Linx Technologies HumPRO MDEV-900-PRO Manuel de service

HumPROTM Series Master Development System

Quick Start Reference

Remove Contents

Remove kit contents including development boards,

antennas, batteries, modules and USB cables.

1Set Up the Programming Docks

With the power off, set up boards by inserting EVMs into

sockets on the Programming Docks and attaching the

antennas.

Revised 6/20/14

Install the Windows software from the

CD that is included with the kit. If already

installed, skip this step.

Install the Software

Connect the Programming Docks to a

computer with the cables included with

the kit. USB drivers are on the CD so

install them if prompted by the computer.

Connect the Programming Docks

Start the software. It automatically

detects conected modules and reads

their conﬁgurations.

Start the Software

RFACTV

RESET

CMD_DATA_IN

POWER_DOWN

CMD

CTS

NV_RESET

CMD_DATA_OUT

VCC

CRESP

LNA_EN

PA_EN

Warning: Installing or removing a Carrier Board

while power is applied could cause permanent dam-

age to the module. Either turn off power to the board

or unplug the USB cable before installing or removing a

Carrier Board
