Logitech G923 Manuel utilisateur

G923

Racing Wheel and Pedals For PlayStation®4

Volant de course et pédales pour PlayStation®4

SETUP GUIDE |GUIDE D’INSTALLATION

ENGLISH . . . . . . . . . . . . . . . . . . . . . . . . .3

FRANÇAIS . . . . . . . . . . . . . . . . . . . . . . . 14

ESPAÑOL . . . . . . . . . . . . . . . . . . . . . . . .25

PORTUGUÊS . . . . . . . . . . . . . . . . . . . . . . 36

G923 RACING WHEEL AND PEDALS FOR PLAYSTATION®4

620-008913.002

USB

3PS4™

logitechG.com/support/g923-ps4

USB

3ENGLISH

CONNECTIONS AND MOUNT POINTS

1 Mounting clamps

2 Cable management cleat

3 Optional shifter connection (DB-9 male)

4 USB cable

5 Pedal unit connection (DB-9 female)

6 Power connection

7 Bolt mounting points (uses M6X1 bolts)

OPTIMAL CABLE ROUTING

USB and pedal cables (1, 2) should be routed

throughinnerchannels.

Power and optional shifter cables (3, 4) should be routed

throughouter channels.

Cables may be wrapped multiple times around cable

management cleat to take in slack.

14 2 3

4ENGLISH

USB

PS4

USB

INSTALLATION — PS4™

— PC

Attach power adapter and USB cables as shown.

Every time your racing wheel connects with your system,

itwillrotate fully to each side and then to the center to calibrate.

Your wheel will be ready once this calibration is completed.

For PC to enable the force feedback and RPM LED features

onyour G923 Wheel and Pedals you must install the Logitech

G HUB software. This can be found at logitechG.com/

support/g923-ps4.

TRUEFORCE and advanced features require game integration.

Visit logitechG.com/support/G923-ps4 for a complete list

ofsupported games.

5ENGLISH

MOUNTING CLAMPS

G923 Racing Wheel is equipped with

a built in clamping system for mounting to a table.

Push down and rotate clamp knobs to lock or unlock.

Rotate clamp knobs to tighten or loosen clamps.

Note:

Clamp extenders should be removed for attachment

tothickertables.

6ENGLISH

BUTTONS

1 Left bumper

2 Directional pad

3 View button

4 L3 button*

5 +/- Setting Adjustment buttons*

6 Right bumper

7 X, ¡, o, rbuttons

8 OPTIONS button

9 R3 button*

10 Setting Selection Dial and Select button*

11 PS button

1 6

* Requires supported games on PS4. Assignable in any game on PC using either

in game assignment or Logitech G HUB software.

7ENGLISH

FORCE FEEDBACK

Your Racing Wheel contains dual motors that will provide

forcefeedback with supported games and systems.

In supported titles you will also experience our next generation

approach to force feedback: TRUEFORCE.

TRUEFORCE integrates directly with game physics and audio

to unlock high-denition, real-time force feedback. Tire grip,

suspension, weight, horsepower—even unique engine sound

resonance—are immediately and accurately felt through

thewheel.

Supported titles on PlayStation®4 and PC may implement

TRUEFORCE high-denition force feedback. For a list of

supported titles visit logitechG.com/support/g923-ps4

Note:

Your Racing Wheel has an overheat protection circuit safeguard

to protect it under high-temperature operating conditions.

Inrare instances, force feedback features may shut down

duringuse while controls continue to operate.

If this occurs, allow the wheel to cool down and power

itdownbyunplugging it. If this occurs frequently,

contactproduct support.

8ENGLISH

FEATURES

1 Clutch pedal

2 Brake pedal

3 Throttle pedal

4 Textured heel rest

1 2 3

9ENGLISH

5 Bolt mounting points (uses M6X1 bolts)

6 Patented carpet grip system

7 Carpet grip release clip

Push towards rear of pedal unit to release

8 Change pedal face position (requires 2.5mm hex key)

10 ENGLISH

USING THE DUAL CLUTCH IN-GAME

Using a dual clutch system from a grid start in a race enables

you to achieve maximum traction without the need to nd the

bite point of your clutch pedal - this can give you a signicant

advantage at the start of a race.

To use the dual clutch system in-game:

1 At race start, fully depress the clutch pedal and the button

assigned to the dual clutch function (see next section

forsetting instructions).

2 Select rst gear using the Gear Up Paddle and fully depress

the gas pedal.

3 As soon as you get the green light for race start, immediately

release the Dual Clutch button. The car should start moving

as the bite point of the clutch is engaged.

4 Smoothly release your foot from the clutch pedal in order

toachieve maximum traction. It’s worth practicing this last

step and modifying the bite point setting several times

to nd amethod that works for you. Once you have it

perfected, thisfeature can help make up several places on

the grid.

Note:

Support for the dual clutch function is not possible in some

games. A list of games that support the dual clutch feature

canbe found at logitechG.com/support/g923-ps4

Note:

Whilst in the Dual Clutch setting mode the RPM LEDs will not

respond to the game/SDK

SETTING UP THE DUAL CLUTCH SYSTEM

1 Press and hold the left and right gear paddle L3

andR3buttons together for two seconds to enter

dualclutchsettingmode. The RPM LEDs will illuminate blue

and ashslowly:
