Logitech PRO RACING WHEEL Manuel utilisateur

PRO RACING WHEEL

for Xbox Series XS, Xbox One and PC

pour Xbox Series XS, Xbox One et PC

SETUP GUIDE GUIDE D’INSTALLATION

•

ENGLISH . . . . . . . . . . . . . . . . . . . . . . . . .3

FRANÇAIS . . . . . . . . . . . . . . . . . . . . . . . 26

ESPAÑOL . . . . . . . . . . . . . . . . . . . . . . . .49

PORTUGUÊS . . . . . . . . . . . . . . . . . . . . . . 72

PRO RACING WHEEL

for Xbox Series XS, Xbox One and PC

适用于 Xbox Series X|S、Xbox One 和 PC

SETUP GUIDE  设置指南

•

3 ENGLISH

CONNECTIVITY

1 USB connection to PC / console

2 Peripheral ports*

3 Power connector

*NOTE:

–Not a standard USB connection. Only Logitech

racing peripherals will function in these ports.

Other USB peripherals will not function and

should not be connected.

Please ensure that the power connector is

fully inserted; otherwise, your PRO Wheel

may not function correctly. As you insert

the connector, you might feel a small click,

butyou can push past this until the connector

is fully inserted. Do not use excessive force to

insert the connector.

4 ENGLISH

INSTALLATION

1 DESK

1a. Place the wheel base on your desk and

ensure the feet at the bottom are aligned

against the edge.

1b. Insert the clamp into the hole at the front.

1c. Tighten the clamp by adjusting

the screw handle.

Once the clamp has come into contact

with the desk, you only need between

a half and one full turn of the handle

toachieve the correct level of clamping.

Donot overtighten.

< 50 mm (1.97 in)

1b 1c

NOTE:

–Also be aware of the construction of your

desk and its suitability for clamping a

high-torque wheel to it. Some desks use

a hollow-core construction, for example,

where you have a top piece of material and

a bottom piece. Those pieces are likely to

be thin and are unlikely to stand up to the

forces applied when the wheel is clamped

in place. Logitech recommends only

clamping your PRO Wheel to a desk made

from a solid material, such as MDF or wood.

5 ENGLISH

2 RACING SEAT

2a. Use the three bolt holes on the

underside of the PRO Racing wheel to

attach it to most major racing seats.

–You will need 3 x M6X1 bolts

(notincluded) with a maximum

depth inside the wheel base of

15mm. Remember to account for the

thickness of the surface that you are

attaching the wheel base to.

–Using a longer bolt than this will

damage the wheel unit, so use

washers if needed to ensure that the

bolts do not encroach too far inside

the wheel base.

–You only need to hand tighten.

Donot use power tools to tighten

the bolts.

2b. You can use the included cover to ll

the clamp hole when attaching to

aracing seat.

WARNING:

–Do not use the wheel rim as leverage

to assist you when getting into or out

of your racing seat as this will damage

your PRO Racing Wheel.

M6X1

M6X1 L = T + 15MM

T L

6 ENGLISH

3 ATTACHING WHEEL RIM

3a. Connect the wheel rim to the wheel

base, ensuring that the shaft is

aligned correctly.

3b. Attach the wheel by locking the

quick release ring in its “squeezed”

position. There’s no need to hold it

there while attaching the wheel rim.

3c. Push the wheel rim onto the shaft

on the wheel base until you hear the

quick release ring lock into position.

*click*

7 ENGLISH

POWER ON AND SOFTWARE

1 Power on the wheel by pressing the Power button

on the front of the wheel base. The wheel rim

will spin slightly to check its calibration and then

centre itself.

2 The settings display on the wheel base will then

prompt you to choose which platform you wish

toplay on.

3 Use either the left or the right dial on the steering

wheel to select the platform and then push

thedial in until it clicks to make your selection.

–To play on your console simply load the

compatible game of your choice and start

racing.

–On PC you must rst download and install the

latest version of the Logitech G HUB software

at www.logitechG.com/GHUB. Once that is

installed you can begin racing in the title of your

choice. Remember that some titles will require

that you rst congure the wheel in the control

settings of the game before it will function.

You may also wish to make use of the G923

compatibility mode for some titles which may

be required to either make the wheel work,

ortosimplify set up. Details of how to access

thiscan be found in the section of the manual

thatcovers the settings display.

Once nished, to power o the wheel, press and

hold the power button for 2 seconds.

1 2

www.logitechG.com/ghub

8 ENGLISH

FEATURES

1 Gear Down

2 Y, X and LT buttons

3 Directional Pad

4 View and LSB buttons

5 Left Dual Clutch Paddle

6 Left Adjustment Dial and push button*

7 Gear Up

8 A, B and RT buttons

9 Menu and RSB buttons

10 Right Dual Clutch Paddle

11 Right Adjustment Dial and push button*

12 Xbox button

1 OLED Settings display and RPM LEDs

2 Settings button

3 Power button

4 Clamp recess cover

1 7

1 2

9 ENGLISH

Your Logitech G PRO Racing Wheel features

a direct drive motor that will provide force

feedback with supported games and systems.

In supported titles, you will also experience our

next generation approach to force feedback:

TRUEFORCE.

TRUEFORCE integrates directly with game

physics and audio to unlock high-denition,

real-time force feedback. Tire grip, suspension,

weight, horsepower — even unique engine

sound resonance — are immediately and

accurately felt through the wheel.

For a list of supported titles visit

logitechG.com/support/PRO_Wheel_xb

FORCE FEEDBACK

NOTE:

The direct drive motor in your wheel can

produce very high levels of torque (up to 11 Nm).

Please exercise caution when using the wheel

and set the level of force feedback that is within

the limits of the person using it.

This product is not intended for use by small

children.

If you crash a vehicle whilst racing in a

simulation title, the wheel may pull itself out of

your hands. Do not attempt to stop the wheel

from moving as this may result in injury. You can

usually stop the wheel by pausing the game.

OnPC, this can be done using your keyboard

(often the Escape key, but other games may

dier). Onconsole, you may need to unplug

theUSB cable of your wheel from the console.

Under heavy use, you may notice a slight odor

from the exhaust at the back of the wheel. This

is normal and will fade over time.

Additionally, if you run exceptionally long

racing sessions with the wheel at maximum

torque, certain parts of the wheel may become

warm to the touch, especially thequick

release collar on the steering wheel and

thequick release adapter on the wheel base.

In such circumstances, it is recommended

that youallow your PRO wheel to cool down

before removing the wheel rim and / or moving

thewheel base from where it is mounted.

10 ENGLISH

SETTINGS

Press the Settings button on the wheel base to

access the Settings menu. In the settings menu

you can congure dierent settings for your

wheel (and pedals, if attached) in5dierent

onboard proles or, if connected to a PC,

directly adjust the currently active prole in

G HUB. You can then easily switch between

proles when you change game titles (or even

when you change cars in the same game title).

All settings are “live adjustable” and will take

eect as soon as you nish adjusting.

The 5 dierent onboard proles can be renamed

using G HUB. If you are racing on console, you

can connect the PRO Wheel to your PC, rename

the onboard proles and those names will still be

present when you connect back to your console.

Menu Navigation

Use either of the adjustment dials on the wheel

toscroll up/down menus or adjust a setting.

Pressthe dial in to select or to conrm a selection.
