory Page…………68

Self-Test……………………………………………………………70

Tones and Their Meanings ………………………………………72

Voice Terminal Tones ……………………………………………72

Labeling and Installing the Designation Card

and the Telephone Number Card ………………………………72

Installation……………………………………………………………74

Contents of the 8528T Package…………………………………74

Connecting the 8528T to the System……………………………74

Desktop Installation ………………………………………………78

Attaching Adjunct Equipment ……………………………………80

Technical Description ……………………………………………81

Introduction

The Lucent 8528T voice terminal can be added to your Integrated

Services Digital Network (ISDN) communications system. In order to

provide you with excellent quality and reliability, Lucent designed this

new voice terminal with the latest advances in telecommunications

technology.

The 8528T voice terminal offers 28 call appearances, Mute, Redial,

Conference, Drop, Transfer, and Hold buttons, a Speakerphone which

can also be optioned as a listen-only Speaker, a Volume control, and an

Adjunct jack for adjunct equipment such as a headset adapter — all that

you will need for easy and efficient call-handling. Four softkeys (the

keys with arrows printed on them) and four display control buttons

located below a 2-line by 24-character liquid crystal display can be used

to access such features as a personal Directory, a Call Log which lists

the most recent incoming and outgoing calls, and a personalized ringing

pattern for the voice terminal.

The following features have been included for the

hearing and visually impaired person:

Two small bars have been placed on the 5dial

pad key;

The rate at which the display messages appear

on your screen can be set at Slow,Medium, or

Fast;

Conﬁrmation and error tones;

Compatibility with inductively coupled hearing

aids.

ORGANIZATION OF THIS MANUAL

This manual is arranged into the following sections:

Your ISDN 8528T Voice Terminal — shows the top and bottom

views of the 8528T and explains its features.

Feature Descriptions — lists the voice features and the features

that can be accessed with the softkeys, tells what each feature does,

and suggests how you might use it.

Voice Features — gives step-by-step procedures on using voice

features.

Features Accessed with the Display and Softkeys — describes

the softkeys and how to use them to access features such as setting

up and using a personal Directory of frequently called numbers and

viewing a Call Log of incoming and outgoing calls.

Tones and Their Meaning — lists and describes the various voice

terminal tones.

Labeling and Installing the Designation Card — explains how to

remove and label the designation card.

Installation — gives brief step-by-step procedures for connecting

your voice terminal to the system, desktop installation such as

connecting the handset and the line cord, and, if appropriate,

attaching adjunct equipment.

Technical Description — provides information on the technical

aspects of the 8528T voice terminal.

CONVENTIONS USED IN THIS MANUAL

A rectangular box containing a feature name, such as

cbbbbbbbc

bbbbbbb

Redial

represents any button having a feature assigned to it, with a

corresponding feature name label.

A 2-line screen, such as

MENU >

Directory CallLog Option

cccbbbbbbbbbbbbbbbbbbbbbbbbcccbbbbbbbbbbbbbbbbbbbbbbbb

represents the display that is shown when you press the

cbbbbbbc

bbbbbb

display

control button. The second line of the display lists the features you can

access by using the four softkeys (the buttons labeled with arrows).

Table des matières

Autres manuels Lucent Technologies Terminal tactile

Lucent Technologies

Lucent Technologies CIB 7102 Manuel utilisateur

Lucent Technologies

Lucent Technologies SLC 5 Series Manuel utilisateur

Lucent Technologies

Lucent Technologies Voice Terminal 8434DX Manuel utilisateur

Lucent Technologies

Lucent Technologies Definity 8434DX Manuel utilisateur

Lucent Technologies

Lucent Technologies Definity 8510T Manuel utilisateur

Lucent Technologies

Lucent Technologies CIB 2853 Manuel utilisateur

Lucent Technologies

Lucent Technologies CIB 3023 Manuel utilisateur

Lucent Technologies

Lucent Technologies CIB 3000 Manuel utilisateur

Lucent Technologies

Lucent Technologies SLC-2000 Access System Central Office... Manuel utilisateur

Lucent Technologies

Lucent Technologies MLC-5 Manuel utilisateur

Lucent Technologies

Lucent Technologies 8400 Series Manuel utilisateur

Lucent Technologies

Lucent Technologies SLC-2000 Access System Central Office... Manuel utilisateur

Lucent Technologies

Lucent Technologies Merlin Magix Manuel utilisateur

Lucent Technologies

Lucent Technologies Mitel SX200D Series Manuel utilisateur

Lucent Technologies

Lucent Technologies 8400 Series Manuel utilisateur

Manuels Terminal tactile populaires d'autres marques

Wincor Nixdorf

Wincor Nixdorf iPOS plus Advanced Manuel utilisateur

Ingenico

Ingenico AXIUM EX4000 Manuel utilisateur

Heisei Electronics

Heisei Electronics Q-POS 815 Manuel utilisateur

Amano

Amano MTX-15 Manuel utilisateur

FLOWBIRD

FLOWBIRD CWT Compact Touch Manuel utilisateur

Demco

Demco SP7 Manuel utilisateur

Lathem

Lathem PC600 Series Manuel utilisateur

Partner

Partner MF-2352 Manuel utilisateur

NCR

NCR RealPOS 7460-2 Manuel

Simrad

Simrad MS50 Instructions de montage

Unitech

Unitech MR350 MKII Guide de démarrage rapide

Jungheinrich

Jungheinrich WMT 210 Manuel utilisateur

Motorola

Motorola MTP850 Manuel utilisateur

YASKAWA

YASKAWA 62H-MDC0 Manuel utilisateur

MVG industries

MVG industries NeptuLink Manuel utilisateur

Price Industries Limited

Price Industries Limited FDC Manuel d'instructions

Honeywell

Honeywell TemaKey Manuel utilisateur

EBN

EBN BPC65-B-A16G Manuel utilisateur
