TABLE OF CONTENTS

HARDWARE INFORMATION

What is the Linksys WRT1900ACS Dual-Band Wi-Fi Router with Ultra-Fast 1.6 GHz

CPU?

What are the parts of the Linksys WRT1900ACS?

What does the LED behavior of the Linksys WRT1900ACS indicate?

What is the warranty period of the Linksys WRT1900ACS?

Where can I find the router’s serial number?

What USB standard does the Linksys WRT1900ACS support?

What is the recommended antenna position for the Linksys WRT1900ACS?

What is the Combo USB 2.0 / eSATA port on my Linksys WRT1900ACS and how does it

work?

What is the Network Map feature of my Linksys WRT1900ACS and how can I use it?

Can I wall-mount the Linksys WRT1900ACS?

10.

Is the Linksys WRT1900ACS stackable?

11.

Does the Linksys WRT1900ACS v1 support Open Source?

12.

What is the Wireless Scheduler feature of my Linksys WRT1900ACS and how can I use

it?

13.

SETUP & INSTALLATION

What requirements are needed in setting up the Linksys WRT1900ACS?

How do I set up the Linksys WRT1900ACS?

Will I be able to run the setup software on a wired computer even though my wireless

adapter is disabled?

What are the default IP Address and password of the Linksys WRT1900ACS?

Can I configure my 5 GHz network during set up?

Can I configure my Linksys WRT1900ACS as a wireless bridge or repeater?

FIRMWARE UPGRADE

How do I upgrade the firmware on the Linksys WRT1900ACS?

Is the Linksys WRT1900ACS v1 firmware compatible with the Linksys WRT1900ACS v2

firmware and vice versa?

Linksys Official Support - Linksys WRT1900ACS Frequently Asked Que... https://www.linksys.com/us/support-article?articleNum=178015

2 of 13

7/8/2019, 10:19 AM

WIRELESS CONNECTION & SECURITY

What wireless security modes does the Linksys WRT1900ACS support?

Which wireless connection standards and frequencies are supported by the Linksys

WRT1900ACS?

Does the Linksys WRT1900ACS support the 80 MHz channel width on the 5 GHz

frequency?

How do I connect a wireless device to the wireless network of the Linksys

WRT1900ACS?

Where can I see the default wireless network name (SSID) and passphrase of the

Linksys WRT1900ACS?

Can I change the default wireless settings during setup?

Does the Linksys WRT1900ACS support simultaneous dual-band (2.4 GHz and 5 GHz)

connection?

What is the 802.11ac standard and what is its speed?

Which wireless band should be used to achieve a speed of up to 1300 Mbps?

How many Guest networks can I set up on my Linksys WRT1900ACS?

10.

ADVANCED CONFIGURATION

What is a media server and how does it work?

Can I connect a USB hub to the USB port of the Linksys WRT1900ACS to use multiple

devices?

Does the Linksys WRT1900ACS allow VPN tunnels using IPSec, L2TP or PPTP

protocols as pass-through?

Does the Linksys WRT1900ACS support SPI firewall?

Does the Linksys WRT1900ACS offer a Filter IDENT that block specific Internet data

types?

What is Demilitarized Zone (DMZ) and what is it used for?

What Dynamic Domain System (DDNS) providers does the Linksys WRT1900ACS

support?

TROUBLESHOOTING

How can I reset the Linksys WRT1900ACS to factory defaults?

I have reset the Linksys WRT1900ACS and now I can’t launch the setup page. What do

I do?

Linksys Official Support - Linksys WRT1900ACS Frequently Asked Que... https://www.linksys.com/us/support-article?articleNum=178015

3 of 13

7/8/2019, 10:19 AM

What should I do if I can't connect to the Internet wirelessly and my network name is not

listed in Available Networks?

What should I do when my wireless network performance is slow, inconsistent or having

difficulty maintaining a VPN connection?

The Parental Controls feature blocks HTTPS but returns a blank page instead of

redirecting to the Parental Controls screen. Is this a normal behavior?

HARDWARE INFORMATION

1. What is the Linksys WRT1900ACS Dual-Band Wi-Fi Router with Ultra-Fast 1.6 GHz CPU?

The Linksys WRT1900ACS Dual-Band Wi-Fi Router with Ultra-Fast 1.6 GHz CPU is a simultaneous

dual-band 3 x 3 Gigabit router with USB / External Serial Advanced Technology Attachment (eSATA)

ports that supports a maximum of 600 Mbps on the 2.4 GHz band and up to 1.3 Gbps on the 5 GHz

band. It comes with four (4) high-performance external antennas for enhanced dual-band

communication, maximum signal strength, better coverage and range. The antennas are adjustable to

customize your wireless signal for single or multi-story buildings and are removable to accommodate

upgrades. For more information about the product features and specification of the Linksys

WRT1900ACS, click here(https://kb.linksys.com/us/support-article?articleNum=178016).

2. What are the parts of the Linksys WRT1900ACS?

The Linksys WRT1900ACS has the following parts:

Four (4) detachable high-performance external antennas

LED lights:

Power

Internet

2.4 GHz

5 GHz

eSATA

USB 1

USB 2 (primary and secondary)

Ethernet 1 ~ 4 (primary and secondary)

Wi-Fi Protected Setup™ (WPS)

Buttons:

WPS

Linksys Official Support - Linksys WRT1900ACS Frequently Asked Que... https://www.linksys.com/us/support-article?articleNum=178015

4 of 13

7/8/2019, 10:19 AM

Reset

Ports:

Ethernet 1 ~ 4

Internet

USB 3.0

Combo port USB 2.0 / eSATA

Power connector

3. What does the LED behavior of the Linksys WRT1900ACS indicate?

The LED behavior indicates the different activities and the status of your router. For a detailed

description on the different Linksys WRT1900ACS LED activities, click here(https://kb.linksys.com

/us/support-article?articleNum=178016#LEDs).

4. What is the warranty period of the Linksys WRT1900ACS?

The warranty period is dependent on the country of purchase. For more information about your

device’s warranty, click here(https://kb.linksys.com/us/support-article?articleNum=135959).

5. Where can I find the router’s serial number?

The router’s serial number is printed on the sticker located underneath the device. You can also locate

this via the router’s web-based setup page by going to Troubleshooting > Status > Report.

6. What USB standard does the Linksys WRT1900ACS support?

The Linksys WRT1900ACS has a USB 2.0 / eSATA port and a USB 3.0 port which are backward-

compatible with older USB versions.

7. What is the recommended antenna position for the Linksys WRT1900ACS?

For more information and image reference, click here(https://kb.linksys.com/us/support-

article?articleNum=138847).

8. What is the Combo USB 2.0 / eSATA port on my Linksys WRT1900ACS and how does it work?

The Combo USB 2.0 / eSATA port of the Linksys WRT1900ACS allows you to connect a USB external

hard drive or an eSATA drive to the network.

NOTE: You can only connect one (1) device at a time. The Linksys WRT1900ACS supports SATA-II.

9. What is the Network Map feature of my Linksys WRT1900ACS and how can I use it?

Linksys Official Support - Linksys WRT1900ACS Frequently Asked Que... https://www.linksys.com/us/support-article?articleNum=178015

5 of 13

7/8/2019, 10:19 AM

The Network Map feature of your Linksys WRT1900ACS allows you to manage and monitor your

devices’ connection to the network. For an overview of the functions of your Network Map Tool, click

here(https://kb.linksys.com/us/support-article?articleNum=136118). To know how to manage devices

using the Network Map Tool, click here(https://kb.linksys.com/us/support-article?articleNum=138954).

10. Can I wall-mount the Linksys WRT1900ACS?

Yes. For instructions on how to wall-mount, click here(https://kb.linksys.com/us/support-

article?articleNum=140774).

11. Is the Linksys WRT1900ACS stackable?

Yes, the Linksys WRT1900ACS is stackable. However, it is recommended that it should be stacked on

top of other stackable devices. Do NOT stack any other devices on top of it to prevent blocking the

ventilation of the router.

12. Does the Linksys WRT1900ACS v1 support Open Source?

Yes, Linksys WRT1900ACS v1 is Open Source-ready. With this, the Open Source community's

demand for Linksys router source codes is met. The base source code is made available for coders to

be able to tweak their own firmware. However, Linksys will only support the official firmware. Since

only the base codes are available, the final consumer codes would have its own security encoding,

which makes it safe for daily use.

13. What is the Wireless Scheduler feature of my Linksys WRT1900ACS and how can I use it?

The Wireless Scheduler feature of your Linksys WRT1900ACS allows you to turn OFF or ON the

wireless networks, including the Guest networks at your preferred time. To know more about this, click

here(https://kb.linksys.com/us/support-article?articleNum=140821).

SETUP & INSTALLATION

1. What requirements are needed in setting up the Linksys WRT1900ACS?

Before setting up the Linksys WRT1900ACS, you will need the following:

A broadband Internet connection

At least one (1) computer with a wired or wireless network adapter

RJ45 Ethernet cable/s

Internet browser (Internet Explorer® 8 or higher, Firefox® 8 or higher, Google Chrome™ 10 or higher,

or Safari® 5 or higher)

2. How do I set up the Linksys WRT1900ACS?

Linksys Official Support - Linksys WRT1900ACS Frequently Asked Que... https://www.linksys.com/us/support-article?articleNum=178015

6 of 13

7/8/2019, 10:19 AM

Setting up the Linksys WRT1900ACS is made fast and easy because of its CD-less setup. Now you

can run the setup from a web browser even if the router initially has no Internet connection and is on

factory default settings. To learn how to set up the Linksys WRT1900ACS, click

here(https://kb.linksys.com/us/support-article?articleNum=142526).

3. Will I be able to run the setup software on a wired computer even though my wireless adapter

is disabled?

Yes, you will be able to run the setup software on a wired computer even though the wireless adapter is

disabled. Just connect the router to the computer using an Ethernet cable, open a web browser and

start the setup process.

4. What are the default IP Address and password of the Linksys WRT1900ACS?

The default IP Address for this router is 192.168.1.1. The default password is admin.

5. Can I configure my 5 GHz network during set up?

Wireless setting changes during setup apply to both the 2.4 GHz and 5 GHz bands. You can configure

unique wireless settings for these bands after you complete the setup. To learn how you can set up the

Linksys WRT1900ACS's 5 GHz network, click here(https://kb.linksys.com/us/support-

article?articleNum=142526).

6. Can I configure my Linksys WRT1900ACS as a wireless bridge or repeater?

Yes. The Linksys WRT1900ACS can be configured as a wireless bridge or repeater. To learn how to

configure a Linksys Smart Wi-Fi Router to work as a wireless bridge, click here(https://kb.linksys.com

/us/support-article?articleNum=141083). For instructions on how to configure it as a wireless repeater,

click here(https://kb.linksys.com/us/support-article?articleNum=136155).

FIRMWARE UPGRADE

1. How do I upgrade the firmware on the Linksys WRT1900ACS?

checkbox. This will automatically upgrade the Linksys WRT1900ACS if there is a new firmware

available. You may also click the Check for Updates button to identify if there is a new firmware

available.

NOTE: To upgrade the firmware manually, you can click the Choose File button. However, you first

need to download the appropriate firmware from the Linksys WRT1900ACS Downloads

page(https://kb.linksys.com/us/support-article?articleNum=165487).

Linksys Official Support - Linksys WRT1900ACS Frequently Asked Que... https://www.linksys.com/us/support-article?articleNum=178015

7 of 13

7/8/2019, 10:19 AM

2. Is the Linksys WRT1900ACS v1 firmware compatible with the Linksys WRT1900ACS v2

firmware and vice versa?

No, the Linksys WRT1900ACS v1 firmware is NOT compatible with the Linksys WRT1900ACS v2

firmware and vice versa.

WIRELESS CONNECTION & SECURITY

1. What wireless security modes does the Linksys WRT1900ACS support?

The Linksys WRT1900ACS supports WEP, WPA2™ Personal, WPA2™ Enterprise, WPA2™ /

WPA™ Mixed Personal, WPA2™ / WPA™ Mixed Enterprise.

2. Which wireless connection standards and frequencies are supported by the Linksys

WRT1900ACS?

The Linksys WRT1900ACS is compatible with 802.11ac, 802.11b, 802.11g, 802.11n and

802.11a technologies. It supports the 2.4 GHz and 5 GHz frequencies.

3. Does the Linksys WRT1900ACS support the 80 MHz channel width on the 5 GHz frequency?

Yes, the 5 GHz band supports the 80 MHz channel width provided that the Channel Width option in the

router's web-based setup page is set to Auto. There is currently no option to select the 80 MHz only

setting.

4. How do I connect a wireless device to the wireless network of the Linksys WRT1900ACS?

To connect a wireless device to the network, you will need to know your wireless settings such as the

network name (SSID) and password. For specific instructions, click here(https://kb.linksys.com

/us/support-article?articleNum=143213).

5. Where can I see the default wireless network name (SSID) and passphrase of the Linksys

WRT1900ACS?

The default network name (SSID) and passphrase can be located at the bottom of the Linksys

WRT1900ACS.

6. Can I change the default wireless settings during setup?

Yes, you will have the option to customize the network name (SSID) and the passphrase.

7. Does the Linksys WRT1900ACS support simultaneous dual-band (2.4 GHz and 5 GHz)

Linksys Official Support - Linksys WRT1900ACS Frequently Asked Que... https://www.linksys.com/us/support-article?articleNum=178015

8 of 13

7/8/2019, 10:19 AM

connection?

Yes, the Linksys WRT1900ACS supports simultaneous dual-band connection.

8. What is the 802.11ac standard and what is its speed?

The 802.11ac is a standard that works on the 5 GHz band of the Linksys WRT1900ACS. It can have a

wireless speed of up to 1300 Mbps when matched with an 802.11ac adapter and when the Channel

Width of the router is set to Auto.

9. Which wireless band should be used to achieve a speed of up to 1300 Mbps?

The speed of up to 1300 Mbps can be achieved if the 5 GHz band is used.

NOTE: Your wireless device should also support the high data rates of up to 1300 Mbps.

10. How many Guest networks can I set up on my Linksys WRT1900ACS?

The Linksys WRT1900ACS allows you to have two (2) Guest networks for the 2.4 GHz and 5 GHz

networks respectively. With these, your visitors at home can connect to the Internet but not have

access to your shared storage devices, and printer .

NOTE: This router supports up to 50 guests.

ADVANCED CONFIGURATION

1. What is a media server and how does it work?

It allows Digital Living Network Alliance (DLNA®) devices including digital media players, gaming

consoles, and digital picture frames to access video, music, and pictures that are stored on a USB hard

drive that is connected to the Linksys WRT1900ACS. Its Storage File System supports File Allocation

Table (FAT), Hierarchical File System Plus (HFS+) and New Technology File System (NTFS).

2. Can I connect a USB hub to the USB port of the Linksys WRT1900ACS to use multiple

devices?

No, you cannot connect a USB hub to the USB port of your Linksys WRT1900ACS.

3. Does the Linksys WRT1900ACS allow VPN tunnels using IPSec, L2TP or PPTP protocols as

pass-through?

Yes, the Linksys WRT1900ACS allows VPN tunnels using Internet Protocol Security (IPSec), Layer 2

Tunneling Protocol (L2TP) or Point-To-Point Tunneling Protocol (PPTP) as pass-through.

Linksys Official Support - Linksys WRT1900ACS Frequently Asked Que... https://www.linksys.com/us/support-article?articleNum=178015

9 of 13

7/8/2019, 10:19 AM

4. Does the Linksys WRT1900ACS support SPI firewall?

Yes, this helps protect your local network from Internet threats. This option is enabled by default.

5. Does the Linksys WRT1900ACS offer a Filter IDENT that block specific Internet data types?

Yes, this feature keeps port 113 from being scanned by devices outside of your local network. This

option is enabled by default.

6. What is Demilitarized Zone (DMZ) and what is it used for?

The DMZ feature allows one (1) local user to be exposed to the Internet for use of a special-purpose

service such as Internet gaming and videoconferencing (VC). The DMZ hosting forwards all the ports

at the same time to one (1) computer.

NOTE: Port Forwarding is more secure compared to enabling the DMZ feature because it only opens

the ports you want to open.

7. What Dynamic Domain System (DDNS) providers does the Linksys WRT1900ACS support?

The Linksys WRT1900ACS supports DynDNS.org and NO-IP.com providers.

TROUBLESHOOTING

1. How can I reset the Linksys WRT1900ACS to factory defaults?

There are two (2) ways to reset the Linksys WRT1900ACS to factory defaults:

Hardware Reset – Press and hold the Reset button at the back panel of the router for 10 seconds

then release.

Software Reset – Log in to your Linksys cloud account. Under Router Settings,

click Troubleshooting > Diagnostics. Click Reset under Factory reset.

2. I have reset the Linksys WRT1900ACS and now I can’t launch the setup page. What do I do?

You can try the following troubleshooting steps:

Step 1:

Enter “myrouter.local” or “192.168.1.1” in the Address bar of a web browser.

Step 2:

If your computer has a static IP Address, make sure it has valid DNS numbers. If not, set the

computer to obtain an IP Address automatically.

Linksys Official Support - Linksys WRT1900ACS Frequently Asked Que... https://www.linksys.com/us/support-article?articleNum=178015

10 of 13

7/8/2019, 10:19 AM

Table des matières

Autres manuels Linksys Routeur sans fil

Linksys

Linksys WRT54GS Manuel d'utilisation

Linksys

Linksys EtherFast Instant Broadband BEFW11S4 Manuel utilisateur

Linksys

Linksys WHW0301 Manuel utilisateur

Linksys

Linksys E9450 Manuel utilisateur

Linksys

Linksys WRV200 Manuel d'utilisation

Linksys

Linksys WRT54GC - Compact Wireless-G Broadband Router... Manuel utilisateur

Linksys

Linksys WRT54GL - Wireless-G Broadband Router... Manuel utilisateur

Linksys

Linksys WRK54G Manuel utilisateur

Linksys

Linksys WRT54GR - Wireless-G Broadband Router Manuel utilisateur

Linksys

Linksys WRT54GR - Wireless-G Broadband Router Manuel utilisateur

Linksys

Linksys WRT300N - Wireless-N Broadband Router... Manuel utilisateur

Linksys

Linksys WHW0303 Manuel utilisateur

Linksys

Linksys WRT310N - Wireless-N Gigabit Router Wireless Manuel utilisateur

Linksys

Linksys WRT54GX - Wireless-G Broadband Router Manuel utilisateur

Linksys

Linksys WRT54G3G - Wireless-G Router For Verizon Wireless... Manuel utilisateur

Linksys

Linksys MAX-STREAM EA7250 Manuel utilisateur

Linksys

Linksys X1000 Manuel utilisateur

Linksys

Linksys WRT54GR - Wireless-G Broadband Router Manuel utilisateur

Linksys

Linksys MAX-STREAM MR7300 Series Manuel utilisateur

Linksys

Linksys WRT600N - Wireless-N Gigabit Router Manuel d'utilisation

Linksys

Linksys WRT160N - Wireless-N Broadband Router... Manuel utilisateur

Linksys

Linksys MAX-STREAM EA9500 Instructions d'utilisation

Linksys

Linksys WRT54GC - Compact Wireless-G Broadband Router... Manuel d'utilisation

Linksys

Linksys WRT160NL - Wireless-N Broadband Router Manuel utilisateur

Manuels Routeur sans fil populaires d'autres marques

Milesight

Milesight UG67 Manuel utilisateur

Airlogic

Airlogic AirSync Class 1 Manuel du propriétaire

Samsung

Samsung WCH730B Manuel utilisateur

TELEFONICA

TELEFONICA USB Adapter Manuel utilisateur

NETGEAR

NETGEAR PowerLINE WiFi 1000 Series Manuel utilisateur

Askey

Askey RAC2V1K Manuel utilisateur

Alloy

Alloy WLF2454AP-S Manuel utilisateur

TP-Link

TP-Link TL-WR542G Manuel utilisateur

NETGEAR

NETGEAR WNR2000v4 Manuel utilisateur

Hama

Hama 53120 Manuel utilisateur

Intellinet

Intellinet 524582 Manuel utilisateur

Asus

Asus RT-N10P Manuel utilisateur

D-Link

D-Link DIR-506L Manuel utilisateur

Sapido

Sapido GR297n Manuel utilisateur

Asus

Asus DSL-N55U Manuel utilisateur

AMTC

AMTC WR7502 Manuel utilisateur

Compaq

Compaq CP-2W - iPAQ Connection Point Manuel utilisateur

SMC Networks

SMC Networks WBR14-N2 FICHE Manuel utilisateur
