Linksys WRTSL54GS Manuel utilisateur

A Division of Cisco Systems, Inc.

Model No.

Media Storage Link Router

Wireless-G

WRTSL54GS

User Guide

WIRELESS

GHz

2.4

802.11g

with SpeedBooster

Wireless-G Media Storage Link Router with SpeedBooster

Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco

rights reserved. Other brands and product names are trademarks or registered trademarks of their respective

holders.

How to Use This User Guide

This User Guide has been designed to make understanding networking with the Wireless-G Media Storage Link

Router with SpeedBooster easier than ever. Look for the following items when reading this User Guide:

In addition to these symbols, there are definitions for technical terms that are presented like this:

Also, each figure (diagram, screenshot, or other image) is provided with a figure number and description, like

this:

Figure numbers and descriptions can also be found in the “List of Figures” section in the “Table of Contents”.

This exclamation point means there is a caution or

warning and is something that could damage your

property or the Router.

This checkmark means there is a note of interest and

is something you should pay special attention to

while using the Router.

This question mark provides you with a reminder

about something you might need to do while using

the Router.

word: definition.

Figure 0-1: Sample Figure Description

WRTSL54GS-UG-51025A JL

WARNING: This product contains chemicals, including lead, known

to the State of California to cause cancer, and birth defects or other

reproductive harm. Wash hands after handling.

Wireless-G Media Storage Link Router with SpeedBooster

Table of Contents

Chapter 1: Introduction 1

Welcome 1

What’s in this User Guide? 2

Chapter 2: Planning Your Wireless Network 4

Network Topology 4

Ad-Hoc versus Infrastructure Mode 4

Network Layout 4

Chapter 3: Getting to Know the Wireless-G Media Storage Link Router 6

The Back Panel 6

The Front Panel 7

Chapter 4: Connecting the Wireless-G Media Storage Link Router 8

Instructions for Connecting the Router 8

Placement Options 10

Chapter 5: Configuring the Wireless-G Media Storage Link Router 12

Overview 12

The Setup Tab - Basic Setup 13

The Setup Tab - DDNS 18

The Setup Tab - MAC Address Clone 19

The Setup Tab - Advanced Routing 20

The Wireless Tab - Basic Wireless Settings 22

The Wireless Tab - Wireless Security 24

The Wireless Tab - Wireless MAC Filter 27

The Wireless Tab - Advanced Wireless Settings 28

The Security Tab - Firewall 30

The Security Tab - VPN Passthrough 31

The Storage Tab - Disk 32

The Storage Tab - Share 33

The Storage Tab - Administration 34

The Storage Tab - Media Server 36

The Access Restrictions Tab - Internet Access 37

The Applications and Gaming Tab - Port Range Forward 39

The Applications & Gaming Tab - Port Triggering 40

Wireless-G Media Storage Link Router with SpeedBooster

The Applications and Gaming Tab - DMZ 41

The Applications and Gaming Tab - QoS 42

The Administration Tab - Management 44

The Administration Tab - Log 45

The Administration Tab - Diagnostics 46

The Administration Tab - Factory Defaults 47

The Administration Tab - Firmware Upgrade 47

The Administration Tab - Config Management 47

The Status Tab - Router 48

The Status Tab - Local Network 49

The Status Tab - Wireless 50

Appendix A: Troubleshooting 51

Common Problems and Solutions 51

Frequently Asked Questions 59

Appendix B: Wireless Security 67

Security Precautions 67

Security Threats Facing Wireless Networks 67

Appendix C: Upgrading Firmware 70

Appendix D: Windows Help 71

Appendix E: Finding the MAC Address and IP Address for Your

Ethernet Adapter 72

Windows 98SE or Me Instructions 72

Windows 2000 or XP Instructions 72

For the Router’s Web-based Utility 73

Appendix F: Glossary 74

Appendix G: Specifications 79

Appendix H: Warranty Information 81

Appendix I: Regulatory Information 82

Appendix J: Contact Information 88

Wireless-G Media Storage Link Router with SpeedBooster

List of Figures

Figure 3-1: The Router’s Back Panel 6

Figure 3-2: The Router’s Front Panel 7

Figure 4-1: Connect the USB Disk 8

Figure 4-2: Connect the Broadband Modem 9

Figure 4-3: Connect Your Network Devices 9

Figure 4-4: Connect the Power 10

Figure 4-5: Stand in Closed Position 10

Figure 4-6: Wall-Mount Slots 11

Figure 5-1: Login Screen 12

Figure 5-2: Setup Tab - Basic Setup 13

Figure 5-3: DHCP Connection Type 13

Figure 5-4: Static IP Connection Type 13

Figure 5-5: PPPoE Connection Type 14

Figure 5-6: PPTP Connection Type 14

Figure 5-7: L2TP Connection Type 15

Figure 5-8: Telstra Cable Connection Type 15

Figure 5-9: Optional Settings 16

Figure 5-10: Router IP 16

Figure 5-11: Network Address Server Settings 16

Figure 5-12: Time Setting 17

Figure 5-13: Setup Tab - DDNS (DynDNS.org) 18

Figure 5-14: Setup Tab - DDNS (TZO.com) 18

Figure 5-15: Setup Tab - MAC Address Clone 19

Figure 5-16: Setup Tab - Advanced Routing (Gateway) 20

Figure 5-17: Setup Tab - Advanced Routing (Router) 20

Figure 5-18: Routing Table Entry List 21

Figure 5-19: Wireless Tab - Basic Wireless Settings 22

Figure 5-20: SecureEasySetup Ready Screen 23

Figure 5-21: Wireless Tab - Wireless Security (WPA Personal) 24

Figure 5-22: Wireless Tab - Wireless Security (WPA Enterprise) 24

Figure 5-23: Wireless Tab - Wireless Security (WPA2 Personal) 25

Wireless-G Media Storage Link Router with SpeedBooster

Figure 5-24: Wireless Tab - Wireless Security (WPA2 Enterprise) 25

Figure 5-25: Wireless Tab - Wireless Security (RADIUS) 26

Figure 5-26: Wireless Tab - Wireless Security (WEP) 26

Figure 5-27: Wireless Tab - Wireless MAC Filter 27

Figure 5-28: MAC Address Filter List 27

Figure 5-29: Wireless Tab - Advanced Wireless Settings 28

Figure 5-30: Security Tab - Firewall 30

Figure 5-31: Security Tab - VPN Passthrough 31

Figure 5-32: Storage Tab - Disk 32

Figure 5-33: Claim Disk 32

Figure 5-34: Storage Tab - Claimed Disk 32

Figure 5-35: Storage Tab - Share 33

Figure 5-36: Share Properties 33

Figure 5-37: Share Access 33

Figure 5-38: Storage Tab - Administration 34

Figure 5-39: User Properties 34

Figure 5-40: Modify - Group Properties 35

Figure 5-41: Create New Group - Group Properties 35

Figure 5-42: Storage Tab - Media Server 36

Figure 5-43: Partition List 36

Figure 5-44: Access Restrictions Tab - Internet Access 37

Figure 5-45: Internet Policy Summary 37

Figure 5-46: List of PCs 38

Figure 5-47: Port Services 38

Figure 5-48: Applications and Gaming Tab - Port Range Forward 39

Figure 5-49: Applications and Gaming Tab - Port Triggering 40

Figure 5-50: Applications and Gaming Tab - DMZ 41

Figure 5-51: Applications and Gaming Tab - QOS 42

Figure 5-52: Administration Tab - Management 44

Figure 5-53: Administration Tab - Log 45

Figure 5-54: Incoming Log Table 45

Figure 5-55: Outgoing Log Table 45

Figure 5-56: Administration Tab - Diagnostics 46

Figure 5-57: The Ping Test 46

Wireless-G Media Storage Link Router with SpeedBooster

Figure 5-58: The Traceroute Test 46

Figure 5-59: Administration Tab - Factory Defaults 47

Figure 5-60: Administration Tab - Firmware Upgrade 47

Figure 5-61: Administration Tab - Config Management 47

Figure 5-62: Status Tab - Router 48

Figure 5-63: Status Tab - Local Network 49

Figure 5-64: DHCP Clients Table 49

Figure 5-65: Status Tab - Wireless 50

Figure C-1: Upgrade Firmware 70

Figure E-1: IP Configuration Screen 72

Figure E-2: MAC Address/Adapter Address 72

Figure E-3: MAC Address/Physical Address 72

Figure E-4: MAC Address Filter List 73

Figure E-5: MAC Address Clone 73

Chapter 1: Introduction

Welcome

Wireless-G Media Storage Link Router with SpeedBooster

Chapter 1: Introduction

Welcome

Thank you for choosing the Linksys Wireless-G Media Storage Link Router with SpeedBooster. The Router will

allow you to network wirelessly better than ever, sharing Internet access, files and fun, easily and securely.

How does the Router do all of this? A router is a device that allows access to an Internet connection over a

network. With the Router, this access can be shared over the four switched ports or via the wireless broadcast at

up to 11Mbps for Wireless-B or up to 54Mbps for Wireless-G.

The Router also has a built-in media server, so it can stream music, video, and pictures from a USB hard disk to a

Universal Plug-and-Play (UPnP)-compatible media adapter. You won’t need a computer to manage the content;

instead, let the Router can do that for you.

Use the WPA standard to secure your wireless network while the whole network is protected through a Stateful

Packet Inspection (SPI) firewall and Network Address Translation (NAT) technology. The Router’s

SecureEasySetup™ feature makes it a snap to set up WPA when you have other SecureEasySetup devices—

notebooks, printers, other peripherals—comprising your network. Run the Setup Wizard and it will guide you

through the steps. You can also access the Router’s features through the easy-to-use, browser-based utility.

But what does all of this mean?

Networks are useful tools for sharing computer resources. You can access one printer from different computers

and access data located on another computer's hard drive. Networks are even used for playing multiplayer video

games. So, networks are not only useful in homes and offices, they can also be fun.

PCs on a wired network create a LAN, or Local Area Network. They are connected with Ethernet cables, which is

why the network is called “wired”.

PCs equipped with wireless cards or adapters can communicate without cumbersome cables. By sharing the

same wireless settings, within their transmission radius, they form a wireless network. This is sometimes called

a WLAN, or Wireless Local Area Network. The Router bridges wireless networks of both 802.11b and 802.11g

standards and wired networks, allowing them to communicate with each other.

With your networks all connected, wired, wireless, and the Internet, you can now share files and Internet

access—and even play games. All the while, the Router protects your networks from unauthorized and

unwelcome users.

lan (local area network): The computers and

networking products that make up the network in

your home or office.

nat (network address translation): NAT technology

translates IP addresses of a local area network to a

different IP address for the Internet.

wpa (wi-fi protected access): a wireless security

protocol using TKIP (Temporal Key Integrity Protocol)

encryption, which can be used in conjunction with a

RADIUS server.

spi (stateful packet inspection) firewall: a technology

that inspects incoming packets of information before

allowing them to enter the network.

firewall: Security measures that protect the

resources of a local network from intruders.

Chapter 1: Introduction

What’s in this User Guide?

Wireless-G Media Storage Link Router with SpeedBooster

Linksys recommends using the Setup CD-ROM for first-time installation of the Router. If you do not wish to run

the Setup Wizard on the Setup CD-ROM, then use the instructions in this Guide to help you connect the

Router, set it up, and configure it to bridge your different networks. These instructions should be all you need to

get the most out of the Wireless-G Media Storage Link Router with SpeedBooster.

What’s in this User Guide?

This user guide covers the steps for setting up and using the Wireless-G Media Storage Link Router with

SpeedBooster.

• Chapter 1: Introduction

This chapter describes the Router’s applications and this User Guide.

• Chapter 2: Planning Your Wireless Network

This chapter describes the basics of wireless networking.

• Chapter 3: Getting to Know the Wireless-G Media Storage Link Router

This chapter describes the physical features of the Router.

• Chapter 4: Connecting the Wireless-G Media Storage Link Router

This chapter instructs you on how to connect the Router to your network.

• Chapter 5: Configuring the Wireless-G Media Storage Link Router

This chapter explains how to use the Web-based Utility to configure the settings on the Router.

• Appendix A: Troubleshooting

This appendix describes some problems and solutions, as well as frequently asked questions, regarding

installation and use of the Router.

• Appendix B: Wireless Security

This appendix explains the risks of wireless networking and some solutions to reduce the risks.

• Appendix C: Upgrading Firmware

This appendix instructs you on how to upgrade the firmware on the Router should you need to do so.

• Appendix D: Windows Help

This appendix describes how you can use Windows Help for instructions about networking, such as installing

the TCP/IP protocol.

Chapter 1: Introduction

What’s in this User Guide?

Wireless-G Media Storage Link Router with SpeedBooster

• Appendix E: Finding the MAC Address and IP Address for your Ethernet Adapter.

This appendix describes how to find the MAC address for your computer’s Ethernet adapter so you can use

the MAC filtering and/or MAC address cloning feature of the Router.

• Appendix F: Glossary

This appendix gives a brief glossary of terms frequently used in networking.

• Appendix G: Specifications

This appendix provides the technical specifications for the Router.

• Appendix H: Warranty Information

This appendix supplies the warranty information for the Router.

• Appendix I: Regulatory Information

This appendix supplies the regulatory information regarding the Router.

• Appendix J: Contact Information

This appendix provides contact information for a variety of Linksys resources, including Technical Support.

Autres manuels pour WRTSL54GS

Table des matières

Autres manuels Linksys Routeur réseau

Linksys

Linksys RangePlus WRT110 Manuel utilisateur

Linksys

Linksys WRT54GL - Wireless-G Broadband Router... Guide de démarrage rapide

Linksys

Linksys RT31P2-VU Instructions d'utilisation d'origine

Linksys

Linksys Velop Plug-in WHW01P Manuel utilisateur

Linksys

Linksys EtherFast EF4116 Manuel utilisateur

Linksys

Linksys BEFSR41 - EtherFast Cable/DSL Router Manuel utilisateur

Linksys

Linksys BEFSR41 - EtherFast Cable/DSL Router Manuel utilisateur

Linksys

Linksys RTP300 - Broadband Router With 2 Phone Ports Manuel utilisateur

Linksys

Linksys WET11 - Instant Wireless EN Bridge Network... Manuel utilisateur

Linksys

Linksys RV0041 - 10/100/1000 VPN Router Instructions d'utilisation d'origine

Linksys

Linksys WET11 - Instant Wireless EN Bridge Network... Instructions d'utilisation d'origine

Linksys

Linksys RTP300 - Broadband Router With 2 Phone Ports Mode d’emploi

Linksys

Linksys MAX-STREAM EA7500 Manuel utilisateur

Linksys

Linksys WRT54GL - Wireless-G Broadband Router... Manuel utilisateur

Linksys

Linksys AC2600 Manuel utilisateur

Linksys

Linksys RV082 Manuel utilisateur

Linksys

Linksys MAX-STREAM MR5500 Series Manuel utilisateur

Linksys

Linksys BEFW11S4 ver.3 Mode d’emploi

Linksys

Linksys BEFSR81 - EtherFast Cable/DSL Router Manuel utilisateur

Linksys

Linksys EtherFast EF3116 Manuel utilisateur

Linksys

Linksys WT54GV22 Manuel utilisateur

Linksys

Linksys EA-Series Manuel utilisateur

Linksys

Linksys RV082 Manuel d'utilisation

Linksys

Linksys PC22224 - ProConnect II 2224 Ethernet Switch Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité
