Linksys WPS54G - Wireless-G PrintServer Print Server Instructions d'utilisation d'origine

A Division of Cisco Systems, Inc.

Model No.

Quick Installation

Model No.

Wireless

WPS54G

PrintServer

Wireless-G

Package Contents

• Wireless-G PrintServer

• Setup Wizard CD-ROM

•UserGuideonCD-ROM

•USB2.0Cable

•NetworkCable

• Power Supply

• Quick Installation

• Registration Card

Before starting the physical

installation, note the PrintServer’s

default name. The default name is

shown in the Server field on the

sticker located on the PrintServer’s

back panel.

AUse the USB cable to connect

your USB printer to the

PrintServer’s USB Printer port.

BIf you are connecting the

PrintServer to your wired

network, then plug one end of

the Ethernet network cable into

the PrintServer’s Ethernet port.

Then connect the other end to

your router or switch.

CPower on your printer.

DPlug the power adapter into

the PrintServer’s Power port.

Then plug the other end into

an electrical outlet.

Connect the PrintServer

EThe IP Settings screen will

appear. If your network uses a

router that automatically

assigns IP addresses, select

Automatically obtain an IP

address (DHCP) and click

Next. If you need to assign the

PrintServer a static IP address,

select Set IP configuration

manually, and enter the IP

Address, Subnet Mask, and

Gateway in the fields provided.

Then click Next.

FOn the Set PrintServer’s

Password screen, enter the

PrintServer’s default password,

admin, in the Current

Password field. Enter a new

password in the New Password

field, and enter it again in the

Verify Password field.

Click Next.

GOn the Wireless Settings

screen, enter your wireless

network’s SSID or name. If your

network is set to ad-hoc mode,

select the channel at which

the network broadcasts its

wireless signal. For the Network

Type setting, select

infrastructure if the PrintServer

will communicate using an

access point or wireless router.

Select Ad-Hoc if the PrintServer

will communicate directly with

wireless-equipped computers.

Click Next.

Configure the PrintServer

AInsert the Setup CD-ROM into

the computer’s CD-ROM drive.

The Setup Wizard should run

automatically. If it does not,

click Start and choose Run. In

the field that appears,

enter D:\setupWizard.exe (if

“D” is the letter of your

CD-ROM drive).

BOn the Welcome screen, click

Setup Wizard.

CThe Setup Wizard will search for

the PrintServer. After it has been

found, the Wireless-G

PrintServer Setup screen will

appear. If this is the first time

you have run the Setup Wizard,

make sure that List only new

(unconfigured) Print Servers is

selected and your PrintServer is

listed by its default server

name. If you have previously

configured the PrintServer,

select List all compatible Print

Servers. Click Next.

DOn the Basic Settings screen,

you may change the Device

Name and Domain Name

settings if you want. Then

click Next.

GHz

2.4

802.11g

Linksys recommends that you set up

your printer and install your printer’s

driver before you install the

PrintServer’s driver.

AOn the Print Server Driver Setup

Welcome screen, click Next.

BOn the Choose Destination

Location screen, select the

location where the driver’s

folder will be installed. If you

want the folder to be installed

in a different location, click

Browse and select the

location. Click Next.

CThe Select Program Folder

screen will appear. An icon will

be added to the program

folder listed. If you want, you

may change the name of the

program folder. Click Next.

HOn the Wireless Security

Settings screen, select a level

of WEP encryption, 64 Bit Keys

or 128 Bit Keys. Then enter a

Passphrase to automatically

generate a WEP key. Then

click Next.

If you would like to enter your

WEP key manually, leave the

Passphrase field blank and

enter the WEP key on the next

screen. Then click Next.

IIf you used a Passphrase, then

a WEP key will appear on the

following screen. Otherwise,

enter your WEP key in the Key 1

field. Click Next.

JOn the Confirmation screen,

make sure your settings are

correct. Click Yes to save your

new settings.

KOn the Congratulations

screen, click User Install to

install the PrintServer’s driver.

Install and Configure the

IThe Configure Printer Port

screen will appear. Your

installed printer(s) will appear in

the Existing Printers field. Select

the printer you want, and click

the Connect button to

associate the printer with your

selected printer port. To add

another printer, click Add New

Printer and follow the on-

screen instructions.

JWhen you have finished

configuring the PrintServer’s

driver, click Close on the Printer

Port Setup screen.

Congratulations! The installation of

the PrintServer is complete.

DAfter the driver is installed, the

Setup Complete screen will

appear. Make sure Configure

Print Driver now is selected.

Click Next to end the driver

installation and begin the driver

configuration.

EDouble-click the Print Driver

Setup icon on your desktop. If

you do not see the icon, click

Start, Programs, Print Server

Utility, and Print Driver Setup.

FRead the Information screen,

and click OK.

GOn the Printer Port Setup

screen, select a printer port to

add, and click Next.

HYou will be informed that the

PrintServer Port has been

added successfully. Click OK.

For additional information or troubleshooting

help, refer to the User Guide on the Setup CD-

ROM. You can also call or e-mail for further

support.

24-hour Technical Support

800-326-7114

(toll-free from US or Canada)

E-mail Support

[email protected]

Website

http://www.linksys.com or

http://support.linksys.com

RMA (Return Merchandise Authorization)

http://www.linksys.com/support

FTP Site

ftp://ftp.linksys.com

Sales Information

800-546-5797 (800-LINKSYS)

Linksys is a registered trademark or trademark of

Cisco Systems, Inc. and/or its affiliates in the U.S.

Model No.

WPS54G-QI-40917A JL

PrintServer’s Driver
