Lorex SG6157 Manuel utilisateur

It’s all on the web

Quick Set-u

Guide

Image Device Color CMOS (510H x 492V)

Resolution 330 TV Lines

Shutter Control Auto 1/60 – 1/15,000 SEC

Lens 6mm F1.8

Minimum Illumination 3.0 LUX, 0 LUX with IR LED

Power Requirement 9V DC Adapter (included)

Operating Temperature 14ºF to 113ºF (-10ºC to 45ºC)

Housings ABS Plastic

4. View the Camera Picture BUSINESS & HOME

a. Turn on your TV WEATHER RESISTANT COLOR

CAMERA with NIGHT VISION

Product Information Specification Sheets

Model SG6157

User Manuals Software Upgrades

Quick Start Guides Firmware Upgrades

b. To view the picture from the camera, switch to

the Video mode (i.e. AV, or AUX mode).

Refer to your VCR’s (or camera’s) owner’s manual

for instructions for connecting the VCR

This camera can also be connected to a video

cassette recorder (VCR) or Digital Video Recorder

(DVR) that provides RCA camera cable input jacks.

Specifications

www.lorexcctv.com

VISIT

Strategic Vista International Inc.

As our products are subject to continuous improvement, SVII

and its subsidiaries reserve the right to modify product design,

specifications and prices, without notice and without incurring

any obligation. E&OE

1. Confirm Package Contents 2. Mount the Video Camera 3. Connect the Camera to the TV

Features:

•Weather Resistant camera ideal for outdoor or

indoor applications

•12 high intensity IR LED’s provide illumination in

no/low light conditions

•Color video in standard lighting, automatically

changes to B&W video in low light

•Easily connects to most TV’s

•Mounts Easily to Walls or Ceilings

100 ft extension cable

Camera Mounting Bracket

SG6157 Camera with low light

illumination, 6’ cable and mounting

bracket

b. Connect the AC adapter to the power socket on

the cable

a. Plug the 6 pin DIN female end of the extension

cable into the camera’s 6 pin DIN male connector.

a. Install the camera bracket in the desired

location.

b. Install the camera on the mounting bracket

c. Plug the 9V DC adapter to the wall

1) Use the threaded holes Video Out (to TV/VCR)

To came

To AC ada

Standard AC Adapter

2) The 6 ft camera cable has a 6 pin DIN male

connector on the end

The mounting bracket is designed to permanently

mount the camera (i.e. to wall or ceiling)

c. Run the supplied 100 ft extension cable

between the security monitor (or TV) and the

camera.

The 100 ft extension cable has a 6 pin DIN female

connector on one end, and an RCA and power

connector on the other end.

Warning Window Sticker

Take Sunshade Off

1. Hold body of housing (rear of camera faces you)

2. Pull sunshade backwards (towards you)

Put Sunshade On

1. Push the sunshade forward (away from you)
